Skinny DRAUGHT User Manual

SKINNY DRAUGHT
SET UP GUIDE
1. FIT THE TAP
3. CONNECT THE KEG COUPLER
(USUALLY ARRIVES ATTACHED)
Connect the blue air
tube to the bottom
of the coupler.
5. PREPARE THE UNIT FOR USE
a) Plug the unit into the mains.
b) Turn the cooling on.
c) Switch the air compressor
on using the switch on the
back of the unit.
Add the drip tray.
Tighten the tap
(counter-clockwise)
using the C Spanner.
Screw the
handle on
to the tap.
Connect the clear
beer tube into the
top of the coupler.
2. CONNECT THE TUBING
Connect the plastic
push fitting into the air
compressor outlet, then
connect the blue air tube.
4. CONNECT THE COUPLER TO THE KEG
IMPORTANT
a) First ensure the
handle on the coupler
is pulled up.
b) Insert the coupler
into the top of the keg
and turn clockwise.
6. ENJOY SKINNY LAGER & IPA
Wait a few minutes
for the beer to chill,
then pour yourself the
perfect pint.
Connect the clear
beer tube into the
beer inlet.
c) Press down
on the handle
to lock.
Adjust flow
if required.
