Smarty Pear Leo's Loo Too Quick Reference Manual

Drum May Have Shifted

The drum may have shifted during shipping. To make sure it
is seated properly before set up, please lift the cover off to
inspect. Drum should be seated evenly in the gear track and
the spindle in the holder in the rear of unit.
Detach hood.
Drum should be seated evenly in
the gear track and the spindle in
the holder in the rear of unit
®
Remove drum from base if
necessary.
Replace cover then begin setup
using your Quick Start Guide
included.

Emptying the Waste Drawer

1 2
When the waste drawer is full, the POWER button light will
turn red and blink slowly. The machine will stop rotating.
Press the POWER button for 2 seconds to power
off, then pull out the drawer.
Remove and replace the waste drawer liner bag
and top off litter in the drum.
Reinsert drawer and short press the POWER
button for 2 seconds to restart.

Cleaning Your Loo

Detach hood and then remove the drum from the
base.
Vacuum base and wipe with cleaning solution and
cloth. Do NOT use water on the base as it will
damage electronics.
Empty old litter from drum and then wash out with
soap and water. Let dry thoroughly.
Return drum to unit, install cover and fill
with fresh clay clumping litter.
3
