D E L O R E A N M O T O R C O M PA N Y
ASI RADIO
OPERATING INSTRUCTIONS
1982/1983 DELOREAN
© 2021 Copyright DeLorean Motor Company. The stylized DMC and DeLorean logos are registered
trademarks of the DeLorean Motor Company. Availability, pricing and specifications subject to change.
DeLorean Motor Company, 15023 Eddie Drive, Humble, TX 77396, USA
REV. 0421-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASI and is the answer not in the manual?

Questions and answers

Summary of Contents for DMC ASI

  • Page 1 OPERATING INSTRUCTIONS 1982/1983 DELOREAN © 2021 Copyright DeLorean Motor Company. The stylized DMC and DeLorean logos are registered trademarks of the DeLorean Motor Company. Availability, pricing and specifications subject to change. DeLorean Motor Company, 15023 Eddie Drive, Humble, TX 77396, USA...
  • Page 2 DMC Parts DMC Workshop Manual DMC Service Bulletins Identification Manual Reproduction of original Reproductions of original factory documentation factory documentation Updated reproduction for dealership service as written for dealership of original factory personnel. service personnel. documentation. Part Number P3113096 Part Number P2107010...
  • Page 3 ON-OFF VOLUME CONTROL LEFT-RIGHT BALANCE CONTROL (INNER MOST KNOB) FRONT-REAR FADER CONTROL PUSH FOR RADIO STATION SEEK LOCAL/DISTANT CONTROL PUSH FOR TAPE PROGRAM CHANGE DOLBY NOISE REDUCTION BUTTON TREBLE CONTROL (CENTER KNOB) RADIO PUSHBUTTONS BASS CONTROL (OUTTER MOST KNOB) FAST FORWARD/REWIND CONTROLS AM/FM SELECTOR BUTTON TAPE EJECT CONTROL...

  • Page 4: Radio Operation

    RADIO OPERATION TO TURN TAPE PLAYER OR RADIO ON The ON-OFF switch combined with the VOLUME control, both of which are operated by the left front knob. Turn this knob clockwise until a “click” is heard, which indi- cates that the radio is now “ON”. Further clockwise rota- tion will increase the volume.

  • Page 5: Seek Tuning

    (filtered) out. SEEK TUNING The SEEK tuning feature of this radio automatically lo- cates the next strong station available on the radio dial when actuated. This feature operates in the up scale di- rection. The SEEK tuning feature is activated by pushing in the left front knob when in the radio mode.
  • Page 6 4. Press one of the tuning pushbuttons. The “M” on the display area will go out indicating the button is now preset to this station. 5. Repeat steps 2-4 for the remaining buttons. 6. Set the AM/FM selector button to the other broad- cast band and set the six pushbuttons in the same manner as above.

  • Page 7: Treble Control

    When the indicator light is off, the radio is in the ‘Local’ mode. This switch allows the user to discriminate the strong (‘Local’ position) from the weak stations (‘Distant’ position) in the FM mode. When the radio is in the Seek Tuning mode, this feature allows the user to discriminate the strong station from the weak stations on both the AM and FM bands.

  • Page 8: Loudness Control

    FADER CONTROL (FRONT-REAR) Adjust the fader control, the rear knob on the right side of the radio to the point where the volume appears equal between the front and rear speakers. LOUDNESS CONTROL Low volume labels are deceptive to the human ear in that the ear has a tendency not to hear the low and high frequencies (bass &...

  • Page 9: Tape Player Operation

    TAPE PLAYER OPERATION Insert the tape cassette into the tape slot until it locks into position. The unit is automatically switched to tape player operation and one of the green tape direction in- dicators located on either side of the display area will be on.
  • Page 10 when depressed. This function allows the location of other sections of the tape program. The button will lock when depressed fully inward. It can be released by par- tially pishing in the Eject button. When the button is re- leased, the unit will play at normal speed. EJECT To eject the tape cassette push in firmly on the “EJECT”...
  • Page 11 Push the button when using hi-bias chrome tape to achieve more faithful reproduction. The function is ON when the green light is ON. PARTS ASI RADIO NOSE PIECE ASI RADIO FACEPLATE Part Number 110691 Part Number 110699 POWER ANTENNA MOTOR &...
  • Page 12 D E L O R E A N M O T O R C O M PA N Y © 2021 Copyright DeLorean Motor Company. The stylized DMC and DeLorean logos are registered trademarks of the DeLorean Motor Company. Availability, pricing and specifications subject to change.
