MARcus TD-WI 1 Operation Manual

Weighing indicator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TD-WI 1
WEIGHING INDICATOR
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TD-WI 1 and is the answer not in the manual?

Questions and answers

Related Manuals for MARcus TD-WI 1

Summary of Contents for MARcus TD-WI 1

  • Page 1 TD-WI 1 WEIGHING INDICATOR Operation Manual...

  • Page 2: Table Of Contents

    Table of Contents SECTION 1 INTRODUCTIONS………………………………………………………………1 1.1 Introduction……………………………………………………………………………………1 1.2 Specification…………………………………………………………………………………..1 1.3 Installation…………………………………………………………………………..………...1 SECTION 2 KEYS DESCRIPTIONS………………………………………………………2 SECTION 3 OPERATIONS…………………….……………………………………….…..3 3.1 Power on/off................... 3 3.2 Functions and parameters setting................3 3.3 Zero the scale...................3 3.4 Tare the scale………………………………………………………………..……. 4 3.5 Parts counting (KEY=1)…………………………………………………………4 3.6 Accumulation (KEY=2)…………………………………………………………….5 3.

  • Page 3: Section 1 Introductions

    SECTION 1 INTRODUCTIONS 1.1 Introduction The indicator provides an accurate, fast and versatile series of general purpose weighing indicator with counting, check-weighing, animal weighing functions and preset tare. 1.2 Specification Stainless steel plastic housing Housing 220~240V AC (110V optional) 50/60Hz Power supply built-in rechargeable battery 6V1.3AH.

  • Page 4: Section 2 Keys Descriptions

    connection of RS232 Plastic housing connect to Din9 Pin 2 RXD Pin3 TXD Pin5 GND Stainless steel housing on PCB SECTION 2 KEY DESCRIPTIONS SOFT POWER ON/OFF Key Power on/off the indicator. ZERO Key 1) When self-checking, Press ZERO Key to enter parameter setting; 2) Set the zero point for all-subsequent weighing;...

  • Page 5: Section 3 Operations

    4) Enter/Cancel animal weighing function when “F3 KEY”=5; UNIT Key 1) When self-checking, press UNIT Key to set unit conversion coefficient. 2) Unit conversion when weighing. SECTION 3 OPERATIONS 3.1 Power on/off Press ON/OFF Key to power on the Indicator and the indicator self-checks, then goes into the weighing state. 3.2 Functions and parameters setting When self-checking, press ZERO Key to enter parameter setting.

  • Page 6: Parts Counting (Key=1)

    indicator will be on to show the indicator is now under tare operation. A product is placed in the container and it will show only the weight of the added product. The scale should be tare a second time if another is added to the first one.

  • Page 7: Holding The Weight (Key=3)

    3.7 Holding the weight (KEY=3) Press MOD Key to enter the hold function. After every weighing, the weight value will be kept on the display. MOD Key can be pressed to cancel hold function. 3.8 Presetting tare value (KEY=4) Press MOD Key to preset tare value. While every weighing, the value displayed is the one actual weight substrate the preset tare value.

  • Page 8: Print (Key=2)

    3.11 Print (KEY=2) Set “P10 PS”: “RS Prt” is selected for the Serial Printer. When weighing, press MOD Key to print. SECTION 4 FUNCTIONS AND PARAMETERS “F1 CLK”: Date and time setting When “F1 CLK” is showed, press FUN Key. It will display the time. Time setting: ZERO Key: shift digit;...

  • Page 9: Section 5 Rs-232 Output

    “F6 INP”: Display the internal counts For LED version “F6 CAL”: Calibration for LCD Version. See below: “F7 CAL”: Calibration “PN”: Press FUN Key to enter “PN”. Initiate password is 0000 “P1 SP”: Set AD converting speed. Options: 1/2/3/4/5. 1 is the fastest and 5 is the slowest. “P2 AUT”: Select the “Power on “...
  • Page 10 ST,GS 0.119,kg ST for stable; US for unstable ; GS for gross weight; NT for net weight ; 0.119 for weighing value; kg for unit (kg, lb); HEX 0d and HEX oa : HEX for hex; 0d for enter; 0a for next line. Mode 2: Automatic output Automatic output mode is same as continue output.

  • Page 11: Section 6 Error Codes

    SECTION 6 ERROR CODES ERROR DESCRIPTION RESOLUTION CODES - - OL - - Over range Remove weight from the scale. Err 1/Err 2 Date and Time not right Reset again. Err 4 Zero Setting Error The scale was outside the normal zero setting range either when it was turned on or when the ZERO Key was pressed.
