Summary of Contents for Hocom WSW-X Series
- Page 1 User Manual WSW-X Series WSW-X Weighing Indicator User Manual DIGITAL WEIGHING INDICATOR...
- Page 2 Cautions Upon receiving the indicator, please take at least 8 hours to recharge the battery before you start to operate this indicator. Please recharge the battery after a long period of storage (more than one month). It takes 8~10 hours to fully recharge the battery.
- Page 4 Dimensions Indicator 245 x 145 x 80 mm (L x W x D) WSW-X Weighing Indicator User Manual...
-
Page 5: Symbols On Lcd
Symbols on LCD Battery Symbol ( - - appears on the top left corner of LCD, and indicates battery level display status.The battery will reduce grid by grid until there is no electricity. When it is running out of power, LCD will indicate -OFF- Please power off the indicator and recharge the battery immediately. -
Page 6: Keyboard Description
Keyboard Description Switch on / off the scale. [ UNIT ] : Select the weight mode: kg / lb / oz [→0← ZERO] : Press this key to make the indicator be at zero point. LCD will indicate →0← on the left-bottom corner. ←... - Page 7 And LCD will show -HI- then press [ TARE ] key to into Hi mode key in 2.50, then press [ F ] key twice to confirm the setting. The indicator will show different color backlight and sound beep continuously while : Yellow color Green color ≦...
- Page 8 Under (simple counting) mode ※ !! The suggested unit weight of the measured subject should be heavier than the division of this indicator. 3. Simple Counting: A. Press [ F ] key once LCD shows 0 pcs, and then press and hold [ F ] key till LCD shows S = 10 (10、20、50、100 could be selected for the sample-quantity of the measured subject).
- Page 9 !! Only can set the [ F ] Function when the mode is under pcs. Press [ F ] once to select pcs mode. Under [ F ] Function: Press and hold [ F ] key till LCD shows F - 01, and press [ UNIT ] key to select F - 01 mode to F - 06 mode, then press [ TARE ] to into mode.
- Page 10 Optional device. GROSS GROSS After using the [ ] function, please follow the steps as below to get the Net and Gross Weight Value. 1. Pressing [ ] key once could recall the deducted tare weight of container or package. Pressing [ ] key once again, LCD will be indicated 0.000, [→0←] and [Net].
- Page 11 RS232 Interface Connection: <optional device> 5 4 3 2 1 5 4 3 2 1 DATE OUT 9 8 7 6 9 8 7 6 RS232 Wiring Configuration: Baurate: 9600 Parity: None Stop Bit: 1 Data Bit: 8 WSW-X Weighing Indicator User Manual...
-
Page 12: Charge Led
Recharge the Battery _______________ Power off the indicator and connect the power cord to an AC outlet. CHARGE LED: will indicate the ongoing status of the battery. It takes about 8~10 hours to fully recharge the battery. CHARGE LED: Color of LED Status of the battery Initial connection ORANGE... - Page 13 Digital Weighing Indicator We do more than you expect WSW-X Weighing Indicator User Manual...
