Summary of Contents for GRDIAN ARC-4K
- Page 1 ARC-4K USER MANUAL grdian.com/product-support...
-
Page 2: Table Of Contents
Contents TABLE OF CONTENTS Safety Information......................1 Overview........................2-3 What’s in the Box.......................4 Recommended Accessories..................5 Mounting the ARC-4K....................6 Routing the Cables......................7 Gesture Control......................8 Camera Settings......................9 Menu Settings.....................10-12 Playback Menu......................12 File Structure......................13 HIT GPS Player......................14 Troubleshooting.......................15 Customer Support....................16... -
Page 3: Safety Information
It is important to keep ARC-4K and its power adapter in a well ventilated and shaded area when in use. -
Page 4: Overview
Overview | Page 2 Overview Camera Angle Power Indicator Gesture Control Video Resolution Recording Time G-Sensor Time Date Recording Screen Brightness Rear Camera Indicator Gesture Control Indicator File Lock Manually locks current video recording to prevent overwriting. Media Library On/Off On-demand playback Driver ID of your recorded... - Page 5 Overview | Page 3 Overview Speaker Screen On/Off Camera Lens Magnetic Mount Extendable Rear Camera Input Memory Card Slot mini USB Power Input GPS Adapter Input...
-
Page 6: What's In The Box
What’s in the Box | Page 4 What’s in the Box ARC-4K Rear Camera (Weatherproof) Rear camera may not be included. Sold separately. Adhesive Magnet Mount Trim Tool Clear Film Mount Protector for Adhesive Magent Mount (x1) 4 Pin Rear Camera Cable... -
Page 7: Recommended Accessories
The Charger Plus Hardwire Kit regu- lates the flow of power and protects your vehicle’s battery from drainage. Safely maintain power to the ARC-4K when your vehicle is turned off. It features a built-in timer and voltage protection setting. Available for purchase at grdian.com/shop. -
Page 8: Mounting The Arc-4K
Press down firmly to securely attach the mount to the Clear Film. 4. Securely fasten and lock the ARC-4K on top of the Adhesive Magnet Mount by sliding the device into place. Slightly pull away the ARC-4K to make sure it is locked in place and not just attached magnetically. -
Page 9: Routing The Cables
1. Locate a power source to plug the provided mini USB charging cable into. 3. Plug the mini USB into the ARC-4K and route the cable inside the headliner and down the A Pillar. Tuck the cable into the rubber weather guard to hide wiring. -
Page 10: Gesture Control
Gesture Control | Page 8 Gesture Control Adjust Camera Angle Adjust Screen Brightness Move up and down to Move up and down to adjust the camera angle of adjust screen brightness. your front or rear camera. Switch Camera Views Swipe left or right in the middle of the screen to switch from front, rear or split screen (both front and rear). -
Page 11: Camera Settings
Camera Settings | Page 9 Camera Settings To access your camera’s settings, press the setting icon on the main screen. This will bring you a list of settings you are able to control. For detailed description of each settings, visit page 10. Camera Settings Swipe up or down to view your camera settings. -
Page 12: Menu Settings
Modes: Menu Settings | Page 10 Menu Settings Back Goes back to the main screen. Resolution Change your video resolution to 1080p, 2K, or 4K. Rear Camera Flip Flips the rear camera horizontally. Enables High Dynamic Range, for broader spectrum of colors and contrasts. Loop Recording Change your loop recording length of each file to 1, 3, or 5 minutes. - Page 13 Modes: Menu Settings | Page 11 Menu Settings Time Zone Choose your timezone here. Date Stamp Turns ON/OFF date stamp display on videos. Driver ID Enable to create a custom driver ID stamp on your videos. Speed Unit Change your speed unit to either MPH or KMH. Startup Soud Turns ON/OFF startup sound.
-
Page 14: Playback Menu
Menu Settings, Playback Menu | Page 12 Menu Settings Default Settings Restores system to factory settings. Version System version info. Playback Menu The Playback Menu is located on the main screen. Press to access your recorded content for on-demand playback. Choose Which Content to View Choose to view your videos, photos, or locked files. -
Page 15: File Structure
File Structure | Page 13 File Structure The ARC-4K will automatically format your memory card for optimal reading and writing. When viewing files on your computer, you will be presented with 3 folders containing your recorded content and a free-to-use software for easy playback. -
Page 16: Hit Gps Player
HIT GPS Player | Page 14 HIT GPS Player HIT GPS Player is a free-to-use video player that comes with the ARC-4K. Simply load videos onto the player to view various information such as speed, route history and more. Software can be found on your memory card once formatted on device. -
Page 17: Troubleshooting
Please use the SanDisk Max Endurance memory card. Is the ARC-4K suppose to get this hot? It is normal for the ARC-4K to get hot when left in direct sunlight. This will not affect its performance. Do I need a hardwire kit to use the Parking Mode Feature? Yes, it is generally recommended to use a hardwire kit to use the Parking Mode Feature. -
Page 18: Customer Support
Customer Support | Page 16 CUSTOMER SUPPORT SUPPORT SUPPORT GRDIAN is dedicated to providing the best possible services and products. To reach out to our support team, please visit: grdian.com/contact-us MESSAGING US We make ourselves available to you on different social media platforms. You can reach out to us on Twitter, Facebook, and Instagram. - Page 20 Connect With Us Facebook facebook.com/teamgrdian Instagram @teamgrdian Twitter @teamgrdian TikTok @teamgrdian WWW.GRDIAN.COM...
