Metro Water Filter of the South
5600 Filter Head Controls & Settings
Table of Contents
Controls and operation_________________________________________________________________ 1
The Clock _________________________________________________________________________ 2
Setting the time ___________________________________________________________________ 2
Backwashing ______________________________________________________________________ 3
What is Backwashing?______________________________________________________________ 3
The Backwash Cycles ______________________________________________________________ 3
Manually starting a backwash cycle ___________________________________________________ 4
The Day Cycle Dial _________________________________________________________________ 5
The Pins_________________________________________________________________________ 5
Infrequent Backwashing _____________________________________________________________ 6
Multiple Filters ____________________________________________________________________ 6
We're here to help __________________________________________________________________ 6
Time Ring
Release Button
Control Knob
Controls and operation
The controls on your filter are fairly simple. Your filter is fully automatic. Other
than normal servicing, and making sure the filter's clock is set to the correct time,
there's not much else for you to do.
Toll free 1-888-604-8043
5600 Filter Power Head
Metro Water Filter of the South
Toll free 1-888-604-8043
Time Window
Day Cycle Dial
1
Advertisement
Table of Contents
Related Manuals for Metro Water Filter of the South 5600
Summary of Contents for Metro Water Filter of the South 5600
- Page 1 Metro Water Filter of the South Toll free 1-888-604-8043 5600 Filter Head Controls & Settings Table of Contents Controls and operation_________________________________________________________________ 1 The Clock _________________________________________________________________________ 2 Setting the time ___________________________________________________________________ 2 Backwashing ______________________________________________________________________ 3 What is Backwashing?______________________________________________________________ 3 The Backwash Cycles ______________________________________________________________ 3...
- Page 2 Metro Water Filter of the South Toll free 1-888-604-8043 The controls on our 5600 power head (photo above) consist of the Control Knob (the large knob in the center of the head), the Time Ring (the large cog wheel behind the Control Knob), the red Release Button, and the Day Cycle Dial (to the right of the Control Knob).
- Page 3 Metro Water Filter of the South Toll free 1-888-604-8043 Note: Be sure to check for AM or PM time since our filters run on a 24 hour clock. You’ll see ‘a’ for AM or ‘p’ for PM in the Time Window.
- Page 4 Metro Water Filter of the South Toll free 1-888-604-8043 time. Once the backwash cycle has begun, the Control Knob advances and displays, each stage of the backwash cycle. In the photo shown below, the filter has entered the first stage of the backwash cycle. The Control knob displays “START B.W.”, meaning the backwash cycle has started.
- Page 5 Metro Water Filter of the South Toll free 1-888-604-8043 The Day Cycle Dial This dial controls the number of times the filter will backwash within a 12-day cycle. At the end of the 12-day cycle, the filter will repeat the cycle.
- Page 6 Metro Water Filter of the South Toll free 1-888-604-8043 Infrequent Backwashing If you won't be using water for several weeks or months, say for a vacation home, you can push all the pins in so the filter won’t clean itself. When you return to your home, set the filter to clean itself that first night.
