GENEVO PRO II
U S E R + I N S T A L L A T I O N M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GENEVO PRO II

Summary of Contents for GENEVO PRO II

  • Page 1 GENEVO PRO II U S E R + I N S T A L L A T I O N M A N U A L...

  • Page 2: Advanced Features

    MAIN FEATURES reported verbally, such as “section OF GENEVO PRO II: speed cameras”. ADVANCED FEATURES: GENEVO PRO II is our most advanced built-in radar detector, • A magnetic display, easily remov- with modern automatic features. able for instant deactivation of the system.
  • Page 3 therefore necessary to have the only if absolutely necessary, as it shortens the detection distance detector set up correctly for each and increases the number of country. false alerts. • Ka: One of the most common- ly used radar band for speed Filters and false alerts: For the measuring.

  • Page 4: Home Screen

    CONTROL HOME SCREEN: Brightness Increase control the volume Decrease the volume Short press: Main menu Short press: Long press: Turn off Sensitivity setting Long press: Add a custom point MAIN MENU: Move the menu left Move the menu right Short press: Enter the submenu Long press: Return to the home screen...

  • Page 5: Setting Submenu

    SETTING SUBMENU: Currently selected item to edit Change Move the item menu up value Move the Change menu item down value Short press: Return to main menu Long press: Return to the home screen DURING ALERT: Hand gesture, or short press of any button will silence the alert Any button will lockout false alert location when long pressed...

  • Page 6: Main Menu Items

    MAIN MENU ITEMS USER INTERFACE SETTINGS: DISPLAY: Setting the information displayed on the right side of the display: • TIME 24H - Displays time in 24h format. • VOLTAGE - Displays the battery voltage. • COMPASS - Displays driving direction. •...
  • Page 7 Deletes all false alert locations (lockouts). ALERTS NOTIFICATION SETTINGS: FRONT RADAR: ON/OFF REAR RADAR: ON/OFF (Turn on only when your GENEVO PRO II is equipped with additional second radar Antenna) SENSITIVITY: HIGHWAY - Maximum detector sensitivity. CITY - Reduced sensitivity. We recommend using the reduced sensitivity only in the case of frequent alerts on a certain band (e.g.
  • Page 8 New Firmware updates add detections of new types of radars, all supported radars, recommended settings and more information can be found at genevo.com/radars_en * These radars can only be detected and are only available in the menu when a GENEVO HDM+ antenna is connected.
  • Page 9 Sets the protection time of the optional laser ac- cessory. With the “DETECT ONLY” option you will be only informed about laser measurement by connected laser accessory or by the PRO II radar antenna if no accessory is connected. LASER NAME: OFF/NO VOICE/VOICE When ALP is selected.
  • Page 10 5 seconds. To deactivate the speedmeter function, it is necessary to update the detector in the usual way and all functions will be fully func- tional again, for help with updating continue to page 15. GENEVO PRO II CONTROL UNIT DIAGRAM: Power Laser module...
  • Page 12 A) GENEVO PRO II CONTROL UNIT The Control Unit is usually placed in a fuse box, or in a space above pedals, using a strip- ping tape, or double-sided sticky tape. For connecting individual components follow the markings on the control box. All can be easily done thanks to plug-in connectors.
  • Page 13 The laser system control unit is installed in the interior of the vehicle, either under the dashboard or someplace similar to the GENEVO PRO control unit. The only important thing is that the control unit must not get into contact with water. Connect the control unit power cord to the control unit using the dedicated pins.

  • Page 14: Database Update

    After the laser system control unit is connected to the GENEVO PRO control unit, connect the sensors into one of the “F” slots for front sensors, or “R” slots for rear sensors. In case you use multiple sensors connect into the dedicated slots.

  • Page 15: Operating Frequency

    Directive 2014/53/EU. The full Declaration of Conformity canbe downloaded here: enevo.com/en/ce-pro.pdf HOMOLOGATION GENEVO PRO was grated a homologation of a type of electrical / electronic sub- assembly with regard to Regulation No. 10., find the full approval here: genevo.com/en/pro-homologation.pdf...
  • Page 16 2022-05-10 Manufacturer: GENEVO s.r.o., Radčina 497/22, Liboc, 161 00, Praha 6...
