- Page 1 [Docs] NetPing Converter 0-20mA, 886A02 ...
-
Page 2: Table Of Contents
[Docs] NetPing Converter 0-20mA, 886A02 - Содержание [ENG] [886A02] Introduction..................4 [ENG] [886A02] Limitation of Liability and Copyright ..........5 [ENG] [886A02] Overview and Main Features ............6 The External View of The Sensor ....................... 6 Main features............................6 [ENG] [886A02] Connectors and Indications Elements .......... - Page 3 [Docs] NetPing Converter 0-20mA, 886A02 - – ...
-
Page 4: [Eng] [886A02] Introduction
This manual will help you get acquainted with the specialities and features of the NetPing Converter 0-20mA, 886A02 model, get an idea of its functionality and technical characteristics and prepare the sensor for operation. A User Guide is designed for network administrators and users, who set up or operate a device. To work with a... -
Page 5: [Eng] [886A02] Limitation Of Liability And Copyright
User Guide, as well as firmware and software of devices and this User Guide belong to NetPing global Ltd. Сopying, replication and translation of this user guide to other languages are not allowed without a prior written permission of a rightholder. -
Page 6: [Eng] [886A02] Overview And Main Features
[Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Overview and Main Features [ENG] [886A02] Overview and Main Features The External View of The Sensor Main features Sensor Specifications Values Сurrent measurement range -30...30 mA ±3% Мoltage measurement range 0…30 VDC ±3% Resistance measurement range 0…29 999 Ohm ±3%... - Page 7 [Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Overview and Main Features Sensor Specifications Values Sensor weight 70 g [ENG] [886A02] Overview and Main Features – ...
-
Page 8: [Eng] [886A02] Connectors And Indications Elements
[Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Connectors and Indications Elements [ENG] [886A02] Connectors and Indications Elements Front Panel Element Function Common connector RS- / RS+ Current loop connectors +12V Power connector +12V +24V Power connector +24V [ENG] [886A02] Connectors and Indications Elements... -
Page 9: Back Panel
[Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Connectors and Indications Elements Back Panel Element Function Loop power indicator Sensor power indicator Host connector [ENG] [886A02] Connectors and Indications Elements – ... -
Page 10: [Eng] [886A02] Installation And Connection
The sequence of connection: Step 1. Remove the converter 886A02 from its packaging. Put it onto the place you need. Step 2. Connect the converter to the 1-wire port of the device (or through an extension-splitter) to which you are connecting it. - Page 11 [Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Installation and Connection The configuration of the sensor and notifications you can see in a description of a built-in firmware on a connected host device. [ENG] [886A02] Installation and Connection – ...
-
Page 12: [Eng] [886A02] Loop/Sensor Connection To The Converter
[Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Loop/Sensor Connection to the Converter [ENG] [886A02] Loop/Sensor Connection to the Converter Functions of the converter`s connectors • +24V and +12V — connectors which can give power to the sensor or loop; •... -
Page 13: The Example Of Connection
[Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Loop/Sensor Connection to the Converter The example of connection For convenience and clarity, we take a 10 kOhm variable resistor as a sensor, connected according to the High-side scheme. Thus, with the "middle" position of the resistor handle: 23,900 mV/4.86 mA = 4918 Ohm. -
Page 14: Equivalent Circuit Scheme Of A Meter Input
[Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Loop/Sensor Connection to the Converter If you connect it this way, only voltage will be measured. Equivalent circuit scheme of a meter input [ENG] [886A02] Loop/Sensor Connection to the Converter – ... -
Page 15: [Eng] [886A01] Delivery Package
[Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A01] Delivery Package [ENG] [886A01] Delivery Package The delivery package consists of: • a NetPing Converter with the analogue interface 0–20mA, 886A02 model — 1 pc.; • a Quick Start Guide brochure — 1 pc.; •... -
Page 16: [Eng] [886A02] Warranty
[Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Warranty [ENG] [886A02] Warranty The manufacturer guarantees normal operation of the product within 24 months from the date specified on the warranty sticker if a buyer follows operating and storage conditions. Manufacturer warranty applies only to failure of a device which occurred because of defects in manufacturing process of products and components used. -
Page 17: [Eng] [886A02] Operating And Storage Conditions
[Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Operating and storage conditions [ENG] [886A02] Operating and storage conditions The converter is designed for continuous round-the-clock operation in closed spaces. In operating conditions the converter is resistant to air temperature from -30°С up to+50°С (without moisture condensation, at normal humidity). -
Page 18: [Eng] [886A02] Additional Documents And Weblinks
[Docs] NetPing Converter 0-20mA, 886A02 -[ENG] [886A02] Additional Documents and Weblinks [ENG] [886A02] Additional Documents and Weblinks The page of the converter 886А02: http://www.netpingdevice.com/products/886a02 Manufacturer's website: http://www.netpingdevice.com Technical support contacts: http://www.netpingdevice.com/support Phone: +886-2-23121582 E-mail: support@netpingdevice.com [ENG] [886A02] Additional Documents and Weblinks – ...
