Summary of Contents for LAZBOY 1800
- Page 1 POWER PACK 1800 Instruction Manual...
-
Page 2: Table Of Contents
Foreword Disclaimer and exclusion of liability La-Z-Boy is not responsible for damage resulting from: • failure to observe these instructions, • changes made to this product which have not been approved by La-Z-Boy, or • the use of replacement parts which have not been approved or manufactured by La-Z-Boy. We reserve the right to make unannounced technical changes in the course of our continal product improvement process. -
Page 3: General
General Read attentively and follow this information carefully before handling the rechargeable batteries. Keep this document in a safe place. Be sure to follow the notices and information found on the battery and packaging. Conventions used Notices which do not relate to safety are indicated in these instructions with a triangle: ▶... -
Page 4: Safety Notices
• as a power source for toys or games. The POWER PACK 1800 can be used by children of 8 years and older, persons with reduced physical, sensory or mental capabilities, or persons with lack of experience or knowledge when they are supervised or instructed concerning the safe use of the device and when they understand the resulting risks. -
Page 5: Product Identification
▶ The ratings plate shown is an example; the specifications for your product may differ from this illustration. Fig. 1: Ratings plate Power Supply PD21 (example) Fig. 2: Ratings plate POWER PACK 1800 (example) -
Page 6: Description
▶ We reserve the right to make unannounced technical changes in the course of our continual product improvement process. To charge the POWER PACK 1800 the POWER SUPPLY PD21 with the appropriate country version is necessary. Fig. 03: POWER PACK 1800 Important Features •... -
Page 7: Dimensions
For charging the must be used POWER PACK 1800 PD21 POWER SUPPLY For charging the POWER PACK 1800 must be used with a PD21 POWER SUPPLY or a power Warning: supply with compatible connections and identical technical specifications. For charging the... - Page 8 Connection Connection As standard the POWER PACK 1300 is charged as needed with the PD21 POWER SUPPLY As standard the POWER PACK 1800 is charged as needed with the PD21 POWER SUPPLY Fig. 06: Overview of charging Fig. 06: Overview of charging...
-
Page 9: Operation
(POWER PACK 1800 and PD21 POWER SUPPLY) by an authorized technician or producer. • Do not set up the POWER PACK 1800 in bath- or shower rooms. The battery and charger are not splash proof. • Only recharge the POWER PACK 1800 at the temperatures given below: Charging temperature: from +10°C to + 40°C... -
Page 10: Commissioning
The POWER PACK 1800 must be charged. Deep-discharge protection The switch-off voltage of the POWER PACK 1800 is ≤ 22 V. If the actual voltage falls below this level, the POWER PACK 1800 is disconnected from the system. If the battery voltage rises back up over the switch-off level, then it will switch on again. -
Page 11: Optical Charge Level Indicator
Optical charge level indicator Red LED: If the charger is connected correctly, the red LED flashes and the POWER PACK 1800 charges. If the LED does not light up, check the connections. There may be a disconnection or malfunction. Green LED: The green LED switches on when the POWER PACK 1800 is charged. -
Page 12: Troubleshooting
Handset or drive system Contact your supplier/ defective dealer Handset does not operate or chair / sofa does not function POWER PACK 1800 is Charge the POWER discharged PACK 1800 The unit’s fuse may have Contact your supplier/ been triggered... -
Page 13: Eu Declaration Of Conformity
• EN 61000-3-2:2014 • EN 55014-2:1997/A1:2001/A2:2008 • EN 61000-3-3:2013 • EN 61000-3-2:2014 • EN 62133:2013 (POWER PACK 1800) • EN 61000-3-3:2013 • EN 62133:2013 (POWER PACK 1800) This declaration of conformity is no longer valid if Konstruktive Änderungen, die Auswirkungen auf die...
