Item #s CSPPD704、CSPPD705
READ AND FOLLOW ALL INSTRUCTIONS IN THIS OWNER'S
MANUAL AND ON EQUIPMENT.
This equipment must be installed and serviced by a qualified technician or professional,
in accordance with the National Electrical Code and all applicable local codes and
Ordinances. Improper installation can create electrical hazards which could result in
property damage, serious injury or death. Improper installation will void the warranty.
Notice to Installer
This manual contains important information about the installation, operation and safe
use of this product. Once the product has been installed this manual must be given to
the owner/ operator of this equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSPPD704 and is the answer not in the manual?

Questions and answers

Related Manuals for CIPU CSPPD704

Summary of Contents for CIPU CSPPD704

  • Page 1 Pool Pumps Item #s CSPPD704、CSPPD705 READ AND FOLLOW ALL INSTRUCTIONS IN THIS OWNER’S MANUAL AND ON EQUIPMENT. This equipment must be installed and serviced by a qualified technician or professional, in accordance with the National Electrical Code and all applicable local codes and Ordinances.
  • Page 2 Water temperature in excess of 100° F (37.7° C) may be hazardous to your health. Prolonged immersion in hot water may induce hyperthermia. Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above normal body temperature of 98.6° F (37° C.). Effects of hyperthermia include: (1) Unawareness of impending danger.

  • Page 3: General Safety Rules

    WARNINGS AND IMPORTANT SAFETY PRECAUTIONS SUCTION ENTRAPMENT HAZARD Hair Entanglement – When the hair tangles or knots in the drain cover, trapping the swimmer underwater. This hazard is present when the flow rating of the cover is too small for the pump or pumps.

  • Page 4: Installation

    8. The operating safety of the pump is only guaranteed if the installation and service instructions are correctly followed. 9. The limit values stated in the technical table should not be exceeded under any condition. 10. In the event of defective operation or fault, contact the technical support department of the manufacturer or it’s nearest authorized agents.
  • Page 5 in accordance to the local codes. 6. The motor must be grounded. 7. The weight of the plumbings and fittings is to be independently supported and not carried by the pump. 8. The maximum total head (Hmax) of the pump (in metres) shown on the pump label should be noted by the installer.

  • Page 6: Maintenance

    ENSURE that all suction and discharge valves are open before you start the pump, otherwise that all suction and discharge valves are open before you start the pump, otherwise that all suction and discharge valves are open before you start the pump, otherwise will result in damage to the pump.
  • Page 7 In climates where the pump may be exposed to frost or freezing, care must be taken to ensure the pump is protected from damage. It is recommended that if the pump is not used during winter period it should be drained completely and store pump in a dry location. Do not replace the drain plug.

  • Page 8: Technical Data

    If supplementary instructions are required or special problems arise, do not hesitate to contact the distributor/agent. TECHNICAL DATA Item CSPPD704 CSPPD705 Input Power 816w 1072w H.

  • Page 9: Illustrated Parts List

    O-Ring 65028003000 Seal Assembly 647284803 Pump Housing 647284804 Motor Mounting Plate 65231016106 Nut M5 65023404000 Dual Speed 1.0HP Motor For CSPPD704 65023405000 Dual Speed 1.5HP Motor For CSPPD705 65432002080 Drain Plug Gasket 648860105 Drain Plug 647202702 Adaptor 91382005 1.5’’ Adaptor Assembly...

  • Page 10: Troubleshooting

    TROUBLESHOOTING Problem Cause Solution Low flow Dirty filter Backwash or clean cartridge Dirty skimmer and pump Clean skimmer and pump strainer strainer Suction air leak Make sure water level is correct through suction points. Ensure baskets and strainers are free of debris. Tighten all fittings/unions on the suction side of the pump, remove and replace mechanical seal...
  • Page 11 operation Air leak in suction Make sure water level is correct through suction points. Ensure baskets and strainers are free of debris. Tighten all fittings/unions on the suction side of the pump, remove and replace mechanical seal Suction blockage Locate and clean blockage Disturbance in impeller Contact supplier Cavitations...
