Sunmer FSB001 User Instruction

Garden swing chair
Hide thumbs

Advertisement

Quick Links

Download this manual
GARDEN SWING
CHAIR
THREE SEATS
WATERPROOF
ADJUSTABLE
CANOPY
CAN HOLD UP
TO 200KG
---------------------------------------------------------
EN
EN USER INSTRUCTION & OPERATION MANUAL
ES MANUAL DE INSTRUCCIONES Y OPERACIONES PARA EL USUARIO
DE BENUTZERANLEITUNG & BETRIEBSANLEITUNG
FR MANUEL D'UTILISATION ET D'UTILISATION
IT ISTRUZIONI PER L'USO E MANUALE OPERATIVO

Advertisement

loading
Need help?

Need help?

Do you have a question about the FSB001 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunmer FSB001

Summary of Contents for Sunmer FSB001

  • Page 1 GARDEN SWING CHAIR THREE SEATS WATERPROOF ADJUSTABLE CANOPY CAN HOLD UP TO 200KG --------------------------------------------------------- EN USER INSTRUCTION & OPERATION MANUAL ES MANUAL DE INSTRUCCIONES Y OPERACIONES PARA EL USUARIO DE BENUTZERANLEITUNG & BETRIEBSANLEITUNG FR MANUEL D'UTILISATION ET D'UTILISATION IT ISTRUZIONI PER L'USO E MANUALE OPERATIVO...
  • Page 2 Thank you for purchasing this SUNMER product. Please read the user manual carefully before using this product. We will update our instruction manuals if necessary. For the most up-to-date user manual, please visit our official website: www.nettadirect.com. You can download a copy of up to date user manuals at any time in electronic format.
  • Page 3 SAFETY & WARNINGS... INTENDED USE ASSEMBLY SUNMER products are for private and Time: 50 minutes residential use only. This product is not intended for use in public places such as People required: 2 hotels, sports grounds, etc. RISK OF PERSONAL INJURY •...

  • Page 4: Assembling The Product

    ASSEMBLING THE PRODUCT...
  • Page 5 • Slide part C into part B. • Attach together by inserting bolt Q (x2) into the holes provided and fix together with M6 washers (W) and M6 nuts (V) and tighten. • Attach nut cover (Z) when the hammock is fully assembled.
  • Page 6 • Attach the front leg (part A1) into the back leg (part A2) through the crossbar by inserting M6 bolts (U) through the holes in the three tubular parts as shown. • Fix together by using M6 washers (W) and nuts (V) and tighten. •...
  • Page 7 • Attach the side brace (part D) to the outside of the back leg by inserting bolt Q through the holes provided as shown. • Fix together by using M6 washer (W) and M6 nut (V) and tighten. • Repeat for the front leg and then do the same on the opposite side.
  • Page 8 • Slide the right rear brace (F) into the left rear brace (E) as shown. • Insert M6 bolt (T) through the holes provided and fix together using M6 washer (W) and M6 nut (V) and tighten. • Attach M6 nut cover (Z) when the hammock is fully assembled.
  • Page 9 • Attach the assembled rear leg brace from step 4 to the two back legs by inserting M6 bolt (S) through the holes provided as shown. • Fix together using M6 washer (W) and M6 nut (V) and tighten. • Repeat on the other side.
  • Page 10 • Attach the armrests (part I) to the front of the seat frame (J) by inserting M8 bolt (R) through the holes provided as shown. • Fix together by using M8 washer (W) and M8 washer (V) and tighten. • Repeat on the other side.
  • Page 11 • Attach one suspension tube (part G) to the front of the armrest by inserting M8 (R1) through the holes as shown. Fix together using M8 washer (W) and M8 nut (V) and tighten. • Attach the other suspension tube (part G) to the back of the armrest by inserting M8 bolt (R) through the holes shown.
  • Page 12 • Attach the seat frame to the main crossbars by inserting a spring (part P) through the holes provided in the two suspension tubes. • Repeat on the other side. • When the springs are attached on the two sides, gently lift the seat frame, and insert the springs through the metal loops on the crossbar.
  • Page 13 • Attach the canopy side tube (part K) to the crossbar by lining up the plastic bracket on the canopy side tube with the corresponding plastic part on the crossbar. • Fix together by inserting part Y and screwing into place. Use wingnut (Y1) to help tighten but do not overtighten.
  • Page 14 • Attach the fabric canopy over part M to the canopy straight tubes (part L) by inserting the tubes through the fabric tunnels on the underside of the canopy. • Insert each tube separately and gather the canopy cover into the centre of the tubes.
  • Page 15 • With the assistance of another person, lift the combined canopy cover and canopy straight tubes up and insert the straight tube into the canopy side tube as shown. • Repeat on the back. • When one side is complete, repeat on the other side of the hammock. •...
  • Page 16 • Fit the main seat and back cushions (part N) to the hammock seat by sliding the fabric flap on the back of the cushion over the back frame. • Attach the cushions to the seat frame using the ties provided. ASSEMBLY IS COMPLETE...
  • Page 17 CLEANING & MAINTANENCE • Only clean this swing chair using a damp cloth and mild detergent. Do not use bleach or abrasive cleaners. • From time to time, check that no screws are loose on this product. • This product should not be discarded with household waste. Contact your local authority for advice on how to dispose of this.
  • Page 18 SPARE PARTS/REPAIR We hope our products will last as long as possible to reduce the build-up of waste in the world. If any consumable parts need replacing, please check our website for stock availability and purchase. If our website does not have the parts listed, but you still need consumable parts, please contact our customer support to check availability and process your order.

  • Page 19: Disposal Of Product

    DISPOSAL OF PRODUCT IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. DISPOSAL: Please dispose of this product responsibly. This item cannot be disposed of with general waste. Please contact your local council authority for more information on how to dispose this product.

  • Page 20: Your Warranty

    YOUR WARRANTY If you purchased with NETTADIRECT, or one of our authorised resellers, you will automatically enrol your warranty for 1 (ONE) year. You do not need to register again for your warranty. All warranties will be carry out our terms and conditions include warranty conditions you will find out from our website at www.nettadirect.com.
  • Page 21 COPYRIGHTS SUNMER is a part of the NETTA brand. NETTA and its logo including images and contents in this manual and website is copyrighted. All intellectual property rights belong to NETTA owner CONSUMABLE DIRECT LIMITED. ANY UNAUTHORISED USE, MODIFICATION or DISTRIBUTION of the NETTA logo, website image, and its contents (from website, manuals) will violate worldwide copyright, trademark, and associated laws.
