- Page 1 SIERRA VIDEO Sierra View MADI-XX User’s Manual...
- Page 3 S I E R R A V I E W M A D I - X X User’s Manual Sierra Video P.O. Box 2462 Grass Valley, CA 95945 Tel: (530) 478-1000 Fax: (530) 478-1105 Email: info@sierravideo.com Version 3.0 Publication Date: September 2014 The information contained in this manual is subject to change by Sierra Video...
-
Page 5: Table Of Contents
SIERRA VIDEO Table of Contents Introduction User configuration MADI-xx Expansion Slots Network Settings Powerful alarms Matrix setup Remote control, monitoring and configuration Using the on-screen matrix mimic scheduling Audio monitor assign ... -
Page 7: Introduction
SIERRA VIDEO Chapter Introduction The Sierra View MADI-xx is a 128 x 128 channel MADI router with integral multi-channel audio metering and signal fault alarms for up to 128 channels. It is designed for live sound theatres, concert halls, radio and TV and is supplied as a 1U... -
Page 8: Madi-Xx Expansion Slots
SIERRA VIDEO MADI-xx Expansion Slots It has two slots for optional external audio expansion using 32 channel analog or AES/EBU I/O cards. When fully expanded, the total usable matrix size is 192 x 128 (two I/P cards), 128 x 192 (2 O/P cards) or 160x160 (1 I/P card and 1 O/P card). -
Page 9: Powerful Alarms
MADI-XX An on-screen menu provides access to all parameters. Up to four pairs of audio channels can be selected for audible monitoring. These can be streamed over the TCP/IP network and are available in both analog and AES/EBU format via an optional monitor output card. -
Page 10: Remote Control, Monitoring And Configuration Scheduling
SIERRA VIDEO Remote control, monitoring and configuration scheduling Although the MADI-xx is designed to be used as a stand-alone monitor it may also be used with control and monitoring software to monitor and configure multiple units over a network. The optional Windows PC software (SOFT-xx) provides multiple frame integration, automated control, event logging, configuration scheduling, real time diagnostics and unlimited user setups. -
Page 11: Main Features
MADI-XX Main features 92x192 router allows any input to be switched to any output 2 x Coaxial & 2 x Optical 64 channel MADI interfaces for 128 MADI channels Optional external 32 channel audio I/O interface cards ... -
Page 12: The On-Screen Display
SIERRA VIDEO The on-screen display The MADI-xx meter/alarm display provides a visual status display of up to 128 channels in two rows of 64 channels each. Each row can be assigned to display MADI input 1 or 2, or the input External bus. -
Page 13: Bargraph Scales
MADI-XX Bargraph scales The following audio scales are supported: Note: Each bar type can have different range colors, break points and level reference. Where optional external audio cards are installed and preferences for different scale types has been detected, external channels are placed automatically into two groups according to signal type. -
Page 14: Alarm Indicators
SIERRA VIDEO Alarm indicators Flashing mini-alarms can be assigned to the bargraphs for under-level, over-level, anti-phase and no-carrier (AES only). The colors used are as follows: ・ Audio Loss: Yellow – position (left or right) indicates channel ・ Audio Over: Red – position (left or right) indicates channel ・... -
Page 15: Audio Streaming
MADI-XX Audio streaming Audio streaming bandwidth is directly proportional to the number of audio pairs streamed and the quality levels used: Network bit-rate does not change when multiple stations are listening to the same stream since multicasting is used for each stereo pair. -
Page 17: Operation
SIERRA VIDEO Chapter Operation The front panel user interface consists of 6 buttons. The functions assigned to control buttons depend on the mode selected. Operating modes Normal or ‘locked’ mode is the normal operating mode. Configuration or ‘menu’ mode provides access to configuration menus. -
Page 18: Control Button Summary
SIERRA VIDEO Control button summary The 6 menu buttons are assigned functions as follows: Note: Factory reset may be applied by holding down the Function/Fade buttons whilst performing a power cycle – see the Trouble Shooting for further details. -
Page 19: Menu Commands
MADI-XX Menu Commands The menu or configuration mode is entered by holding the Lock button down for three seconds. This will allow configuration menus to be accessed. Menu Navigation ← → Select submenu when menu name highlighted or change Parameter value within menu ↑... -
Page 20: Bargraph Scales
SIERRA VIDEO Bargraph scales Standard scales and their corresponding ballistics may be selected. These may be positioned to the left, right or both sides of the relevant bargraphs or turned off. Analog and digital scale references The AES/EBU scale is designed for use with digital audio. Analog scales can be used for AES/EBU channels, (and AES/EBU scales may be used for analog channels) but the default normal and upper range settings are re-scaled. -
Page 21: Level Bars - Bar And Label Settings
MADI-XX Level Bars – bar and label settings... -
Page 22: Meter Rows
SIERRA VIDEO Meter Rows Two 64 channel bargraph rows are supported which can be assigned to either MADI input or output or either the I/P or O/P expansion bus. If the second row is turned off, the first row is scaled to fill the screen. -
Page 23: Analog And Digital Groups
MADI-XX Analog and digital groups When digital and/or analog input cards are installed, the external input bus may be assigned to the upper and/or lower bargraph rows for monitoring. Bar groups are automatically created based on the following rules: With 2 analog input cards and a row selected as EXTERNAL IN, the meter scale for analog signals is used for all 64 channels in that row. -
Page 24: Phase Bars - Phase Bar And Multi-Indicator Settings
SIERRA VIDEO Phase Bars – phase bar and multi-indicator settings Phase bar settings The phase bar can be positioned at the top or bottom of the screen and assigned to any channel pair. Note: The assigned channel pair will be highlighted during selection from the on-screen mimic. -
Page 25: Alarms Configuration
MADI-XX Alarms configuration... -
Page 26: Alarms
SIERRA VIDEO Alarms Alarms may be enabled per channel for audio-loss and over-level. Alarms may be enabled per channel pair for anti-phase and carrier-loss (AES/EBU inputs only). Thresholds and timeouts are adjustable for each alarm type for both digital and analog bar types. -
Page 27: System - User Config, Ip Settings, Matrix Setup, Audio Mon, Screen Resolution
MADI-XX System – user config, IP settings, matrix setup, audio mon, screen resolution... -
Page 28: User Configuration
SIERRA VIDEO User configuration The MADI-xx has four user memories, USER 1, USER 2, USER 3 and USER 4. Settings can be copied from one user to the other and further changes can be made before saving. Any changes made are saved automatically when exiting the menu by briefly pressing the ‘Lock’ button, whichever User is selected. -
Page 29: Matrix Setup
MADI-XX Matrix setup Input sources may be taken from either the optical or BNC connectors for each 64 channel MADI inputs independently. Each of the three 64 output groups (MADI 1, MADI 2 and the Ext bus) of the 192x192 matrix may assigned to any of the 64 input groups;... -
Page 30: Audio Monitor Assign
SIERRA VIDEO Audio monitor assign There are four audio monitor output pairs available in both analog and digital form. Each of these pairs can be assigned to any available pair of audio inputs. Both analog and digital audio monitor outputs are provided, irrespective of the format of the input signal selected for monitoring. -
Page 31: About - Firmware And Installed Cards
MADI-XX About – Firmware and installed cards Firmware The firmware level installed is shown for both network and controller. Input card type The type of I/O cards fitted is displayed. -
Page 33: Installation
SIERRA VIDEO Chapter Installation The Sierra View MADI-xx 1U frame may be installed in 19 inch bays with 355mm depth (~400mm including connectors). Ventilation is produced in each frame with three exhaust fans on the left hand side (viewed from front) with intake grilles at the right. -
Page 34: Health And Safety Considerations
SIERRA VIDEO Health and safety considerations The Installation and Maintenance of the Sierra View MADI-xx unit and any associated equipment, must be carried out by PERSONS SUITABLY QUALIFIED to work with equipment which may be connected to the mains supply. -
Page 35: Input Card Configurations
MADI-XX Input card configurations The MADI-xx may be fitted with up to two hot-swappable external audio I/O cards. The input cards are always installed in the two lower right hand slots (as viewed from the front). The controller card is always fitted in the top left slot and the Audio Monitor card is always fitted in the bottom left slot. -
Page 36: Serial Port Assignments
SIERRA VIDEO Serial port assignments Jumpers JP1 and JP2 are located on the RS232 pcb at the rear of the unit. Access requires the removal of the top cover with the power removed as explained in the 'Removing the top cover' section. -
Page 37: Audio I/O Connector Pin Assignments
MADI-XX Audio I/O connector pin assignments Analoge audio In/Out Connector type: 37 way ‘D’ female AES/EBU inputs may be jumper selected per channel to be either balanced or unbalanced. The settings are set via jumpers on each digital audio input card. - Page 38 SIERRA VIDEO Analog audio Out connector type: 25 way “D” male...
-
Page 39: Supplied Accessories
MADI-XX Supplied accessories Options... -
Page 40: Upgrading Firmware
SIERRA VIDEO Upgrading firmware From time to time, MADI-xx firmware updates may be made available. These might be either for the network card, the controller card, or both. The method for uploading to the frame is the same and is easily performed using a PC connected to the MADI-xx LAN port directly, or over a network. -
Page 41: Using Soft-Xx
MADI-XX Using SOFT-xx SOFT-xx has been developed specifically for use with the Sierra View AM-xx and MADI-xx multi- channel audio meter systems on a TCP/IP network. The main purposes of the software are: ・ The integration of up to four AM-xx and / or MADI-xx frames on a LAN ・... -
Page 42: Config-Xx
SIERRA VIDEO CONFIG-xx This application is the system management administrative tool. Password protection can be implemented to prevent unauthorized access. Only one instance of CONFIG-xx can be run on the same LAN at any one time. CONFIG-xx is USB dongle protected and must be run on the PC to which the dongle is connected. - Page 43 MADI-XX Virtual Meter Bridge Displays Parameters monitored by DISPLAY-xx can include audio level, audio-loss, carrier-loss (when using AES/EBU inputs) over-level and sustained anti-phase between assigned channel pairs. Six industry standard audio meter types are supported and each meter can have its own range colors, break points and reference level.
-
Page 44: Installation Guide
SIERRA VIDEO Installation Guide A basic system consists of multiple MADI-xx/AM-xx frames and a single PC connected to a common LAN. The LAN may be dedicated or form part of a larger system. In the latter case, care must be taken to ensure that sufficient data capacity is available and that no conflicts are likely to be encountered with other equipment and services. -
Page 45: Initial Setup
MADI-XX Initial Setup Both CONFIG-xx and DISPLAY-xx use IP addresses to communicate with frames. If desired, IP settings can be entered directly via each MADI-xx/AM-xx on-screen menu. Alternatively, CONFIG-xx can be used to search for MADI-xx/AM-xx frames on the network by entering the Network Setup page within its Utilities menu. -
Page 47: Troubleshooting
SIERRA VIDEO Chapter Troubleshooting The power switch should illuminate red whenever mains power is supplied. Always ensure that power is connected before using the problem solving guide. A spare fuse is supplied in space provided in the IEC mains connector before the unit leaves the factory. Always replace the fuse with one of the correct value as shown in the Installation section. - Page 48 SIERRA VIDEO Can I use analog bargraphs for digital inputs (or digital scales for analog inputs)? Yes. The range colors, break points and level references are set for the scale type and NOT the source assigned. For example assuming the following settings:...
- Page 49 MADI-XX How is audio monitoring streamed? Audio is streamed using open standard RTSP/RTCP/RTP streaming media protocols and can be played back by any compliant media player. This includes Quicktime, VLC, and MPlayer. Others, such as Microsoft Media Player and RealPlayer use their own standards and cannot be used.
-
Page 51: Specifications
SIERRA VIDEO Chapter Specifications Standard I/P format 2 x MADI 64 channel, coaxial & optical Optional I/P format Analog, 32 channels, +24 dB capability per card AES/EBU, balanced / unbalanced, 16 pairs per card Inputs 32/44.1/48/96 kHz. All 96kHz AES/EBU input channels are resampled at 48KHz for resynchronization with the internal clock. - Page 52 SIERRA VIDEO Scales and Ballistics NORDIC: Overall dynamic range: 54dB (+12 to -42dB) Attack time: 10mSec Decay time: 1.7Sec per 20dB decay DIN PPM: Overall dynamic range: 55dB (+5 to -50dB) Attack time: 10mSec Decay time: 1.5Sec per 20dB decay BBC PPM: Overall dynamic range: 24dB +3dB down "Mark 1"...
-
Page 53: Warranty
Warranty A. General Buyer assumes all responsibility for ascertaining the suitability of Sierra Video (hereinafter "SVS") products for Buyer's intended use. No product sold by SVS is designed or manufactured for use in any manner or under any conditions other than those described in SVS's instruction manuals and other printed material for each particular product. - Page 54 WARRANTY THIS LIMITED WARRANTY IS EXPRESSED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE, AND ALL OTHER OBLIGATIONS OR LIABILITIES ON SVS'S PART. SVS neither assumes nor authorizes any other person to assume for SVS any other liabilities in connection with the sale of products of its own manufacture.
