S E M I P R I V A C Y F E N C I N G I N S T A L L G U I D E
2 part domical cover
HF-SEMIP-DC
Order Code:
150mm
English style cap
Order Code:
HF-SEMIP-EC
157mm
Slimline tapered cap
Order Code:
HF-SEMIP-STC
107mm
— hamptons fencing
TECH SPECS
• 2 part domical cover – suits 102x102mm post
• Can fitted after post and panels installed.
2 parts neatly clip together
• White UV stabilised PVC with protective titanium
dioxide additives
• Provides a stylish post finish
TECH SPECS
• Press on external fit cap
• 'English' style cap with tapered top provides a
decorative finish
• White UV stabilised PVC with protective titanium
dioxide additives
• Use silicone for long term binding
TECH SPECS
• Press on external fit cap
• Slimline tapered cap for minimalist post finishing
• White UV stabilised PVC with protective titanium
dioxide additives
• Use silicone for long term binding
89
Advertisement
Table of Contents
Summary of Contents for PVC HF-SEMIP-DC
- Page 1 • 2 part domical cover – suits 102x102mm post • Can fitted after post and panels installed. 150mm 2 parts neatly clip together • White UV stabilised PVC with protective titanium dioxide additives • Provides a stylish post finish English style cap...
- Page 2 hamptons fencing — S E M I P R I V A C Y F E N C I N G I N S T A L L G U I D E 2450mm 56.9mm 50.8 x 88.9mm Top Rail 50.8 x 88.9mm Mid Rail 38.1 x 38.1mm Picket 101.6 x 101.6 Post...
- Page 3 — hamptons fencing S E M I P R I V A C Y F E N C I N G I N S T A L L G U I D E 2450mm C of posts 2450mm C of posts Standard post spacing Mark post positions with spray paint or appropriate markers...
- Page 4 hamptons fencing — S E M I P R I V A C Y F E N C I N G I N S T A L L G U I D E THIS SECTION RELATES TO BASE PLATED POSTS Posts are supplied at length for in ground installation.
- Page 5 — hamptons fencing S E M I P R I V A C Y F E N C I N G I N S T A L L G U I D E Install short pickets into bottom-rail leaving long pickets for subsequent step. The long pickets are postitioned 6 pickets in from either end. Push mid rail into slot on 1 post then lever into slot on adjacent post.
- Page 6 hamptons fencing — S E M I P R I V A C Y F E N C I N G I N S T A L L G U I D E Install top rail over long pickets guiding pickets into holes on underside of top rail. Insert top rail into one post and then lever into adjacent post. If using custom span lengths secure top rail...
