Instructions manual
02031
Supplementary Due Fili power supply unit with 28 V d.c. 15 VA output,
power supply 230 V~ 50 Hz, installation on DIN rail (60715 TH35),
occupies 4 modules of 17.5 mm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the by-me 02031 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vimar by-me 02031

  • Page 1 Instructions manual 02031 Supplementary Due Fili power supply unit with 28 V d.c. 15 VA output, power supply 230 V~ 50 Hz, installation on DIN rail (60715 TH35), occupies 4 modules of 17.5 mm...
  • Page 2: Technical Characteristics

    Description - Technical Characteristics - Installation 1. DESCRIPTION The supplementary power supply unit art. 02031 is to be used in Due Fili systems to power electronic entrance panels and video door entry units to support the main power supply unit art. 02030. For video door entry units use the output terminals “-”...
  • Page 3: Installation

    Installation Table for audio and video door entry systems in a building complex with 1 or more entrance panels in parallel. For the entrance panels at the foot of the stairs, the audio and video door entry units of the buildings see Tab. 1. Number of video panels Number of power supply units art.
  • Page 4: Connection Diagrams

    Connection diagrams 4. CONNECTION DIAGRAMS BUS TERMINATION FOR DUE FILI SYSTEMS This note applies to all devices with Due Fili technology equipped with a “BUS termination connector”, identified on the electronic card with the printing “ABC” and marked on the connection diagrams with * . A jumper must be inserted in this connector in order to be able to adjust the video signal. The rule to follow for correct line adjustment is: •...
  • Page 5 Connection Diagrams VIDEO DOOR ENTRY SYSTEM WITH 4 ENTRANCE PANEL AND TWO POWER SUPPLY ART. 02031. B - VIDEO DOOR ENTRY UNIT D - ENTRANCE PANEL Art. 02001 - 02003 F - POWER SUPPLY Art. 02030 G - POWER SUPPLY Art. 02031 J - RELAY Art.
  • Page 6 Connection diagrams VIDEO DOOR ENTRY SYSTEM WITH MORE THAN 2 SINGLE FAMILY VIDEO DOOR ENTRY UNITS AND POWER SUPPLY ART.02031 D - ENTRANCE PANEL Art. 02001 Art. 02037 F - POWER SUPPLY Art. 02030 20550 + 01963 G - POWER SUPPLY Art. 02031 oppure K - LANDING CALL BUTTON G - Art.
  • Page 7 Connection Diagrams VIDEO DOOR ENTRY SYSTEM WITH 4 ENTRANCE PANEL, MORE THAN 2 SINGLE VIDEO DOOR ENTRY UNITS AND POWER SUPPLY ART.02031 Art. 02037 D - ENTRANCE PANEL Art. 02001-02004 F - POWER SUPPLY Art. 02030 G - Art. 02031 20550 + 01963 G - POWER SUPPLY Art.
  • Page 8: Installation Rules

    Installation Rules - Standard Compliance 5. INSTALLATION RULES Installation should be carried out in compliance with the current regulations regarding the installation of electrical systems in the country where the products are installed. - Carefully read the instructions given in this document as they provide important information on safety for installation, use and maintenance. - After removing the packing, check the integrity of the appliance.
  • Page 10 Viale Vicenza, 14 I 36063 Marostica VI Tel. +39 0424 488 600 Fax +39 0424 488 188 49400240A0EN 01 1008 http://www.vimar.eu VIMAR - Marostica - Italy...
