- Page 1 SILENT SENTINEL ARE SPECIALISTS IN LONG RANGE OSIRIS INSTALLATION GUIDE OPTICAL SENSORS INCLUDING BOTH COOLED AND UNCOOLED THERMAL CAMERAS Silent Sentinel Osiris Mechanical Installation Guide Version: V1.0 Date: 12/08/2021 Commercial in Confidence 1/26...
- Page 2 Please refer to the actual product. We try our best to make sure all the contents in this manual are accurate. We do not provide any representations or warranties in this manual. If you need the latest version of this manual, please contact us. Silent Sentinel recommends that you use this manual under the guidance of professionals.
-
Page 3: Table Of Contents
OSIRIS INSTALLATION GUIDE Contents System Overview ............................... 5 Overivew ................................ 5 Power / Interface Requirements ........................5 System Orientation ............................6 Mechanical Installation ............................7 Overview ................................ 7 Fixtures and Fittings; ............................7 Mounting the Jaeger PTU ..........................8 Attaching the Side Payloads ........................10 Wiper Assembly Installation .......................... - Page 4 OSIRIS INSTALLATION GUIDE INSTALLATION SHOULD BE CARRIED OUT BY QUALIFIED PERSONNEL ONLY IN ACCORDANCE WITH THE APPLICABLE LOCAL CODES. THE MANUFACTURER CAN ACCEPT NO LIABILITY FOR ANY DAMAGES OR LOSSES CAUSED DUE TO INCORRECT OR IMPROPER INSTALLATION. Safety Information Before installing the equipment, please read this guide carefully. Installation of this product should only be carried out by a competent and suitably qualified engineer.
-
Page 5: System Overview
OSIRIS INSTALLATION GUIDE System Overview Overivew The Osiris PT system generally comprises of; 1. The Osiris PT Unit 2. QTY1 EO (Daylight Camera) 3. QTY1 Ti (Thermal Camera) However, as the Osiris is a highly modular platform the number and nature of payloads may vary from unit to unit. -
Page 6: System Orientation
OSIRIS INSTALLATION GUIDE System Orientation Figure 2 Figure 1 Figure 4 The Osiris is a 360 Degree PT unit but it does have a front indicated by the sticker shown in Figure 4. The sticker also displays the correct side connectors for the daylight and thermal payloads. Commercial in Confidence 6/26... -
Page 7: Mechanical Installation
OSIRIS INSTALLATION GUIDE Mechanical Installation Overview The system should be installed in the following order; 1. Pan / Tilt securely mounted to the Mast / Installation Location 2. Side Payloads 3. Cable / PSU Note: The system should not be powered on when any of the payloads are attached. Fixtures and Fittings;... -
Page 8: Mounting The Jaeger Ptu
OSIRIS INSTALLATION GUIDE Mounting the Jaeger PTU Step Detail The image on the right shows the Osiris mounting points. Primary mounting points Line up the Osiris base with the mast. Insert bolts through mast and line up with holes is Osiris base. Commercial in Confidence 8/26... - Page 9 OSIRIS INSTALLATION GUIDE Insert all bolts and tighten until spring washer is flat. Commercial in Confidence 9/26...
-
Page 10: Attaching The Side Payloads
OSIRIS INSTALLATION GUIDE Attaching the Side Payloads Note: please ensure you are attaching the payloads to the correct side. Please refer to the System Overview section for further information. Step Detail Protective caps are fitted to the ends of the shafts to prevent moisture and impact damage to the electrical connections. - Page 11 OSIRIS INSTALLATION GUIDE Once the tube is fully located on the shaft the top securing screw should be inserted and partially tightened – not all the way. The remaining two screws should be inserted in to their respective holes and, once in place, all three tightened fully Commercial in Confidence 11/26...
-
Page 12: Wiper Assembly Installation
OSIRIS INSTALLATION GUIDE Wiper Assembly Installation Overview This guide details the steps involved to install the wiper assembly onto a RHT camera housing. Fixtures and Fittings 1. Wiper Assembly 2. Wiper Blade 3. O-Ring 4. Fixings Step Detail Power down the camera unit and remove the bottom cover at the front of the camera housing. - Page 13 OSIRIS INSTALLATION GUIDE Insert the supplied O-Ring into the groove on the wiper box. Align the wiper assembly holes with camera house jack plug holes Screw the supplied M4x 50 screws into the QTY4 fixing holes. Ensure that the O’ring is seated properly when screwing together Insert the spring into the wiper assembely shaft.
- Page 14 OSIRIS INSTALLATION GUIDE Fit the wiper onto the shaft, locate the wiper at the desired park position and tighten. Note: the wiper ‘wipes’ anti-clockwise as you look at the face of the tube. Therefore, the park position should be to the right of the window and outside of the FOV of the camera.
-
Page 15: Boresight Guide
Boresight Guide Overview As standard Silent Sentinel factory boresights the cameras ‘parallel’ at full tele. Therefore, the separate between FOV should never be any greater than the separation of the payloads. However, should it be desired the boresight position can be adjusted externally as detailed below. -
Page 16: Vertical Adjustment
OSIRIS INSTALLATION GUIDE Vertical Adjustment Step Detail The cover is secured by four screws requiring an M3 Allen key tool. Using an M3 Allen key, loosen (do not remove) the locking screw that is located beside the adjustment wheel. The vertical action can now be made by turning the adjustment wheel using a chisel-tip (slot) screw driver. - Page 17 OSIRIS INSTALLATION GUIDE ANNEX 1 – Galvanic Kit Galvanic Kit Provided with the Galvanic Kit: 1. 4 x M8x20 aluminium bolts 2. Rubber matting for underneath base 3. Aluminium lanyard The galvanic kit prevents galvanic corrosion from happening on the base on the unit. It isolates the metal of the unit from the metal of the mast or platform it’s secured on.
-
Page 18: Annex 1 - Cable Information
OSIRIS INSTALLATION GUIDE ANNEX 2 - Cable Information Cable Overview The UCM cable supplied with the Osiris can come in various lengths (up to 50m) and in two different formats; 1. Double ended; a. Each end of the Aeron cable is terminated with a UTS6JC14E19S Connector i. -
Page 19: Annex 2 - Physical Connectors
OSIRIS INSTALLATION GUIDE ANNEX 2 - Physical Connectors Osiris Base Connector EATON Base Socket: U14EN (UCM) Cable Connector: UTS6JC14E19S Contact arrangement: 21-29. Contacts No.20 and No.25 are Coaxial types for Video transmission. View of the socket face. Installation cable - Contact assignments and conductors (CA-UCM cable). Commercial in Confidence 19/26... -
Page 20: Side Payload Mounting Connector
OSIRIS INSTALLATION GUIDE Side Payload Mounting Connector. MIL-D38999 G39 Amphenol D38999 Series-III / TV. PTZ Hub Socket: Amphenol D38999/20FG39SN (Connector on payload: Amphenol D38999/26FG39PN – For attached equipment) Contact arrangement: G39 / 21-99 - [G39T]. Contact “r” is a Coaxial type for Video transmission on HD-SDI models. (available on limited pan models only) View in to Socket face. - Page 21 OSIRIS INSTALLATION GUIDE Commercial in Confidence 21/26...
