ASSEMBLY INSTRUCTIONS
INSTRUCTIONS D'ASSEMBLAGE
INSTRUCCIONES DE ENSAMBLAJE
Modèle
Model/
/ Modelo
-3268-
Item
Article/
/ Articulo
Headboard 39"
Tête de 99 cm
-096-
Cabecera 39"
ADULT ASSEMBLY REQUIRED
DOIT ÊTRE ASSEMBLÉ PAR UN ADULTE
DEBE SER ENSAMBLADO POR UN ADULTA
N.B.: It is important to carefully read the instructions
before beginning the assembly.
Identify all the parts and hardware.
We recommend that you assemble the unit on a carpeted floor
to avoid scratches. To facilitate assembly
Keep the assembly instructions
for warranty purposes. It contains all pertinent
information regarding replacement parts and maintenance.
N.B. Il est important de bien lire les instructions
avant de commencer l'assemblage.
Bien identifier les pièces et la quincaillerie.
Il est recommand d'assembl
é
éviter les égratignures. Pour un assemblage facile et agréable
;
2 personnes sont requises
Gardez les instructions d'assemblage pour
la garantie. Elles contiennent toutes les informations pour un
remplacement de pièce ou pour l'entretien périodique.
N.B. Lea con detenimiento las instrucciones
antes de comenzar a ensamblar su mueble.
Identifique las piezas y los articulos de ferretería.
Se recomienda ensamblar la unidad sobre una alfombra
para evitar los rasguños. Para un ensamblaje mas facil
se necesitan dos personas.
para
un futuro
uso
Este instructivo contiene todas las informaciones necesarias
para un sustitución de pieza o un mantenimiento periodico.
1-800-290-0465
10012165
Rev.:C
2 people are required
for future use
and
l'unité sur un tapis pour
er
.
et pour
utilisation future
Guarde
el instructivo de ensamble
y para usos
de garantía.
01/02/2012
.
