The Akron Style 3419 Apollo PE (Portable Electric) Monitor is designed to provide efficient trouble-free operation for many years. The
following operating and maintenance instructions are provided to assist in obtaining the best possible performance for this unit.
PRODUCT RATINGS
Maximum Flow:
Maximum Pressure:
PRODUCT WARNINGS
Read and follow the Warning Tag Instructions on the Lock Pin Lanyard.
A
/
turn shut off valve should not be used with the Apollo. If any other type of shut off valve is used,
1
4
it must be opened and closed slowly. Opening and closing a valve too quickly may result in damage to
the Apollo and other equipment, which can result in an injury to the operator or others.
Read and follow the Safety Chain Warning Tag located on the Ground Mount Tag.
Read and follow the vertical Safety Stop Plunger Pin Caution Tag.
Under freezing conditions the monitor must be drained to prevent damage.
Read and follow the Tip Pressure Tag located on the Portable Ground Base.
Read and follow the Set Up Instruction Tag located on Inlet Body.
Incorrect hose layout may cause instability.
Do Not use with an upper deck extension pipe (Style 3405)
STYLE 3419 Apollo™ PE (Portable Electric) Monitor
with Foldaway Legs
OPERATING & MAINTENANCE INSTRUCTIONS
800 GPM (3030 LPM) Dual Inlet Portable Base
1000 GPM (3800 LPM) Single Inlet Portable Base
1250 GPM (4800 LPM) Direct Mount
200 PSI (1380 Kpa, 14 BAR)
122698
Advertisement
Table of Contents
Related Manuals for Akron Brass Apollo 3419
Summary of Contents for Akron Brass Apollo 3419
- Page 1 STYLE 3419 Apollo™ PE (Portable Electric) Monitor with Foldaway Legs OPERATING & MAINTENANCE INSTRUCTIONS The Akron Style 3419 Apollo PE (Portable Electric) Monitor is designed to provide efficient trouble-free operation for many years. The following operating and maintenance instructions are provided to assist in obtaining the best possible performance for this unit. PRODUCT RATINGS Maximum Flow: 800 GPM (3030 LPM) Dual Inlet Portable Base...
- Page 2 Figure 1 Inlet connector Tabs Locking Pins Truck Flange connection ears GENERAL INSTRUCTIONS 1. Installation For On Truck Operation: A. Connect the Apollo PE to the truck mount flange by placing the inlet connector tabs between the truck mount flange connection ears (Figure 1).
- Page 3 2. INSTALLATION FOR GROUND OPERATION: To prepare the Apollo PE for ground based operations perform the following steps: A. Turn control power switch to the “OFF”(down) position. (Figure 2) B. Disconnect vehicle power cable from truck power input connector. (Figure 2) C.
- Page 4 – PAUSE/ RESUME” switch. The monitor will now oscillate between the left and right limits you have set. To adjust the oscillation limits, press and hold the “OSCILLATION START/SET – PAUSE/RESUME” switch upwared when moving in the direction in which you wish to change the limit and release the “OSCILLATION START/SET – PAUSE/RESUME” switch when the new limit is reached.
- Page 5 5. SINGLE INLET PORTABLE BASE. When used with the single inlet portable base, the unit should not be operated at more than 1000 GPM (3800 LPM) with a fog nozzle or the following discharge pressures with straight tips unless the unit is secured in the direct connect flange base on a truck: TIP SIZE 1 3/8”...
- Page 6 Check both the inlet clappers (dual inlet base only) function properly. Lubrication is not normally required in this area. Check that the latch of the safety chain hook engages properly in the chain. If any of the parts do not function properly, contact Akron Brass for repair instructions or return the unit to the Akron Brass Company.
- Page 7 NOTES ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________ ____________________________________________________________________________________...
- Page 8 REvISED: 4/12 WARRANTY AND DISCLAIMER: We warrant Akron Brass products for a period of five (5) years after purchase against defects in materials or workmanship. Akron Brass will repair or replace product which fails to satisfy this warranty. Repair or replacement shall be at the discretion of Akron Brass. Products must be promptly returned to Akron Brass for warranty service.
