- Page 1 A division of Enphase Energy, Inc. PEDESTAL INSTALLATION GUIDE TESLA ® WALL CONNECTOR & CLIPPERCREEK HCS...
- Page 2 This user’s manual includes the latest information at the time of printing. Enphase Energy, Inc. reserves the right to make changes to this product without further notice. Changes or modifications to this product by other than an authorized service facility may void the product warranty.
-
Page 3: Table Of Contents
PEDESTAL INSTALLATION GUIDE TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ................4 INSTALLATION CONFIGURATIONS AND TOOLS REQUIRED ........ 4 INSTALLATION REQUIREMENTS ................8-9 PACKING LISTS ........................10 OPTIONAL ORDERABLE ITEMS ................... 11 INSTALLATION CHAPTERS: MAIN PEDESTAL ......................................12-14 TESLA® WALL CONNECTOR ................................15-21 CLIPPERCREEK HCS .................................... -
Page 4: Important Safety Instructions
PEDESTAL INSTALLATION GUIDE IMPORTANT SAFETY INSTRUCTIONS BEFORE YOU BEGIN: Read these instructions completely, including the Safety Instructions. If you have questions about the use of this product, contact your Service Representative. NOTE TO THE INSTALLER: Be sure to leave these instructions with the user. NOTE TO THE USER: Keep these instructions for further reference. - Page 5 PEDESTAL INSTALLATION GUIDE Single TESLA® Wall Connector, Single ClipperCreek HCS TESLA® Wall Connector and ClipperCreek HCS Combo NOTE TO INSTALLER REGARDING THE COMBO CONFIGURATIONS: FOR EASIEST ASSEMBLY INSTALL TESLA® Wall Connector PRIOR to the ClipperCreek HCS Dual TESLA® Wall Connector, Dual ClipperCreek HCS Page 5...
- Page 6 PEDESTAL INSTALLATION GUIDE TESLA® WALL CONNECTOR SINGLE AND DUAL MOUNT CONFIGURATION DIMENSIONS Page 6...
- Page 7 PEDESTAL INSTALLATION GUIDE CLIPPERCREEK HCS SINGLE AND DUAL MOUNT CONFIGURATION DIMENSIONS Page 7...
-
Page 8: Installation Requirements
One (1) TESLA® Wall Connector (EVSE). NOTE: The TESLA® Wall Connector comes with a Cable Organizer for Wall Mounting • Purposes only. This cable organizer is not utilized on the Pedestal Mounting System. One (1) ClipperCreek TESLA® EVSE Pedestal Kit, ClipperCreek part number 0300-00-022. • One (1) dedicated 208 or 240 VAC branch circuits. - Page 9 PEDESTAL INSTALLATION GUIDE Four (4) Anchor Bolts with Nuts and Washers • • REQUIRED EQUIPMENT FOR A SINGLE-MOUNT PEDESTAL WITH ONE CLIPPERCREEK HCS CHARGING STATION (ONE EVSE PER PEDESTAL): One (1) ClipperCreek HCS EVSE Pedestal Kit, ClipperCreek part number 0300-00-019. •...
-
Page 10: Packing Lists
PEDESTAL INSTALLATION GUIDE PACKING LISTS 0300-00-022 TESLA® PEDESTAL KIT, STANDARD 4 FOOT, SINGLE-MOUNT PART NUMBER DESCRIPTION 1003-0043 Pedestal Metalwork, Cap with Front and Rear Flange NOTE: this item may already be attached to the top of the pedestal. 1003-0023 Pedestal Metalwork, Base Cover 1003-0035 Pedestal Metalwork, 4-Foot Post 1003-0037... -
Page 11: Optional Orderable Items
PEDESTAL INSTALLATION GUIDE OPTIONAL ORDERABLE ITEMS 0300-00-021 TESLA® WALL CONNECTOR DUAL-MOUNT KIT FOR STANDARD 4 FOOT PEDESTAL (OPTIONAL) PART NUMBER DESCRIPTION 1003-0042 Pedestal Metalwork, TESLA® Wall Connector Mounting Plate 4000-0011 Machine Screw, Tapered Flat Head, 1/4-20 Size, 3/4” Length, T27 Torx 4001-0008 Hex Nut, 18-8 Stainless Steel, 5/16”-18 Thread, 1/2”... -
Page 12: Main Pedestal
PEDESTAL INSTALLATION GUIDE: MAIN PEDESTAL MAIN PEDESTAL SETUP – BOTH HCS & TESLA® INSTALLATIONS REQUIRE THESE STEPS 1. CONCRETE PAD REQUIREMENTS The location, dimensions, and composition of the concrete pad underlying the pedestal should always adhere to local building codes. The following dimensions are minimum recommended values. - Page 13 PEDESTAL INSTALLATION GUIDE: MAIN PEDESTAL For the Standard 10” Square Pattern: Arrange four (4) 1/2” or 3/8” anchor bolts in a 10” square pattern. This placement corresponds to the corner cutouts in the pedestal base. For the Alternate 5.25” x 11.1” Rectangular Pattern: Arrange four (4) 3/8”...
- Page 14 PEDESTAL INSTALLATION GUIDE: MAIN PEDESTAL 4. INSTALL THE PEDESTAL BASE COVER A two-piece pedestal base cover set is included in the pedestal kit. The purpose of the pedestal base cover is to beautify the installation and to protect against injury from protruding anchor bolts. •...
-
Page 15: Tesla® Wall Connector
PEDESTAL INSTALLATION GUIDE: TESLA® WALL CONNECTOR TESLA® WALL CONNECTOR INSTALLATION REQUIRES THESE STEPS THESE STEPS ARE TO BE COMPLETED AFTER THE MAIN PEDESTAL INSTALLATION FOR THE TESLA® WALL CONNECTOR CONFIGURATIONS ONLY. REPEAT EACH STEP FOR DUAL-MOUNTED CONFIGURATIONS ON THE OPPOSITE SIDE OF THE PEDESTAL: 1. - Page 16 PEDESTAL INSTALLATION GUIDE: TESLA® WALL CONNECTOR 3. PREPARE THE TESLA® WALL CONNECTOR FOR PEDESTAL MOUNTING With the TESLA® Mounting Bracket in place, the pedestal is now ready for a TESLA® Wall Connector to be mounted. For Dual-Mount Installations, repeat the steps below for the opposite side. Release the front cover Using a Torx T20 driver, Disconnect the ground wire...
- Page 17 PEDESTAL INSTALLATION GUIDE: TESLA® WALL CONNECTOR 4. MOUNT THE TESLA® WALL CONNECTOR TO THE PEDESTAL • The TESLA® Wall Connector has provisions for 1” (25 mm) conduit. • Align the TESLA® Wall Connector over the Mounting Bracket. • Attach the grounding wire. Fasten the TESLA®...
- Page 18 PEDESTAL INSTALLATION GUIDE: TESLA® WALL CONNECTOR 5. CONNECT THE WIRING NOTE: For most branch circuits of 100A, use 3 AWG (26.7 mm2), 75°C (167°F) copper wire. For installations less than 100A, use conductors that are sized according to local electrical codes. WARNING: Do not connect service wiring until you have read and fully understand the pages in the document titled “Service Wiring.”...
- Page 19 PEDESTAL INSTALLATION GUIDE: TESLA® WALL CONNECTOR 6. CONFIRM A SUCCESSFUL INSTALLATION Set the dip switches, located in the lower right-hand portion of the connector, to the test setting shown here. Use a pointed object such • as a pen. While holding the front cover near the TESLA® Wall Connector, re-connect the Ribbon Cable be aligning the cable, as shown. •...
- Page 20 PEDESTAL INSTALLATION GUIDE: TESLA® WALL CONNECTOR 7. SET OPERATING CURRENT • Turn off the power. WARNING: RISK OF ELECTRIC SHOCK! Before continuing, use a volt meter to confirm that NO POWER is available at the service wiring or terminals. • Open the front cover and hold it with one hand while completing the next step.
- Page 21 PEDESTAL INSTALLATION GUIDE: TESLA® WALL CONNECTOR 8. RE-INSTALL THE PEDESTAL POST CAP 9. INSTALL THE COVER PLATE • The pedestal cap is provided to cover the • The cover plate is provided to cover the electrical opening to protect the conductors and inner access hole for Single-Mount Pedestals only.
-
Page 22: Clippercreek Hcs
PEDESTAL INSTALLATION GUIDE: CLIPPERCREEK HCS CLIPPERCREEK HCS INSTALLATION REQUIRES THESE STEPS THESE STEPS ARE TO BE COMPLETED AFTER THE MAIN PEDESTAL INSTALLATION FOR THE CLIPPERCREEK HCS CONFIGURATIONS ONLY. REPEAT EACH STEP FOR DUAL-MOUNTED CONFIGURATIONS ON THE OPPOSITE SIDE OF THE PEDESTAL: 1. - Page 23 PEDESTAL INSTALLATION GUIDE: CLIPPERCREEK HCS 3. MOUNTING A SINGLE CHARGING STATION TO THE PEDESTAL With the mounting plate in place, the pedestal is now ready for a single charging station to be mounted. Place a 1/4” Neoprene-bonded sealing washer around the shaft of each of the two (2) 1/4-20 •...
- Page 24 PEDESTAL INSTALLATION GUIDE: CLIPPERCREEK HCS FOR DUAL-MOUNT INSTALLATIONS: Dual-Mount installations utilize a replacement post cap provided in the Du- al-Mount Kit. This post cap lacks a flange at the rear. • Place the post cap onto the top of the pedestal. •...
- Page 25 PEDESTAL INSTALLATION GUIDE: CLIPPERCREEK HCS 8. MOUNTING TWO CLIPPERCREEK HCS EVSE’S TO THE PEDESTAL For an installation with two charging stations affixed to the same post, repeat the previous steps 7 through 11 for the opposite side. 9. WRAP AND STOW THE VEHICLE CONNECTOR Loosely wrap the cable around the HCS.
-
Page 26: Customer Support
PEDESTAL INSTALLATION GUIDE CUSTOMER SUPPORT Call your ClipperCreek Service Representative at any time, 24 hours a day, at the number below. PLEASE HAVE THE MODEL NUMBER AND SERIAL NUMBER AVAILABLE WHEN YOU CALL. This information is printed on the label. If your call is made after business hours or on weekends, please leave your name, telephone number, the unit serial number, and a brief description of the problem. -
Page 27: Warranty Information
Enphase or an authorized Enphase representative or dealer has been advised of the possibility of such damages or of any claim by any other party. - Page 28 ClipperCreek A division of Enphase Energy, Inc. www.clippercreek.com 877-694-4194...
