MODEL
ACKPWB6K NEPTUNE KEYPAD EM/HID S/ALONE WIEGAND OUT IP68 VANDAL PROOF (3x4)
HOW TO........
Press and Hold * for 2-3 Sec's until Red LED Flashes
<Enter>888888 #
00 (New Master Code) #, (Repeat new Master code) #
Note: New Master code must be a 6 digits number.
-
Exit Menu's
Note: Admin password is a 6 digits number, 888888 is the factory default admin password.
The user must change the admin password when use the device for the first time, otherwise user
cannot continue other operations.
After inputting correct Master code, the LED light will flash green for one time and then back to red
flashing status.
HOW TO........
Press and Hold * for 2-3 Sec's until Red LED Flashes
<Enter>Admin Password #
(Specified ID number and input 4-6 digits PIN to add user:)
11 (ID) # (User PIN) #(User 1) , (ID) # (User PIN) #(User 2), ... (Multiple Users keep adding until
finished)
- Exit Menu's
Eg. 11 1 # 1111 (User ID 1 with PIN 1111)
Note: ID number are 1~5 digits between 1~20000, User PIN in zone 1 are any 4~6 digits, except 1234
NEPTUNE
Quick Reference Guide
Change Default Master Code for Normal operation
Add a PIN User
Advertisement
Table of Contents
Summary of Contents for Neptune ACKPWB6K
- Page 1 NEPTUNE Quick Reference Guide MODEL ACKPWB6K NEPTUNE KEYPAD EM/HID S/ALONE WIEGAND OUT IP68 VANDAL PROOF (3x4) HOW TO…….. Change Default Master Code for Normal operation Press and Hold * for 2-3 Sec’s until Red LED Flashes <Enter>888888 # 00 (New Master Code) #, (Repeat new Master code) # Note: New Master code must be a 6 digits number.
- Page 2 NEPTUNE Quick Reference Guide HOW TO…….. Set Lock - Open-time Press and Hold * for 2-3 Sec’s until Red LED Flashes <Enter>Admin Password # 34, 0#, Can set Open time to 50mS, pulse for some access control systems or RQE inputs. ## 34, (1-999) #, the default value is 2, set Open time from 1 to 999Sec’s **.
- Page 3 NEPTUNE Quick Reference Guide HOW TO…….. Set for Single Door mode, with Super-open password Press and Hold * for 2-3 Sec’s until Red LED Flashes <Enter>Admin Password # 03 1# - Single door mode (Default) 00 (8 digits #) Must be 8 digit Super-open password ...
- Page 4 NEPTUNE Quick Reference Guide HOW TO…….. Set for Doorbell operation Press and Hold * for 2-3 Sec’s until Red LED Flashes <Enter>Admin Password # 4.1.18 Set alarm or doorbell output function • 42 1 # - alarm wire output doorbell signal voltage <Grey Wire>...
- Page 5 Authorization-card when you need to restrict user access ## The Authorization Cards must be Ordered separately and do not come with the ACKPWB6K These Cards would be either EM or HID Format and could be any Site Code or User No.
- Page 6 11(ID, User Location)# read card<To Activate Relay 2> Exit Menu’s ## The Authorization Cards must be Ordered separately and do not come with the ACKPWB6K To Activate follow the steps below, Press and Hold * for 2-3 Sec’s until Red LED Flashes Note: Add number “2”...
