Uni-bond E-913 Series Installation Manual

Wire Colour Function
Red Power
Ground
Black
Yellow Pattern Selection
Surface Mount: 2 Holes @ 3 " centres
Pattern Selection (12 Flash Patterns)
- Tap yellow wire to red wire (Power) for 5 seconds to change patterns (see Flash Patterns)
To return to pattern NO. 1, touch yellow wire to red wire (Power) quickly 3 times.
-
NO.
1 Random Patterns
2 Steady Light
3 Single Flash
4 High Intensity Flash
5 Double Flash
6 Triple Flash
7 Quad Flash
8 Quint Flash
9 Quad Flash / High Intensity Flash
10 Single Flash / Quad Flash
11 Single Flash / High Intensity Flash
12 Single / Triple / Quad Flash
Wiring Instructions
- Connect fused wire from power source to "ON-OFF" Switch (ST100 sold separately)
- Run power wire from "ON/OFF" Switch to the side terminal of "Momentary ON-OFF" Toggle Switch
(ST108 sold separately)
- Connect red wires from lights to the side terminal of "Momentary ON-OFF" Toggle Switch
- The next step depends on how many lamps in a series - see below;
A Single Lamp
- Connect yellow wire from light to the bottom terminal of "Momentary ON-OFF" Toggle Switch
- Connect black wire from light to ground
B Two Lamps
- Connect both yellow wires from lights to the bottom terminal of "Momentary ON-OFF" Toggle Switch
- Connect both black wires from lights to ground
For more information, visit our website at: www.unibondlighting.com
INSTALLATION MANUAL
E-913 Series LED Warning Lights
Flash Patterns
Connect To
+12/24 VDC (Power)
-
12/24 VDC (Ground)
+12/24 VDC (Ground)
