DOUBLE RING STOOL ASSEMBLY INSTRUCTIONS
Parts List
1
Wrench (1)
2
Allen wrenches (2)
3
Sleeved allen head screws (8)
4
Nuts and bolts (4)
NOTCHED LEG
Step 1: Attach inner support
ring to the stool leg (with notch
at the top and secure it with 2
sleeved-bolts and Allen screws.
Do not tighten all the way
.
5
Machine screws (4)
6
Shims (4)
7
Stool legs (2)
8
Swivel base (1)
Step 2: Slide the other stool leg
over the notched-leg and inner
support ring.
PG.1
MTCPUBSTOOL
9
Stool pad (1)
10 Inner support ring (1)
11 Outer support ring / foot rest (1)
Step 3: Add other 2
sleeved-bolts and Allen screws
to the inner support ring. Do
not tighten all the way.
