Traverse Wall Assembly Instructions

Thank you for purchasing Elevate Climbing Walls's Traverse Wall Kit. The kit comes complete

with eight 4 ft x 4 ft climbing panels, 47 climbing holds, a color coordinated border, and

installation screws for the border and mounting of the panels. If you have questions during

assembly, feel free to call us or email us at contact@elevateclimbingwalls.com. We are happy to

help.

Materials and Tools needed:

Not include in Kit

Ten 2x4 wood studs at 8 ft length (or five at 16 ft each)

Drill/driver

70 timber lock fasteners (5-inch length) to secure 2x4 to existing wall (NOTE: may not

be needed if attaching to concrete wall, etc.)

Padding (we recommend 4" padding that extends at least four feet outward from the

traverse wall.)

Included in Kit:

100, 2 in deck screws to fasten panels and border to mounting surface (2x4s)

Bit for deck screws

Hand holds

Hand hold wrench

Border (eight 4 ft pieces, with two being slightly longer than the others)

The climbing wall must be mounted to a framed wall formed of 2x4 wood studs (or

stronger, e.g., 2x6 studs) at 16" on center. The climbing wall may be mounted to

concrete walls or other structural walls (e.g., CMU, steel studs, etc.) possibly using other

hardware.

We assume the framed wall to be covered with dry wall and to include insulation.

Therefore, we recommend mounting wood 2x4s in a horizontal orientation and on the

3.5" side against the drywall. This will create a 1.5" air gap behind the panels when they

are mounted in this way leaving room for the hand hold bolts to project through the

panels after installation of the hand holds.

The final climbing wall with the board is 16 ft 2 in long and 8 ft 1 in tall. The traverse

wall can be placed in a corner of a room, with one side being 4 ft and the other side

extending 12 ft or both sides being 8 ft in length.

Elevate Climbing Walls, LLC | 18870 72

Ave S | Kent, WA 98032 | 206-641-9119

18870 72

Ave S

Kent, WA 98032

206-641-9119

Table of Contents

Do you have a question about the Traverse Wall and is the answer not in the manual?

Page 1 Made in the USA Traverse Wall Assembly Instructions Thank you for purchasing Elevate Climbing Walls’s Traverse Wall Kit. The kit comes complete with eight 4 ft x 4 ft climbing panels, 47 climbing holds, a color coordinated border, and installation screws for the border and mounting of the panels. If you have questions during assembly, feel free to call us or email us at contact@elevateclimbingwalls.com.
Page 2 Note: The middle horizontal stud will be overlapped by both the top row of panels and the bottom row of panels of your traverse wall and will be used to secure all panels. The other studs should terminate flush with the edges of the panels (be hidden once panels are attached).
Page 3 Step 6: Install padded flooring We recommend 4” padding for a traverse wall that is up to 8 ft tall. If you left a space for the padding under the climbing wall, push the padding slightly under the climbing wall for a secure and clean looking fit.
