Page 1
The contents of this manual are subject to change without notice.
Page 2
FEATURES ● Digital circuit design ● Multi-use modulation/delay/reverb combo pedal ● Perfect tool for ambient/experimental musicians ● 16 carefully selected effect algorithms in one stompbox ● Tap Tempo function for real time effect speed/delay time control ● X, Y knobs for detailed effect control ●...
Page 3
MIX: Controls the mix level between CONTROLS A / B: Select effect groups: dry/wet signal (depending on effects) green LED – Group A, red LED – Group B DEPTH/FB: Controls the effect depth/feedback amount (depending FOOTSWITCH: on effects) Turn the pedal on/off HOLD: Engage/disengage Tap TIME: Controls the effect speed/delay Tempo function (the LED will...
Page 4
TYPE LIST A1 - Chorus A B1 - Chorus B Simulates the vintage TYPE Knob (TY) Produces a warm, chorus sound from lush chorus sound a famous jazz-amp combo Controls the mix level Controls the mix level MIX Knob (M) between dry/wet signal between dry/wet signal DEPTH/FB Knob (D)
Page 5
A2 - Phaser A B2 - Phaser B A3 - Flanger A Simulates the legendary Produces a massive Adds a phasing 4-stage phasing/rotary jet-like flanger tone variation to the sound vibe effect with plenty of feedback Volume (controls the Volume (controls the Volume (controls the effect volume) effect volume)
Page 6
B3 - Flanger B A4 - Tremolo A B4 - Tremolo B Produces a standard Produces a vintage Produces a warm bias flanger tone optical tremolo sound tremolo sound Volume (controls the Volume (controls Volume (controls effect volume) the effect volume) the effect volume) Controls the depth Controls the depth...
Page 7
A5 - Delay A B5 - Delay B A6 - Reverb A Produces a warm, Produces a pure, Simulates a plate reverberator vintage delay sound accurate delay sound Controls the mix level Controls the mix level Controls the mix level between dry/wet signal between dry/wet signal between dry/wet signal...
Page 8
B6 - Reverb B A7 - Air A B7 - Air B Simulates the acoustics Combines chorus Combines delay of a performance hall and delay in one and reverb in one Controls the delay mix Controls the mix level Controls the mix level level between dry/wet signal between dry/wet signal between dry/wet signal...
Page 9
A8 - Ambient A B8 - Ambient B Combines chorus, delay and reverb Combines chorus, delay and reverb in one, in one, producing a warm, spacious producing a clear modern ambient sound ambient sound Controls the chorus and delay Controls the chorus and delay mix level mix level between dry/wet signal between dry/wet signal Controls the delay feedback...
Delay Time Range: 25ms-2000ms Power Requirement: 9V DC center negative SPECIFICATIONS Current Consumption: 180mA Dimensions: 93.5mm (D) x 42mm (W) x 52mm (H) Weight: 150g The FCC regulation warning (for U.S.A.) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
