  • Page 1 TSR 2800-10C Hardware Installation Manual...
  • Page 2: Table Of Contents

    2.3.3 Cabinet Configuration ....................7 2.3.4 Power Requirements ....................8 2.4 Installation Tools and Device ....................8 Chapter 3 Installing the TSR 2800-10C Router ..................9 3.1 Installation Flow of TSR 2800-10C ..................9 3.2 Installing the Machine Box of the Router ................9 3.2.1 Installing the Machine Box on the Desk ..............10 3.2.2 Installing the Machine Box on the Cabinet ...............
  • Page 3: Chapter 1 Tsr 2800-10C Introduction

    TSR 2800-10C Hardware Installation Manual Chapter 1 TSR 2800-10C Introduction The section describes the characteristics and parameters of TSR 2800-10C and gives an overview of TSR 2800-10C. 1.1 Appearance Description for Standard Configuration The TSR 2800-10C modularized router has three parts: 10 10/100/1000M Ethernet ports, 1 Console port, 1 USB interface.
  • Page 4 If the indicator flickers, the system works normally. If the router is powered on, the Power indicator indicator is on. Back template of the TSR 2800-10C Table 0-3 Parts at the back template of the TSR 2800-10C Abbrev. Name Description WIFI1 antenna...
  • Page 5: Tsr 2800-10C Systematic Characteristic Parameters

    TSR 2800-10C Hardware Installation Manual grounding column The grounding must be fine. Input voltage: 170~264V, AC power supply input interface Input frequency: 47~63Hz, Input current: 1A/230V 1.2 TSR 2800-10C Systematic Characteristic Parameters Cavium CN5020 Memory 512MB Nor Flash Nand Flash 4Gbit...
  • Page 6: Rohs Description

    TSR 2800-10C Hardware Installation Manual Input voltage: 170~264V, AC power supply Input frequency: 47~63Hz, Input current: 1A/230V 1.3 ROHS Description - 4 -...
  • Page 7: Chapter 2 Installation Preparation

    Similar to other electronic products, the semiconductor chip easily gets damaged if you power on or off abruptly and frequently. To restart up the router of TSR 2800-10C, you have to open the power on-off after the power is cut down for three to five seconds.
  • Page 8: Safety Principles For Live Working

    TSR 2800-10C Hardware Installation Manual 2.2.3 Safety Principles for Live Working When you work under electricity, following the following principles:  Put off ornaments, such as ring, necklace, watch and bracelet, before you operate under live working. When metal articles connect the power to the ground, short circuit happens and components may be damaged.
  • Page 9: Requirements For Common Locations

    TSR 2800-10C Hardware Installation Manual ring. If there is no hand ring, use the metal clip with the metal cable to clip the unpainted metal part of the machine box. In this case, the static is discharged to the ground through the metal cable of the clip.
  • Page 10: Power Requirements

    2.4 Installation Tools and Device The tools and devices to install the TSR 2800-10C router are not provided by the TSR 2800-10C router. You yourself need to prepare them. The following are the tools and devices needed for the typical installation of the TSR 2800-10C router: ...
  • Page 11: Chapter 3 Installing The Tsr 2800-10C Router

    TSR 2800-10C Hardware Installation Manual Chapter 3 Installing the TSR 2800-10C Router Caution: Only professionals are allowed to install or replace the devices. 3.1 Installation Flow of TSR 2800-10C 3.2 Installing the Machine Box of the Router The installation of the machine box has two modes: ...
  • Page 12: Installing The Machine Box On The Desk

    TSR 2800-10C Hardware Installation Manual 3.2.1 Installing the Machine Box on the Desk The TSR 2800-10C router can be directly put on the smooth and safe desk. Note: Do not put things weighing 4.5 kg or over 4.5 kg on the top of the router.
  • Page 13 RJ45 socket, whose pins can be aligned from left to right with the value from 1 to 8. Figure 3-1 Pin1 to Pin 8 Figure 3-2 Connecting the console port of TSR 2800-10C and computer Table 3-1 Pins of the console port...
  • Page 14: Connecting Gigabit Ethernet Ports

    One end of the cable is a RJ45 8-pin plug and the other end is a 9-hole plug (DB9). The RJ45 plug is put into the socket of the console port on TSR 2800-10C. The console cable is numbered as RLC0301.
  • Page 15: Connecting Gigabit Ethernet Optical Ports

    Sending/receiving the paraphase of the data 3 TP3- 3.3.3 Connecting Gigabit Ethernet Optical Ports TSR 2800-10C supports 2 gigabit Ethernet combo ports, which can connect with other switching devices by the optical fiber cables. See the following figure: - 13 -...
  • Page 16: Connecting To The Usb Interface

    TSR 2800-10C Hardware Installation Manual 3.3.4 Connecting to the USB Interface The USB interface supports the physical-layer protocol of USB2.0. The USB interface works in main mode, which can be plugged into the sub-device. - 14 -...
  • Page 17: Chapter 4 Maintaining Router

    TSR 2800-10C Hardware Installation Manual Chapter 4 Maintaining Router Caution: 1. Before opening the machine box, make sure that you have released the static you carried and then turn off the power on-off of the router. Before operating any step in Appendix B, read the section “Safety Advice”.
  • Page 18: Closing The Machine Box

    TSR 2800-10C Hardware Installation Manual Note: After taking off the cover, put it horizontally and avoid it to be crushed or collided. 4.2 Closing the Machine Box The section mainly describes how to put the cover and close the machine box. Do as follows: ...
  • Page 19: Chapter 5 Hardware Fault Analysis

    TSR 2800-10C Hardware Installation Manual Chapter 5 Hardware Fault Analysis The part describes how to remove the fault from the router. 5.1 Fault Separation The key for resolving the systematic faults is to separate the fault from the system. You can compare what the system is doing with what the system should do to detect the fault.
  • Page 20: Indicator Description

    TSR 2800-10C Hardware Installation Manual 5.2 Indicator Description The LED indicator shows that the router is running. The following table shows the indicators of the TSR 2800-10C router and their description: Abbrev. Name Description When the router is powered on, the Power indicator indicator is on.
