OPERATING MANUAL

SPECIFICATIONS

Maximum Capacity . . . . . . . . . . . . . . . . . . . . . 750 Lbs.
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36.2"
Overall Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26.8"
Overall Height. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33.7"
Net Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Lbs.
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . 60.5 Lbs.
Manufactured to comply with the
ASME PASE-2019 Safety Standard
CSEES1KM
•
•
Copyright © Professional Tool Products, 2020
1
CSEES1KM
750 LB.
ENGINE STAND
All rights reserved
03/30/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSEES1KM and is the answer not in the manual?

Questions and answers

Summary of Contents for Cornwell Tools CSEES1KM

  • Page 1 CSEES1KM 750 LB. ENGINE STAND OPERATING MANUAL WARNING INFORMATION PARTS LIST • • SPECIFICATIONS Maximum Capacity ..... 750 Lbs. Overall Length ......36.2"...
  • Page 2 CSEES1KM 750 LB. ENGINE STAND WARNING INFORMATION This is the safety alert symbol. It is used to alert you WARNING: Indicates a hazardous situation WARNING to potential personal injury hazards. Obey all safety which, if not avoided, could result in death messages that follow this symbol to avoid possible or serious injury.
  • Page 3 3. Every stand owner is responsible for keeping the device labels clean and readable. Use a mild soap solution to wash external surfaces of the device. Contact Cornwell Tools for a replacement label if the device's label is not readable.
  • Page 4 CSEES1KM 750 LB. ENGINE STAND WARRANTY COVERAGE Cornwell Quality Tools Company (“Cornwell”) warrants this product against defects in material and workmanship for a period of TWO (2) YEAR from the date of original retail purchase. Subject to the conditions and limitations set forth below, Cornwell will, at its option, either repair or replace any part of the product(s) that proves defective by reason of improper workmanship or materials.
  • Page 5 CSEES1KM 750 LB. ENGINE STAND Item Part Item Part Description Qty. Description Qty. RS75002 3.5" Caster Assembly (incl. #2) RS75005 3.5" Locking Caster Assembly (incl. #2) Bolt (M8) (incl. with #1 and #13) Main Post Back Leg RS75006 Lock Pin (12) Nut (M8) Hand Grip (incl.
