Art. Nr.: 12200R Cabrio
EN
Instructions for assembly and use
Item no.: 12200R
Gas Barbecue Trolley Cabrio
Before you start using this device, please read this installation and
instructions carefully.
Keep these operating instructions in a safe place for future reference.
Page 1 of 22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 12200R Cabrio and is the answer not in the manual?

Questions and answers

Related Manuals for Activa 12200R Cabrio

Summary of Contents for Activa 12200R Cabrio

  • Page 1 Art. Nr.: 12200R Cabrio Instructions for assembly and use Item no.: 12200R Gas Barbecue Trolley Cabrio Before you start using this device, please read this installation and instructions carefully. Keep these operating instructions in a safe place for future reference.

  • Page 2: Table Of Contents

    Art. Nr.: 12200R Cabrio Table of contents 1. Table of contents ....................2 2. Product information ..................2 3. Safety instructions ..................3 4. Intended use ....................4 5. Technical data ....................4 6. Assembly instructions ..................5 7. Exploded view ....................6 8. Parts list ......................7 9.

  • Page 3: Safety Instructions

    Art. Nr.: 12200R Cabrio Safety instructions Please observe the following symbol hints: Warnings! Attention! Warnings: • Only use the grill trolley outdoors! Never in an enclosed space such as a tent, boat or mobile home. • Do not move the grill cart during operation! •...

  • Page 4: Intended Use

    Art. Nr.: 12200R Cabrio Attention: • Parts of the grill are very hot during operation, protect from children! • When grilling, wear grilling gloves, according to DIN-EN 407 or use suitable grilling tongs! • Any technical modification to the device can be dangerous and is not allowed! •...

  • Page 5: Assembly Instructions

    Art. Nr.: 12200R Cabrio 2575-21 6. Assembly instructions ca. 1 Stunde Set-up time: • Read the assembly instructions carefully before assembly and commissioning and follow the assembly steps. • Allow sufficient time for the assembly. • Create a working area of approx. 2 - 3 m².

  • Page 6: Exploded View

    Art. Nr.: 12200R Cabrio Exploded view Page 6 of 22...

  • Page 7: Parts List

    Art. Nr.: 12200R Cabrio Parts list Bezeichnung Anz. Bild Bezeichnung Anz. Bild Support leg back Cooking grid right Flame tamer Front cover Support leg Grill body front right Support leg Side shelf back left Bracket A for side Support leg...

  • Page 8: Mounting Material

    Art. Nr.: 12200R Cabrio 9. Mounting material Bezeichnung Anz. Bild Bezeichnung Anz. Bild Screw Collar Screw M6 M6x12 Split pin Please note that we must reserve the right to make minor factory changes regarding the mounting material. Page 8 of 22...

  • Page 9: Assembly

    Art. Nr.: 12200R Cabrio 10. Assembly Step 1 A M6 x12 8 Pieces Step 2 A M6 x12 8 Pieces Page 9 of 22...
  • Page 10 Art. Nr.: 12200R Cabrio Step 3 A M6 x12 8 Pieces Step 4 2 Pcs. Page 10 of 22...
  • Page 11 Art. Nr.: 12200R Cabrio Step 5 Step 6 A M6 x12 4 Pcs. Page 11 of 22...
  • Page 12 Art. Nr.: 12200R Cabrio Step 7 A M6 x12 8 Pcs. Step 8 C M6 8 Pcs. Page 12 of 22...
  • Page 13 Art. Nr.: 12200R Cabrio Step 9 Page 13 of 22...
  • Page 14 Art. Nr.: 12200R Cabrio Step 10 Page 14 of 22...
  • Page 15 Art. Nr.: 12200R Cabrio The grill is now ready for operation! Carefully read the safety instructions and directions for lighting the grill before operating the unit! Please note that we must reserve the right to make minor factory changes regarding the mounting material.

  • Page 16: Connecting The Gas Cylinder And Checking For Leaks

    Art. Nr.: 12200R Cabrio 11. Connecting the gas cylinder and checking for leaks The following parts are required to connect the device: • Commercially available camping gas bottle 5 - 11kg filling weight, e.g., gray camping propane gas bottle. You buy these from a liquid gas dealer. The empty cylinder is replaced for refilling.

  • Page 17: Storage Of The Gas Cylinder

    Art. Nr.: 12200R Cabrio 12. Storage of the gas cylinder The storage of gas cylinders is not permitted in rooms below ground level, in stairwells, corridors, passageways and driveways of buildings or in their immediate vicinity. The valves must be fitted with valve protection caps and lock nuts.

  • Page 18: Information On Commercial Use

    Art. Nr.: 12200R Cabrio Light the grill with a match: 1. Proceed as indicated. 2. Light a long match and insert it into the ignition hole on the right side of the firebox. 3. Press and turn the control knob of the selected burner to MAX.
  • Page 19 Carry out the nection points leak test as described. Technical Service Hotline: 09287 / 9560970 Mo - Fr von 8 - 17.00 ACTIVA Grillküche GmbH – Wilhelmstraße 10 - 95100 Selb / Bayern Page 19 of 22...

  • Page 20: Cleaning And Maintenance

    Art. Nr.: 12200R Cabrio 16. Cleaning and maintenance The gas grill is easy to clean and in general maintenance-free, but the housing should be cleaned occasionally after use with detergent and a sponge. To do this, the appliance must be completely cooled down and the gas supply closed.

  • Page 21: Warranty

    • If original spare parts are not used. Service Hotline: ACTIVA Grillküche GmbH – Wilhelmstraße 10 – 95100 Selb Tel.: 09287 9560970 Monday – Friday between 8:00a.m - 17:00 p.m Page 21 of 22...

  • Page 22: Declaration Of Conformity

    Art. Nr.: 12200R Cabrio 20. Declaration of conformity Declaration of Conformity Konformitätserklärung ACTIVA Grillküche GmbH Wilhelmstraße 10 / D 95100 Selb Hereby declare that our product(s): Hiermit wird erklärt, dass das unten bezeichnete Produkt Artikel Nr.: 12200R Produktname: Gas-Grillwagen Cabrio •...
