Summary of Contents for Holland Green Science Aeolus 10209001
- Page 1 User Manual 10209001 Aeolus Vacuum Controller User Manual Version 1.0...
-
Page 2: Table Of Contents
User Manual Table of Contents I. LIMITED WARRANTY & DISCLAIMER ................. 3 II. Safety ............................ 7 III. Introduction ......................... 8 IV. Technical Specifications ....................9 V. Inspection..........................10 VI. Operating Instructions ......................11 VII. Fault Diagnosis.........................18 VIII. Maintenance and Cleaning ....................19 Version 1.0... -
Page 3: Limited Warranty & Disclaimer
User Manual I. LIMITED WARRANTY & DISCLAIMER • The intellectual property rights for this manual belongs to Holland Green Science Corporation (hereinafter referred to as “the Company”). • Products of the company are under the patent protection of China and other countries and regions (inclusive of obtained patents and patents currently under application). - Page 4 User Manual Company's review, the Company will provide Buyer with service data and/or a Return Material Authorization ("RMA"), which may include biohazard decontamination procedures and other product-specific handling instructions, then, if applicable, Buyer may return the defective Products to the Company with all costs prepaid by Buyer. Replacement parts may be new or refurbished, at the election of the Company.
- Page 5 User Manual WHETHER EXPRESS OR IMPLIED, ORAL OR WRITTEN, WITH RESPECT TO THE PRODUCTS, INCLUDING WITHOUT LIMITATION ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE OR USE. THE COMPANY DOES NOT WARRANT THAT THE PRODUCTS ARE ERROR-FREE OR WILL ACCOMPLISH ANY PARTICULAR RESULT.
- Page 6 User Manual LIMITATION OF LIABILITY NOTWITHSTANDING ANYTHING TO THE CONTRARY CONTAINED HEREIN, THE LIABILITY OF THE COMPANY UNDER THESE TERMS AND CONDITIONS (WHETHER BY REASON OF BREACH OF CONTRACT, TORT, INDEMNIFICATION, OR OTHERWISE, BUT EXCLUDING LIABILITY OF THE COMPANY FOR BREACH OF WARRANTY (THE SOLE REMEDY FOR WHICH SHALL BE AS PROVIDED UNDER THIS SECTION) SHALL NOT...
-
Page 7: Safety
User Manual II. Safety ! DANGER (may cause serious damage to property and or casualties) 1. Please carefully read this User Manual prior to operating the instrument and observe the instructions on safe operation. 2. The power source must be grounded reliably and away from any sources of electromagnetic interference. -
Page 8: Introduction
User Manual III. Introduction The instrument is intended to control the vacuum level of a vacuum system with gas as the medium in non-residential environments such as schools, laboratories and or factories. Environment requirements are as follows: • Voltage fluctuation does not exceed nominal value by ±10%. •... -
Page 9: Technical Specifications
User Manual IV. Technical Specifications Model 10209001 Product Name Aeolus Control Range 1-1000mbar Measurement Range 1-1000mbar Single-point control operation mode, program operation Control Operation Modes mode Up to 5 Programs. Control Program Each program contains five-step control (vacuum degree and time can be set). Interface Touch Screen setting Display Screen... -
Page 10: Inspection
User Manual V. Inspection Packing List Unpack the equipment carefully and check for any damage which may have arisen during transport. In the event of identified damage, please contact serviceusa@hollandgreenscience.com The package includes the following items: Item Description. Quantity. Main Unit Power Cable Quick Setup Card Note:... -
Page 11: Operating Instructions
User Manual VI. Operating Instructions 1. Overview Application Connector Touch Screen Three-in-One Switch Power Output Pump Socket Connector Air Vent Name Description Setting parameters and displaying settings Touch Screen and operation information Three-in-One Unit power input, with a switch controlling Switch the power supply to the entire unit. - Page 12 User Manual 2. Instrument Preparation • Place the instrument on a stable and well-ventilated surface, clear of flammables or explosives. • Ensure the instrument voltage matches the power supply voltage before connection. • Ensure that the power socket is grounded properly. •...
- Page 13 User Manual 4. Instrument Configuration Press the ‘SETTINGS’ button to display the ‘PASSWORD SOFT KEYBOARD’, enter the password. The default initial password is 6666, then press ‘ENTER’, confirm the password is correct and then ‘SETTING INTERFACE’ displays Name Function Pump Delay (ms) The delay time after ‘opening or closing’ the vacuum pump. The delay time after ‘opening or closing the solenoid valve Valve Delay (ms) (inside the instrument).
- Page 14 User Manual 5. Operating Mode - Selection and Configuration Press the ‘PROGRAM’ button to display the ‘Program Selection Interface’ 5.1 Single-Point Control Operation Mode Press ‘VACUUM CONTROL’ refresh the current page Name Function Set Vacuum Set the vacuum value within a range of 1 - local atmospheric pressure (mbar) (P0) Hysteresis value affects the pressure fluctuation range and...
- Page 15 User Manual Note: The larger the hysteresis value set, the larger the pressure fluctuation, the smaller the hysteresis value set, the smaller the pressure fluctuation and the more frequently the vacuum pump starts up and shuts down. The recommended hysteresis value is set at 10mbar. Note: The sum of the set vacuum value and hysteresis value cannot exceed (P0-10) mbar and the set vacuum value is larger than the hysteresis...
- Page 16 User Manual 5.2 Program Operation Mode Press ‘VACUUM CONTROL’ button to display the ‘Program Selection Interface’ Figure 8. Figure 8. Name Function Open Select the program number Hysteresis value affects the pressure fluctuation range and the Hysteresis ‘ON’ frequency of the vacuum pump (mbar) Setting range 1-300mbar After setting the parameters, press the ‘OK’...
- Page 17 User Manual 5.3 Program Editing Press the ‘Edit’ button in the ‘Program Selection Interface’ to display the ‘Program Editing Interface’ Program Editing Area Program No. Selection Button Name Function Sequence No. of program execution Time (min) Timing, set within a range of 0-5999min Set the vacuum value within a range of 1 - local atmospheric Vac (mbar) pressure (P0)
-
Page 18: Fault Diagnosis
User Manual VII. Fault Diagnosis. Cause Analysis Solution Fault Check the power switch Switch the vacuum on the vacuum pump is pump, power switch The vacuum pump ‘ON’. ‘ON’. does not work. Check the power cable Connect the cable. connection. Error message displays when Check whether the SET... -
Page 19: Maintenance And Cleaning
User Manual VIII. Maintenance and Cleaning Keep the instrument dry and clean in routine operations. Clean the outer surface with a non-abrasive cleanser and only connect the power supply when the entire instrument surface is dry. If liquid or moist solids enters the instrument, please immediately disconnect the power supply and contact supportusa@hollandgreenscience.com •...
