Page 1 PRODUCT MANUAL SPARTAN CEILING TILT TV LIFT...
Page 2: Table Of Contents
TABLE OF CONTENTS SPARTAN PRODUCT DIAGRAM ................................3 PRE-INSTALLATION ................................6 INSTALLATION: METHOD 1 ..............................7 INSTALLATION: METHOD 2 ..............................9 POST-INSTALLATION: ................................. 11 CABLE MANAGEMENT ................................ 13 MOUNTING THE TV ................................15 WIRING DIAGRAM ................................17 OPERATION ..................................18 OPERATION: AUTOMATION ...............................
Page 3: Product Diagram
PRODUCT DIAGRAM SPARTAN PRODUCT DIAGRAM LID CLOSURE PANEL SIDE TRIM PANELS REMOVABLE ACCESS PANEL (CONTROL BOX IS ON THIS SIDE) SCREEN HANGING RAILS CEILING CLOSURE PANEL...
Page 4 PRODUCT DIAGRAM SPARTAN PLASTER CEILING WIDTH DEPTH (LENGTH/3) - 120 LENGTH - 160...
Page 5 PRODUCT DIAGRAM SPARTAN SECTION 12MM MOUNTING POINT FRONT PANEL GAP SIDE PANEL GAP DETAIL DETAIL AREA TO BE PLASTERED SIDE PANEL GAP REAR ULTRALIFT CEILING PANEL GAP PANEL REAR PANEL DETAIL DETAIL...
Page 6: Pre-Installation
After establishing the correct location for the lift and display panel, cut a hole in the ceiling at the size listed on the following page. Organise a qualified trades person to frame up the roof to accommodate the Spartan so that it can be •...
Page 7: Installation: Method 1
3. Route the Audio-Visual cables to the lift position in the ceiling. See the Cable Management instructions to be followed post install. 4. A double power point is required in the ceiling to power the Spartan and the display panel. NOTE: Access to the power point in the ceiling is advisable.
Page 8 INSTALLATION: METHOD 1 SPARTAN 7. Raise the Spartan unit into the pre-cut hole from the underside into position and line up with the pre-built timber frame. 8. Ensure the bottom of the unit is flush with the ceiling plaster. 9. Secure the unit in place using the coach screws and through the mounting holes.
Page 9: Installation: Method 2
2. Route the Audio-Visual cables to the lift position in the ceiling. See the Cable Management instructions to be followed post install. 3. A double power point is required in the ceiling to power the Spartan and the display panel. NOTE: Access to the power point in the ceiling is advisable.
Page 10 INSTALLATION: METHOD 2 SPARTAN SECTION 4 x ROOF MOUNTING PLATES FRAME WIDTH -186MM LOCKING ALLTHREAD NUTS DYNABOLT OPTION DETAIL ALLTHREAD OPTION...
Page 11: Post-Installation
2. If using IR Controller, expose the IR eye in a suitable position to achieve line of sight to the remote. 3. Once Spartan unit is safely secured, refit any removed panels, in reverse order as you took it apart.
Page 12 POST-INSTALLATION: SPARTAN FRONT CUT AWAY VIEW (BLUE = PLASTER INFILL AREA) SIDE CUT AWAY VIEW (BLUE = PLASTER INFILL AREA) CEILING PLASTER TRIM PANEL TRIM PANEL CEILING STANDARD PLASTER PLASTER DETAIL DETAIL FRONT SIDE...
Page 13: Cable Management
CABLE MANAGEMENT SPARTAN CABLE MANAGEMENT 1. Connect cables (blue) to the display panel and run-down cable management arms as per diagram below. Make use of Cable Ties provided as indicated in the diagram below (black lines). There is a small clearance between the frame members and the timber closure panel, allowing the use of the Cable Ties.
Page 14 CABLE MANAGEMENT SPARTAN CABLE MUST PASS THROUGH HOOP DETAIL RUNNING CABLE THROUGH HOOP...
Page 15: Mounting The Tv
SPARTAN MOUNTING THE TV CAUTION The screen should only be fitted to the lift when installation of the Spartan has been completed. The Installer is responsible for ensuring that the lift is properly secured in the ceiling. 1. Connect power to the lift and lower lift using the controller.
Page 16 MOUNTING THE TV SPARTAN VERTICAL RAILS SLOT OVER HORIZONTAL RAILS VERTICAL RAILS LOCKED IN PLACE WITH LOCKING SCREW DETAIL DETAIL...
Page 17: Wiring Diagram
WIRING DIAGRAM WIRING DIAGRAM The wiring diagram shown below is the standard wiring arrangement for Ultralift’s Linear-Motor Driven products including Atlas, Phoenix, Titan, and Spartan range. This should not need to be changed unless swapping to an integrated automation setup using contact closure.
Page 18: Operation
LEARNING A NEW REMOTE: To learn a new remote handset, point the remote at the IR receiver then press and hold the stop “ “ button for 10 seconds. Ultralift UIRC DP1U Infrared Remote IMPORTANT The lift should not be run up and down more than 4 times, or continuously at full load for more than 1 minute without a 10-minute break.
Page 19: Operation: Automation
OPERATION: AUTOMATION OPERATION: AUTOMATION Your product can be integrated into most control systems using dry contact relays. These instructions are provided for Automation specialist reference only. Please contact us, or an Automation specialist, before attempting this change. If your existing product does not have a DP1U Controller: Unplug and remove the original controller and replace it with a DP1U Controller.
Page 20 “LEARNING A NEW REMOTE” procedure should be followed. The Ultralift UIRC has a built-in infrared receiver located behind the small hole on the side of the box to accommodate adhesive backed infrared emitters without using the infrared eye extension.
Page 21: Troubleshooting
Release the “DOWN” button then press and hold again for 6 seconds. The lift should move up and down slightly. The system is now initialised. If you are still having issues, please contact Ultralift Australia on +61 3 9459 0873 for further support.
Page 22: Warranty And Returns
WARRANTY AND RETURNS SPARTAN WARRANTY AND RETURNS At Ultralift Australia Pty Ltd, we take pride in the fact that our products are of the highest quality. Because of this, we offer the following programs to ensure your satisfaction. ULTRALIFT 3 YEAR WARRANTY 1.
