Falcon
Product Technical Note
GPS/GNSS Antenna and Receiver
Installation Guidelines
Document version: 1.8
Proprietary Information. This document contains information, which is proprietary to Fibrolan
Ltd. No part of its contents may be used, copied, disclosed or conveyed to a third party in any
manner whatsoever without prior written permission from Fibrolan Ltd.
www.fibrolan.com
Advertisement
Table of Contents
Summary of Contents for FibroLAN Falcon
- Page 1 Installation Guidelines Document version: 1.8 Proprietary Information. This document contains information, which is proprietary to Fibrolan Ltd. No part of its contents may be used, copied, disclosed or conveyed to a third party in any manner whatsoever without prior written permission from Fibrolan Ltd.
- Page 2 GNSS Antenna and Receiver Installation Guidelines Falcon /G models (µFalcon-MX/G, Falcon-MX/G, µFalcon-ST8/G, Falcon-MTS and Falcon-RX/G) include an integrated Global Navigation Satellite System (GNSS) receiver. It is a multi-constellation (GPS, GLONASS, Galileo, Beidou) receiver designed to provide high precision and stable synchronization in Telecom and Enterprise environments.
-
Page 3: General Considerations
• Use professional and adequate accessories for installation. Such may be ordered (optionally) from Fibrolan. • Position the GNSS antenna at a minimum of 1.5m / 5 ft distance from any metallic object and a minimum of 1m / 3 ft distance from any other GNSS antenna •... -
Page 4: Installation Examples
(perhaps none at times) of satellites to track. Figure-2: Examples of antenna installation location In cases where good sky dome exposure cannot be secured, consult Fibrolan for alternatives based of extended holdover and other unique mechanisms available on certain models. Such, will maintain synchronization for a given period even at the absence of adequate satellite signals. -
Page 5: Antenna Selection
G P S / G N S S A n t e n n a I n s t a l l a t i o n G u i d e l i n e s 2 Antenna and transmission system selection It is recommended to obtain the antenna, cable and other accessories from Fibrolan along with the timing device. This will ensure full support and higher performance of the solution. -
Page 6: Lightning Arrestor
If more than a single receiver is connected to the antenna a powered/amplified splitter is installed. Figure-5: Multiple receiver installation with splitter 2.2.1 Cables Fibrolan recommends using 50Ω or 75Ω coax cable for connecting the GNSS antenna to the Falcon GNSS receiver port. •... - Page 7 (typically 0.1dB). 2.2.3 In-Line Amplifier In case the total gain at the Falcon GNSS input drops below 15dB an in-line amplifier is required. For example, Fibrolan’s GNSS antenna model GPANT-4's gain is 28dB, which can be translated to a maximum of 13dB attenuation for the entire transmission system (indoor+ outdoor) without amplification.
- Page 8 3 Power and grounding installation Falcon models can be installed with two load sharing, hot swappable, redundant AC or DC power supplies. µFalcon models are equipped with dual DC feed power supply.
- Page 9 Central-Eastern Europe Fibrolan Ltd. Fibrolan Inc. Fibrolan CEE GmbH. Tel: +972-4-959-1717 Tel: +1-201-843-1626 Tel: +43 2253 21188-0 Fax: +972-4-959-1718 Fax: +1-201-843-1628 Fax: +43 2253 21188-99 info@fibrolan.com us.info@fibrolan.com office@fibrolan.at www.fibrolan.com www.fibrolan.com www.fibrolan.at ©2021 Fibrolan. All Rights Reserved P a g e...
