  • Page 5: Omnitrack Installation And Programming Instructions

    Programming Instructions Overview The OmniTrack was developed to track and record the use of items that reside outside as well as inside the Omnicell cabinet. Because the OmniTrack panel can be added to any cabinet, it is an ideal solution when space limitations prohibit the placement of additional storage racks.
  • Page 6 Note: To install the OmniTrack directly above the PC box check the wireway for a 10 pin or a 14 pin connector. If there is a 10 pin connector, use the standard connector. If there is only a 14 pin connector, use the 14-pin cable that came in the OmniTrack kit.

  • Page 7: Reassembling The Omnitrack

    OmniTrack Installation and Programming Instructions 1-3 Reassembling the OmniTrack 5. Secure the OmniTrack in place, using the screws provided with the kit. Use a Phillips head screwdriver. Figure 1-3. Secure the OmniTrack with the screws provided. Note: If possible, use all eight screws provided; otherwise, use at least four screws in the top or bottom, whichever is more accessible.
  • Page 8 Wires must be connected and not rearranged. Note the orientation of PCBA within the extrusion. 3. Connect the “controller to SPC” (part # 42-7015) cable to the controller, or when installing the OmniTrack directly above the PC Box, connect the flex connector (part # 42-31230). OmniTrack Installation Guide/67-2055 Rev A...

  • Page 9: Programming The Omnitrack

    OmniTrack: Set Programming Mode 1. Power on the cabinet. 2. Set the OmniTrack into programming mode by pressing and holding down the upper left Return Item button for approximately ten seconds until the bottom row LEDs light up. Figure 1-8.

  • Page 10: Zone Address

    = Zone 6 (2+4) = Zone 15 (1+2+4+8) If the OmniTrack is being used for off-Omni items or for SecureTrack items, set the zone address to Zone 9 or any other appropriate auxilliary/imaginary zone. If the OmniTrack is being used for pharmacy items with a refrigerator either on or off the OmniSupplier, set the zone address to the zone in which the OmniTrack is physically located.

  • Page 11: Host Zone Address

    OmniTrack is physically located. SecureTrack Association If the OmniTrack is being used to run a SecureTrack, turn on the first item button from the right side of Row Two of the OmniTrack. Figure 1-12.

  • Page 12: Switchpanel Bin Type

    The OmniTrack can be addressed like a switchpanel with button numbers from 0-31 (one zone = five switchpanels each having eight item buttons); or like a supply drawer with button numbers from 40 - 199. These two types of addressing make it possible to use the OmniTrack in any zone with any configuration.

  • Page 13: Exit Programming Mode

    = button number range 136-167 NOT VALID = button number range 168-199 NOT VALID Exit Programming Mode Press any of the items in the bottom row (row four) of the OmniTrack. This will turn OFF all of the LEDs and exit programming mode. Figure 1-15.
  • Page 14 1-10 OmniTrack Installation and Programming Instructions Configuring the OmniSupplier Software Supply Drawer Addressing Figure 1-16. Figure 1-17. OmniTrack Installation Guide/67-2055 Rev A © 2009 Omnicell, Inc.

  • Page 15: Documentation Feedback

    Documentation Feedback This document is designed to provide relevant technical information to those responsible for the implementation, service, and support of Omnicell products. The Documentation team needs your input, so we can continue to improve our publications. Sending Comments to the Technical Documentation Team Did this document meet your needs? If so, please let us know what we’re doing right.
