P o w e r S u p p l y M o d u l e V 1 . 0
( D G P 2 - P S 1 7 )
I n s t r u c t i o n s
DGP2PS17-EI01
I
N T R O D U C T I O N
The Power Supply Module (DGP2-PS17) is a fully supervised 1.7A switching
power supply that is connected to the communication network of the Digiplex
(DGP-48) or DigiplexNE (DGP-NE96) control panel.
I
N S T A L L A T I O N
The DGP2-PS17 is connected to the control panel's communication
network in a star and/or daisy chain configuration. This 4-wire
communication network provides power and two-way communication
between the control panel and all modules connected to it. Connect the four
terminals labeled red, black, green and yellow of the DGP2-PS17 to the
corresponding terminals on the control panel as shown in Figure 1 (refer to
reverse side). Connect the 5A PGM output of the DGP2-PS17 as shown in
Figure 1, Inset 2 (refer to reverse side).
A
O
U X I L I A R Y
U T P U T
The DGP2-PS17's auxiliary output provides up to 12Vdc. Connect devices
to the auxiliary terminals as shown in Figure 1 (refer to reverse side). A
fuseless circuit protects the auxiliary output against current overload and
autimatically shuts down if the current exceeds 1.1A.
P
M
R O G R A M M I N G
E T H O D
To program the DGP2-PS17, you must enter the "Module Programming
Mode" using any keypad in the system:
1) Press and hold the [0] key.
2) Key in the [
INSTALLER CODE
3) Key in section [953] (DGP-48) / [4003] (DGP-NE96).
4) Key in the DGP2-PS17's 8-digit [
5) Key in the 3-digit [
] you wish to program.
SECTION
6) Turn the desired option ON/OFF or key in the required data.
Please note that the serial number is located on the DGP2-PS17's PC
board. The DGP2-PS17 can also be programmed using the control panel's
Module Broadcast feature as well as through the WinLoad Software (V2.0
or higher). Refer to the Digiplex or DigiplexNE Reference & Installation
Manual for more information on the Module Broadcast feature and to
WinLoad's Online Help for information on programming with WinLoad.
T a m p e r R e c o g n i t i o n
The DGP2-PS17 does not come equipped with a tamper switch. If your
installation requires tamper recognition, enable this feature and connect a
tamper switch as shown in Figure 1, Inset 1 (refer to reverse side). When a
tamper is detected on the module, it will send a tamper report to the control
panel via the communication network. Default: Option [1] is OFF.
B a t t e r y C h a r g i n g C u r r e n t
Turning option [2] ON will set the battery charging current at 700mA.
Turning option [2] OFF will set the battery charging current at 350mA. A
battery charging current of 350mA will require more time to charge the
battery compared to 700mA but will consume less power from the module
itself. Default: Option [2] is OFF.
].
].
SERIAL NUMBER
S e c t i o n [ 0 0 1 ] - O p t i o n [ 1 ]
S e c t i o n [ 0 0 1 ] - O p t i o n [ 2 ]
P G M D e a c t i v a t i o n O p t i o n
When the PGM Activation Event occurs, this option determines when the
PGM will return to its normal state (deactivate). When option [3] is ON, the
PGM will deactivate when the PGM Timer programmed in section [003] has
elapsed. When option [3] is OFF, the PGM will deactivate when the PGM
Deactivation Event programmed in sections [008] to [011] occurs.
Default: Option [3] is OFF.
P G M B a s e T i m e S e l e c t i o n
If the PGM Deactivation Option (section [001] option [3]) is set to follow the
PGM Timer, you must define whether the PGM Timer programmed in
section [003] is in minutes or seconds. If option [4] is ON, the PGM Timer
will be in minutes. If option [4] is OFF, the PGM Timer will be in seconds.
Default: Option [4] is OFF.
P G M T i m e r
If the PGM Deactivation Option (section [001] option [3]) is set to follow the
PGM Timer, the value programmed in section [003] represents how long
the PGM will remain in its opposite state after being activated. To program
the timer, enter a 3-digit decimal value (001-255) into section [003], where
this value is multiplied by the PGM Base Time Selection (section [001]
option [4]) of 1 second or 1 minute. Default: 005.
P G M A c t i v a t i o n E v e n t
The PGM Activation Event determines which event will activate the DGP2-
PS17's on-board PGM output. The Event Group specifies the event, the
Feature Group identifies the source, and the Start # and End # sets the
range within the Feature Group. Use the PGM Programming Table in the
Digiplex/DigiplexNE Modules Programming Guide to program the DGP2-
PS17 PGM Activation Event. Enter the sections that correspond to the
Event Group, Feature Group, Start # and End # of the PGM and enter the
required data.
Event Group
Feature Group
PGM
[004]
Only Event Groups 000 to 055 can be used to program the
DGP2-PS17's PGM Activation Event.
P G M D e a c t i v a t i o n E v e n t
If the PGM Deactivation Option is set to follow the PGM Deactivation Event
(Section [001] option [3]), the PGM will return to its normal state when the
event programmed in sections [008] to [011] occurs. The Event Group
specifies the event, the Feature Group identifies the source, and the Start #
and End # sets the range within the Feature Group. Use the PGM
Programming Table in the Digiplex/DigiplexNE Modules Programming
Guide to program the DGP2-PS17 PGM Deactivation Event. Enter the
sections that correspond to the Event Group, Feature Group, Start # and
End # of the PGM and enter the required data.
Event Group
Feature Group
PGM
[008]
Only Event Groups 000 to 055 can be used to program the
DGP2-PS17's PGM Deactivation Event.
S e c t i o n [ 0 0 1 ] - O p t i o n [ 3 ]
S e c t i o n [ 0 0 1 ] - O p t i o n [ 4 ]
S e c t i o n [ 0 0 3 ]
S e c t i o n s [ 0 0 4 ] t o [ 0 0 7 ]
Start #
[005]
[006]
S e c t i o n s [ 0 0 8 ] t o [ 0 1 1 ]
Start #
[009]
[010]
End #
[007]
End #
[011]
