Summary of Contents for TPI SP323
- Page 1 SP323 Smart Temperature Clamp Probe Instruction Manual Scan to download the TPI View app:...
- Page 2 1. Install the TPI View App on your smart device. 2. Press and hold the SP323 on/off key for approximately 2 seconds to turn the smart probe on. An orange LED will blink indicating the SP323 is ready to be paired.
- Page 3 AUTO POWER OFF If the SP323 is not connected to a smart device for more than 8 minutes it will auto power off. When connected to a smart device the auto power off is disabled. Auto power off is also disabled during data logging.
- Page 4 7. Once logging has been stopped or ended, logged data can be retrieved using the View app. GENERAL MAINTENANCE Housing: The SP323 can be wiped down with a damp lint free cloth. Do not use any cleaning agents including solvent or soap.
- Page 5 SPECIFICATIONS -40⁰F to 185⁰F (-40⁰C to 85⁰C) Temperature Range Clamp Pipe Size 1/4 inch to 1 1/2 inch (6mm to 38mm) 0.1⁰F / 0.1⁰C Resolution 32⁰F to 185⁰F (0⁰C to 85⁰C) = +/- 0.9⁰F (+/- 0.5⁰C) Accuracy <32⁰F (<0⁰C) = +/-1.8⁰F (+/-1.0⁰C) Data Logging 10,000 readings in 1 sec to 59 min 59 sec intervals Battery Life...
- Page 6 SP323 STANDARD ACCESSORIES A.323SP – Soft Pouch for SP323 SP670 OPTIONAL ACCESSORIES A931 – Carrying case capable of holding (2) SP670 pressure probes, (2) SP323 temperature clamps, and (2) A597 humidity probes WARRANTY This product is warranted to the purchaser against defects in material and workmanship for three years from the date of purchase.
- Page 7 NOTES...
- Page 8 Test Products International, Inc. 9615 SW Allen Blvd., Ste. 104 Beaverton, OR 97005 Tel: 503-520-9197 www.testproductsintl.com Test Products International, Ltd. 342 Bronte Road South, Unit #6 Milton Ontario Canada L9T 5B7 Tel: 905-693-8558 www.tpicanada.com Test Products International Europe Ltd. Rutherford Way Industrial Estate Rutherford Way Manor Royal Crawley...
