Summary of Contents for Quadelectra Transient Splitter

  • Page 3: Welcome To Transient Splitter

    Usually you tame your transients using a Transient Shaper, that takes an audio input, processes the transients, and outputs the result. Transient Splitter, although it can be used as a Shaper, takes an input audio signal and splits it into two different parts. The actual transients of a signal, and the body part (the rest).
  • Page 4: How Transient Splitter Works

    Operation Manual 1.3. How Transient Splitter Works Instead of using a set of envelope followers, Transient Splitter uses an envelope to extract the detected transients from the audio input signal. This method ensures more consistent results. The transients are subtracted from the input signal and the result of that operation produces the body part.
  • Page 5: Front Panel

    The output volume affects only the main output of the device. Auxiliary outputs are not affected. • Detection Controls (Grey): Transient Splitter uses an envelope follower set up to detect transients. This group of controls, deals with the detection aspects of the envelope follower and the input signal.
  • Page 6 Operation Manual and Right channels separately, causing different triggers for each channel. This switch does not produce any results when Transient Splitter is used in mono. ◦ Sens (Sensitivity): Use this knob to dial the desired sensitivity for the trigger. Lower values make the envelope follower more sensitive and catch more transients.
  • Page 7 ▪ Linear ▪ Exponential ◦ Trigger Lamp: This lamp flashes every time a trigger is detected by the Transient Splitter. Transient Controls (Red) / Body Controls (Blue): These two groups • contain the same set of controls. One is dedicated to the Transient part and the other to the Body part of the processed signal.
  • Page 8 Operation Manual ◦ Aux Connection Lamp: This lamp is lit when the auxiliary outputs are connected to another device. Fig.2.5: The final product with respect to the previous figure. The red area is the transient part of the input audio, while the blue is the body of the signal.
  • Page 9: The Rear Panel

    Operation Manual 3. The Rear Panel Figure 3.1: Transient Splitter Rear Panel Transient Splitter’s rear panel, is divided in 5 sections. Starting from left to right, these are: • Main Inputs (L/R): As expected, incoming signal to be processed is connected to this pair of inputs.
  • Page 10 Operation Manual ◦ Trig CV Out: Fires a CV Trigger once a transient has been detected by the Rack Extension device. ◦ Env CV Out: Similar to Trigger CV Out, but instead sends the complete AHD envelope level Page 10...
  • Page 11: Appendix I: Midi Cc Map

    Operation Manual APPENDIX I: MIDI CC Map Below you can see the Transient Splitter MIDI Continuous Controls Map. CC # Description Envelope Attack Time Envelope Hold Time Envelope Decay Time Envelope Follower Sensitivity Transient Volume Body Volume Input Gain Output Volume...
  • Page 12: Table Of Contents

    Operation Manual TABLE OF CONTENTS 1. Welcome To Transient Splitter............3 1.1. What Are Transients............3 1.2. What Is the Transient Splitter by Quadelectra......3 1.3. How Transient Splitter Works..........4 2. Front Panel................5 3. The Rear Panel...............9 APPENDIX I: MIDI CC Map.............11 TABLE OF CONTENTS..............12...
