- Page 1 INSTRUCTION MANUAL WTL Phono Rev. June 21...
- Page 2 A word from the Chief Engineer The Well Tempered Phono stage is designed to accommodate both moving magnet (MM) and moving coil (MC) cartridges and has a maximum gain of 68 dB for MC cartridges and the gain is switched for MM cartridges. The necessary break points for the RIAA equalisation are distributed throughout the circuit in order to ensure optimum overall time response of the circuit as well as to ensure the necessary frequency response.
- Page 3 The Well Tempered Lab Phono has a shielded chassis but it is not recommended that it is placed close to the turntable or cartridge.
- Page 4 Impedance and Gain The Well Tempered Lab Phono is equipped with micro switches on the underside to facilitate both loading and gain. There are many factors that contribute to the optimum loading for phono cartridges that include cables, preamplifier etc. and we recommend starting with the lowest impedance setting closest to the manufacturers recommendations.
- Page 7 Well Tempered Lab, P.O. Box 2650, Christchurch, New Zealand. This Well Tempered Lab product is warranted against defects in material and workmanship for one year from date of purchase. This warranty does not cover normal wear and tear and is void if the Well Tempered product has been subject to mis-use, accident or negligence or if it has been tampered with or modified in anyway.
- Page 8 Registration Card Name Address City State Post Code (Zip) Country Phone Email Model Serial No. Dealer Date of Purchase...
