V-GREAT VG-6612 Instructions

VG-6612 (Standard Version) remote control instructions
I. Product introduction
The VG-6612 remote controller is applicable to the VG-6622 smoke alarm series produced by our company, and has
the function of wireless networking for fire detection and alarm.When you need to carry out self check, mute, alarm
location and other operations on the networked fire detection alarm, just press the corresponding button of the remote
control.
II. Main technical parameters
Wireless frequency: 868.35mhz
Working voltage: DC3V (one CR2032 battery)
Working current: ＜ 10mA
Static power consumption: ≤ 2ua
Communication distance: ≥ 50m (open)
Working temperature: - 10 ~ 50 ℃
III. Product diagram
Button
Top Cover
IV. Installation and use
1. Installation
1) Insert the supplied plastic disc into the groove of the battery cover plate, rotate the position in Fig. 1 anticlockwise,
and take out the battery cover plate.
2) Pull out the red insulating sheet as shown by the arrow in Figure 2. At this time, the green indicator light on the front
of the remote control will remain on for 3 seconds, indicating that the product has been powered on (for example,
please replace the battery when pulling out the red insulating sheet).
3) Align the battery cover groove to "
and use the plastic disc to rotate clockwise to "
installation as shown in Figure 3.
VG-6612
" unlock symbol and makes the battery cover flush with the base surface,
" lock symbol position, and hear the click sound to complete the
Battery cover
Down Cover
Indicator Lamp
Groove
