LVM AERO2GEN Owner's Manual

AERO2GEN OWNERS MANUAL
LVM 212 : 12 Volt LVM224 : 24 Volt

PARTS CHECK LIST

1 : Generator (M6 grub screw fitted)
1 : Tail Tube
1 : Tailfin
1 : Fan Hub Bossed
1 : Fan Clamp Plate
5 : Fan Blades
8 : M4 X 20 Stainless Steel Screws
8 : M4 Stainless Steel Nuts
5 : M4 Stainless Steel Washers
1 : Instruction Leaflet
1 : M5 x 30 Hex. Bolt with Spring Washer
1 : M5 Nyloc Nut
5 : Plastic Hub Retaining Washers
1 : Hub Cover
2 : Male push-fit connectors
2 : Male push-fit connector covers
2 : Female push-fit connectors
2 : Female push-fit connector covers

Guarantee

Thank you for purchasing this product. It has been manufactured to
exacting standards and LVM Products guarantees that should any
defect in materials or workmanship occur within ONE YEAR of the date
of purchase we will repair or replace the defective part free of charge.
Damage caused by misuse, failure to follow instructions, negligence,
and modification or transit damage will not be warranted.
LVM Products will not be liable for any loss of revenue or any
consequential loss or damage to property or persons from any cause
whatsoever.
Retain your purchase invoice, as it will be needed in the event of a
warranty claim.
What is Not Covered –
•
Damage due to lightening
•
Damage due to improper installation
•
Damage due to improper wiring
•
Damage from flying debris causing blade damage.
CE
Aero2gen Performance
5
4
3
2
1
0
0 10 20 30
Wind speed (knots)
Note: Amps output of a 24v
model will be half shown
above
40 50 60
