MANUAL FOR WIFI 5 IN 1 LED STRIP CONTROLLER
1. Features
With wireless func�onality that can be easily controlled over WIFI or 4G via the MiBoxer app, this controller
offers up some of the most advanced PWM control technology in addi�on to memory func�on, enabling you
to easily customise your ligh�ng setup to your exact liking quickly and conveniently.
16 million colours to
choose from
Colour temperature
adjustable
Mul�ple brightness
levels
2.4G Wireless
transmission technology
WIFI wireless control
support long-range control
Timer se�ngs, including
countdown
SKU: MS-FYL5
Remote control distance
of 30m
Smartphone app control
Third party voice app
control
Family sharing
Customisable ligh�ng
scenes
Advertisement
Table of Contents
Summary of Contents for Mirrorstone MS-FYL5
- Page 1 MANUAL FOR WIFI 5 IN 1 LED STRIP CONTROLLER SKU: MS-FYL5 1. Features With wireless func�onality that can be easily controlled over WIFI or 4G via the MiBoxer app, this controller offers up some of the most advanced PWM control technology in addi�on to memory func�on, enabling you to easily customise your ligh�ng setup to your exact liking quickly and conveniently.
- Page 2 2. Parameters SET Bu�on: To ac�vate Smart Link mode, press and hold the SET bu�on for 3 seconds. Once the red indica- tor light starts to blink quickly, then reset the connected device to link the devices. Switching Output Mode: Quickly press the SET bu�on.
- Page 3 Controller Connec�ng To LED Strip Diagram The following diagrams indicate how to wire your controller with your LED strips. Note that controller input voltage must be in accordance with the required voltage of LED strips...
- Page 4 3. Signal Transmi�ng One single light can transmit the signal received from your remote to another light within 30m. As a result, as long as you have a light within 30m, the distance this remote control can cover is theore�cally limitless. 4.
- Page 5 5. Linking/Unlinking Instruc�ons To link Your Light To A Remote If the light is not blinking slowly, then the linking has not been successful. Please follow the above steps again. Please note, lights that have been linked cannot be linked again. To Unlink Your Light From A Remote If the light is not blinking quickly, the unlinking has not been successful.
- Page 6 Compa�ble With These Remote Control (Sold Separately) 6. Instruc�onal Videos If you want to learn how to pair your controller with a smartphone app, or with a third-party voice control system, you can scan these QR codes to watch an instruc�onal video...
- Page 7 5. Do not use the light in a loca�on with strong electromagne�c waves nearby, or else the remote distance will be seriously affected. sales@mirrorstone.co.uk www.mirrorstoneheating.co.uk 86 Scudamore Road Leicester, LE3 1UQ +44 (0) 116 321 4121...
