IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

Tools Needed

Helpline

If you have any problems with this product or
require any replacement fittings pl e ase contact
Customer Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part o r fully completed unless the item is
found to be faulty. Should you need to return the unassembled product, please repack in the original packaging.

IMPORTANT

• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
• Not suitable for use in bathrooms.

PRODUCT INFORMATION

• Made from MDF with painted finish.
• Made in China.

CARE INSTRUCTIONS

• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration
or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if
necessary.
855468 ASHTON GLAZED SIDE
ASSEMBLY INSTRUCTIONS.
Page 1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASHTON GLAZED SIDE 855468 and is the answer not in the manual?

Questions and answers

Summary of Contents for Next ASHTON GLAZED SIDE 855468

  • Page 1 855468 ASHTON GLAZED SIDE ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings pl e ase contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part o r fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS PARTS (1) Top Panel x 1 (2) Side Panel (L&R) x 2 (3) Bottom Panel x 1 (4) Back Panel x 1 (5) Back Panel x 1 (6) Back Panel x 1 (8) Back Lower Rail x 1 (7) Shelf Panel x 2 (9) Front Lower Rail x 1 (10) Door Panel x 1 STEP ONE...
  • Page 3 STEP THREE 1. Insert 7 x cambolts (A) and 1 x wooden dowels (C) into side panel 2-R. 2. Attach side panel 2-R to the assembled unit. 3. Insert 7 x camlocks (B) into 2 x shelf panels 7, back lower rail 8 and front lower rail 9. Ensure the arrow indicator is pointing towards the panel edge before tightening with a screwdriver.
  • Page 4 STEP SIX 1. Attach back panel 4, back panel 5 and back panel 6 to the assembled unit with 23 x screws (D) and tighten. STEP SEVEN 1. Attach 2 x hinges (H) to door panel 10 with 4 x screws (J) and tighten.
  • Page 5 SCREW NB : Wall fixings are not included-please source suitable fixings for your wall type. If in doubt please consult a qualified trades person. Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 5 of 5...
