Battery Torch with LED
Components List
Wooden board
Wooden strips
Plywood
Battery holder
Aluminium strips
Acrylic glass
LED super bright
Slide switch
Push switch
Reflector
Connecting wire
Tapping screw
Tapping screw
Washer
1
113.989
Required Tools:
Wood Glue
Pencil
Phillips
Drill bit
screwdriver
The Opitec Range of projects is not intended as play toys for young children. They are tea-
ching aids for young people learning the skills of craft, design and technology. These projects
should only be undertaken and operated with the guidance of a fully qualified adult. The fini-
shed projects are not suitable to give to children under 3 years old. Some parts can be swallo-
Quantity
Size (mm)
1
100x100x10
4
100x25x10
1
100x100x3
1
1
250x10x2
1
60x60x2
1
ø10
1
19x6
1
1
ø40
1
500
6
2,9x13
4
2,2x6,5
2
4,9/9
Ruler
Jigsaw or scroll
saw
ø 2
ø 3
ø 6
ø 8
ø12
Sandpaper
File
Please Note:
wed. Danger of suffocation!
Description
Lid board
Frame strips
Back side
Power supply
Handle
Cover LED
Lighting
On/off switch
Reflector
Wiring
Screw connection
Screw connection
Spacer handle
Superglue
Soldering iron
and solder
Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Advertisement
Summary of Contents for Opitec 113989
- Page 1 Please Note: The Opitec Range of projects is not intended as play toys for young children. They are tea- ching aids for young people learning the skills of craft, design and technology. These projects should only be undertaken and operated with the guidance of a fully qualified adult. The fini- shed projects are not suitable to give to children under 3 years old.
- Page 2 Instructions 113.989 Battery Torch with LED Side part 1 Recess Drilling Slide switch Handle Side part 3+4 ø2 ø6 ø8 Recess Side part 2 ø12 Push switch Drilling handle For the side parts, shorten 2 of the wooden strips (2) to 80 mm with the jigsaw or scroll saw (side parts 3+4). Then take one of the two remaining wooden strips (100x25 mm / side part 1, pag.
- Page 3 Instructions 113.989 Battery Torch with LED Insert the reflector (10) into the opening (ø 35mm) into the opening as Screw the handle tight form both sides with a washer (14) and a shown. If necessary glue it with superglue. tapping screw (12) as shown. Insert the push switch (9) into the blind hole provided from the inside Insert the LED (7) into the opening in the reflector (10) as shown.
- Page 4 Instructions 113.989 Battery Torch with LED Place the battery holder (4) and all the wires in the box and asten the Fasten the lid (6) with the screws (13) over the reflector. Done! base plate with four screws (12). Note: Do not overtighten the screws or the lid may tear. Note:The battery holder can also be glued.
- Page 5 Instructions 113.989 Battery Torch with LED Handle Template Top Scale 1:1 Scale 1:1 Bending Template Handle Scale 1:1...
- Page 7 Instructions 113.989 Battery Torch with LED Template Side Part 1 Scale 1:1 Template Base Plate Scale 1:1...
