- Page 1 MAGPOWR TENSION CONTROL MAGPOWR Model PS-24 24 VDC Power Supply Instruction Manual MI 850A302 1 D...
-
Page 2: Table Of Contents
INSTALLATION ..................3-1 Enclosure ......................... 3-1 Power selection and current range settings ............. 3-2 connections ......................3-3 MAINTENANCE ..................4-1 TROUBLESHOOTING ................5-1 SPECIFICATIONS ..................6-1 SERVICE AND REPLACEMENT PARTS ............7-1 www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D... -
Page 3: Introduction
All of the information herein is the exclusive proprietary property of Maxcess International, and is disclosed with the understanding that it will be retained in confidence and will neither be duplicated nor copied in whole or in part nor be used for any purpose other than for which disclosed. -
Page 4: Product Overview
The control circuits are not electrically isolated from the power circuits. The control circuit negative is connected to the P.E. connection, that is, control input circuits are not floating. www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D... -
Page 5: Safety Instructions
The signal word CAUTION refers to the danger of slight to moderate bodily injuries or material damage. The signal word NOTICE refers to the possibility of damage to equipment. www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D... -
Page 6: Symbols Used
WARNING/CAUTION – Danger due to voltage, electric shock Reference to danger of injury caused by electric shock due to voltage. WARNING/CAUTION – Danger due to hot surfaces Reference to risk of fire. www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D... -
Page 7: Basic Safety Information
Protect against unexpected movement by removing electrical power from the PS-24 system and the machine into which it is installed. Decommissioning The PS-24 must be disposed of in accordance with all the applicable national, state and local regulations. www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D... - Page 8 M O D EL: 35.2 mm [1.39 in] 85.9 mm [3.38 in.] C LU TC H -B R AK E P O W E R S U PP LY Figure 1. Enclosure dimensions www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D...
- Page 9 PS-24 (See Figure 3 for J2 current range settings). The factory setting is 1/2 amp range. Replace the enclosure top. Figure 3. J1 input power selection / J2 current range settings www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D...
-
Page 10: Installation
24 VDC supply. EMC performance may be REMOTE METER 0-1 mA DC 1K TO 10K degraded. Do not use with AC supply. (OPTIONAL) REMOTE POTENTIOMETER Figure 4. Electrical connections for PS-24 www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D... -
Page 11: Maintenance
The enclosure may be opened by inserting a flat blade screwdriver under the retaining tabs in the base (See Figure 2). The enclosure must be re-installed to maintain the IP rating. www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D... -
Page 12: Troubleshooting
1 mADC full scale and no more than 100 ohm resistance. Meter wires shorted or Disconnect meter wiring at the PS-24 open and check for proper meter resistance between the wires. www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D... -
Page 13: Specifications
-0.032 to 1.0 ADC -0.064 to 2.0 ADC Regulation: <1% of range Current drift: 0.024% Meter signal: 0 to 1 mADC, ±3% into 100 ohm maximum Potentiometer: 10 VDC ±3%, 10 mADC maximum www.maxcessintl.com MAGPOWR PS-24 Power Supply MI 850A302 1 D... - Page 14 AND AFRICA AND SE ASIA Tel +1.405.755.1600 Tel +86.756.881.9398 Tel +91.22.27602633 Tel +81.43.421.1622 Tel +49.6195.7002.0 asia@maxcessintl.com Fax +1.405.755.8425 Fax +86.756.881.9393 Fax +91.22.27602634 Fax +81.43.421.2895 Fax +49.6195.7002.933 www.maxcess.asia sales@maxcessintl.com info@maxcessintl.com.cn india@maxcessintl.com japan@maxcessintl.com sales@maxcess.eu www.maxcessintl.com www.maxcessintl.com.cn www.maxcess.in www.maxcess.jp www.maxcess.eu © 2018 Maxcess...
