- Page 1 OUTDOOR BBQ RANGEHOOD INSTRUCTION & INSTALLATION MANUAL CXWB12062 CXWB12082 CXWB14802 CXWB14802 ISLAND IMPORTANT: Read and save these instructions and keep with proof of purchase.
- Page 2 Page | 2...
-
Page 3: Table Of Contents
BALCONIES & VERANDAS PAGE 9 SUPPLIED MATERIALS PAGE 10 RANGEHOOD INSTALLATION DUCT MOUNTING OPTIONS PAGE 11 DUCTING CALCULATIONS PAGE 12 INSTALLING CXWB12062 & CXWB12082 PAGE 13-14, 17 INSTALLING CXWB14802 PAGE 15-16,17 INSTALLING CXWB14802 ISLAND PAGE 18-21 RANGEHOOD OPERATION PAGE 22-23 CLEANING... -
Page 4: Trouble Shooting
TROUBLE SHOOTING 1.THE RANGE HOOD VIBRATES WHEN THE FAN IS ON: The range hood might not have been secured properly on to the wall or ceiling. Contact your installer to check the Range hood. 2.I HAVE NO POWER TO MY RANGE HOOD. THE FANS ARE NOT TURNING ON AND THE LIGHTS DO NOT WORK. -
Page 5: Warranty Terms & Conditions
If outside the metro area, there may be additional travel charges for the warranty repair. The Excelsior Range Hood is covered by a 24 month warranty for parts failure. If the range hood is not installed by a qualified installer, the warranty may be revoked. The warranty does not extend to installation faults or disconnection costs. - Page 6 WARRANTY TERMS AND CONDITIONS TO ENQUIRE ABOUT CLAIMING UNDER THIS WARRANTY, PLEASE FOLLOW THESE STEPS: (a) carefully check the operating and installation instructions, troubleshooting, and the terms of this warranty; (b) have the model and serial number of the appliance available; (c) have the proof of purchase (e.g.
-
Page 7: Important Information
IMPORTANT INFORMATION Read all instructions before installing and operating this Rangehood. This Rangehood is designed for use above an outdoor domestic gas (propane/natural) barbecue. This manual is intended for qualified installers, service technicians or persons with similar qualified backgrounds. Incorrect installation is not covered under warranty. DO NOT attempt to install this appliance yourself. -
Page 8: Installation Preperation
INSTALLATION PREPERATION WHAT IS AN OUTDOOR AREA An outdoor area is an open-air situation that is not obstructed by buildings, structures etc, facilitating correct combustion and allowing products of combustion to be readily dispersed to atmosphere. An alfresco area, veranda or balcony (large area) is considered outdoors when it is an open-air situation with natural ventilation. -
Page 9: Balconies & Verandas
INSTALLATION PREPERATION BALCONIES & VERANDAS An outdoor range hood may be installed and used on a balcony or veranda if, by location and use, it will not cause a hazard and the manufacturer’s instructions allow for such use. It may also be necessary to consult local building laws before installing or using a gas barbecue on a balcony or veranda. -
Page 10: Supplied Materials
INSTALLATION PREPERATION SUPPLIED MATERIALS CXWB12062 & CXWB14802 ITEM CXWB14802 CXWB12082 ISLAND RANGEHOOD WITH DUCT ADAPTORS FITTED TO EACH MOTOR 400MM HIGH FLU COVERS CHIMNEY MOUNTING BRACKET ROOF MOUNTING BRACKET SEMI RIGID 150MM DUCTING HARDWARE TO ATTACH BRACKETS REQUIRED FOR USE Accessible power pointed fitted within 1m of range hood mounting position. -
Page 11: Rangehood Installation
RANGEHOOD INSTALLATION DUCT MOUNTING OPTIONS You will need some additional parts to complete these installations. All motors need to be ducted individually and the included semi rigid ducting is 150mm diameter. If ducting at the rear or via the Soffit/Eave please review page 12 for reduction in ducting requirements The ideal position of the Rangehood is as follows: 1. -
Page 12: Ducting Calculations
DUCTING All motors need to be ducted individually to ensure air flow and suction is adequate and meets all regulations. CXWB12062 and CXWB12082 – 2 Ducts 150mm Ø CXWB14802 and CXWB14802 ISLAND – 3 Ducts 150mm Ø DUCT RUN CALCULATIONS If installation of ducts is not straight up vertically please ask the licensed installer to use the following as a guide. - Page 13 1. Using a tape measure mark the centre hole (A) on your wall. This mark should be in the centre of your cooking surface and 1636.8mm (CXWB12062) and 1686mm (CXWB12082) above your cooking surface.
- Page 14 CXWB12082 RANGEHOOD Page | 14...
-
Page 15: Installing Cxwb14802
RANGEHOOD INSTALLATION INSTALLING – CXWB14802 RANGEHOOD WALL BRACKET Note: Bracket must be level, if not range hood will not operate correctly. 1. Using a tape measure mark the centre bottom hole (A) on your wall. This mark should be in the centre of your cooking surface and 1685mm above your cooking surface. - Page 16 Page | 16...
-
Page 17: Installing Cxwb12062 & Cxwb12082
RANGEHOOD INSTALLATION INSTALLING – CXWB12062 , CXWB12082, CXWB14802 RANGEHOOD DUCTING 1. Remove all tape from the ducts butterfly valves and ensure they move up and down freely. 2. Position the butterfly valves up. 3. Position the ducting over the top of the collection box and butterfly flaps. Use duct tape to secure semi rigid ducting. -
Page 18: Installing Cxwb14802 Island
RANGEHOOD INSTALLATION INSTALLING – CXWB14802 ISLAND CEILING MOUNT CEILING BRACKET Note: Bracket must be level. If not Range hood will not operate correctly. 1. Using a plumb bomb mark on the ceiling the centre of your cooking surface. 2. Place the ceiling bracket on the ceiling. Ensure the sides and front are level with your cooking surface and that it is centre of the cooking surface. - Page 19 RANGEHOOD INSTALLATION INSTALLING – CXWB14802 ISLAND CEILING MOUNT RANGEHOOD WARNING: VERY HEAVY 2 PERSON LIFT. 1. Using nuts and bolts attach 1 angle bracket to each corner of the range hood motor box. 2. Slide the 2 flue surrounds over the top of the 4 angle brackets and onto the range hood body. Note: The inner flue surrounds attach to the holes at the top of the ceiling bracket.
- Page 20 RANGEHOOD INSTALLATION DUCTING 1. Remove all tape from the ducts, butterfly valves and ensure they move up and down freely. 2. Position the butterfly valves up. 3. Position the ducting over the top of the collection box and butterfly valves. 4.
- Page 21 Page | 21...
-
Page 22: Rangehood Operation
RANGEHOOD OPERATION CONTROL PANEL SPEED SPEED LIGHTS TIMER POWER DOWN BUTTON FUNCTION SET: Use to set the Time Press to decrease the fan speed and to decrease minutes for the Timer. SPEED DOWN: SPEED UP: Press to increase the fan speed and to increase minutes for the Timer. Displays the fan speed setting, Time and Timer DIGITAL SCREEN: LIGHT :... -
Page 23: Cleaning
RANGEHOOD OPERATION FAN SPEED The Range hood has 3 fan speed settings, Low Medium and High. To increase the fan speed press the SPEED UP button. To decrease the fan speed press the SPEED DOWN button until desired setting is reached. REMOTE CONTROL POWER Press to turn range hood on and off LIGHTS Press to turns lights on and off... -
Page 24: Specifications
Note: Stainless Steel baffle filters are a consumable product and are not replaced under warranty. You can purchase replacement filters by contacting the Distributor. SPECIFICATIONS CXWB14802 Description CXWB12062 CXWB12082 CXWB14802 ISLAND 316 Marine Grade Stainless Steel Body 1200W x 600D... - Page 25 CXWB12062 CXWB12082 Page | 25...
- Page 26 CXWB14802 CXWB14802 ISLAND Page | 26...
- Page 27 For any queries or assistance call Customer Service (Australia Only) 1300 174 876 Hours of operation: Monday to Friday 8am - 5pm EST IMPORTANT: RETAIN THESE INSTRUCTIONS FOR FUTURE USE. Excelsior is a trademark of Sitro Group Australia www.excelsiorproducts.com.au...
