MÖBLER Sansa Care And Handling Instructions

Care and handling instructions of electrically height adjustable tables
Designation: Sansa

General description

The table is electrically height adjustable. It is controlled with buttons at the front edge of the table. The
user can create their working position. A regular alternation between sitting and standing strengthens
muscles and helps to prevent strain injuries.
Below you can see how to use your electric height adjustable table in a proper way which ensures good
ergonomics and safety. Note that the table may only be used in office environment, and that minor people
is not allowed to handle the table without adult supervision.
The table stand may only be used with tabletops approved by SA Möbler AB.
Table top maximum height above the floor:
Table top minimum height above the floor:
Maximum load (spread load): 80 kg.

Mounting

Installation is performed according to the enclosed installation instruction.

Installation

* Ensure the free movement of space around the table sides of at least 50 mm.
* Ensure that there are no objects above the table that can affect / be affected by the table upward
movements. Risk of crushing injury!
* Ensure that there are no objects under the table which could affect / be affected by the table's downward
movement. Risk of crushing injury!
* Adjust the table horizontally by using the adjustment screws and a spirit-level. Maximum adjustment
range is 10 mm.
* Connect the table power connection in a 220V socket. NOTE! Make sure the cord allows full movement
up and down with respect to both the length and the movement pattern. Use an extension cord if
necessary.
* Make sure that something / someone not is trapped in the leg connection at the table foot.
* When assembling the table, check that all cables are connected properly. Then press the down-button. All
legs run in the bottom position. To calibrate the table shall the down-button be hold for five seconds until
the table makes a "kneeling". Then run the table in the top position and hold the up-button for five
seconds. Now, the table can be driven up and down.
Calibration of the desk should be done periodically.
Operation of the table (to adjust the height of the table):
1. Ensure that no person or object is in the tables operating space.
2. If the tabletop is desired higher, hold the up-button until the desired height is reached.
3. If the tabletop is desired lower, hold the down-button until the desired height is reached.
4. If the table does not stop even though the buttons are not pressed, pull out the plug!
SA Möbler AB
Kyrkefallavägen 3
SE-543 34 Tibro
Sweden
Telephone
+46(0)504-198 00
Telefax
+46(0)504-150 65
1210 mm (1270 mm)
710 mm (620 mm)
