Congratulations and thank you for purchasing a Maverick Camper Trailer or Hybrid Caravan. You are now part of the Maverick Family. We are a passionate group of enthusiasts who love the great outdoors and offer our customers an incredibly special product to make your journey through our beautiful country stylish and comfortable with the confidence of being engineered to handle any obstacle or challenge.
This manual is a guide to the operation and maintenance of your Camper or Caravan. Caravans sold by Maverick Campers are available in several sizes and models, so accessories and components may differ. Some equipment described in this manual may not apply to your camper or caravan. If you find the components vary significantly from what is described, contact your branch to ensure you have the correct information.
HOW TO CHARGE YOUR BATTERIES VIA THE CHARGER ....................25 projecta 1000w modified sine wave inverter ....................... 26 160w solar blanket ................................ 28 Maverick campers external hot water system ......................29 bluetooth stereo/dvd/mp3 player ..........................30 19inch hd tv unit ................................31 onboard hot water systems ............................
Page 5
MAINTAINING YOUR CAMPER .............................. 84 TORQUE SETTINGS ................................ 84 ELECTRIC BRAKES ................................84 BATTERY CARE ................................85 Chargers & Inverters ..............................86 Gas & Water Systems ..............................86 WHEEL BEARINGS................................87 SHOCK ABSORBERS ............................... 87 SUSPENSIONS ................................88 Maverick Campers Operations Manual 2021...
Page 6
PRE-HOOK UP ................................95 PRE-HOOK UP ................................95 manufactures operating manuals ............................96 dometic stove manual..............................96 tRUMA 14L HOT WATER SYSTEM USER MANUAL ......................96 duoetto hot water system ............................96 dometic internal toilet manual ............................. 96 Maverick Campers Operations Manual 2021...
O W N E R ' S R E S P O N S I B I L I T I E S To get the most out of your Maverick Campers camper trailer or hybrid caravan it is incredibly important to regularly maintain and care for your van or trailer.
I O N S As an owner of a Maverick Camper or Hybrid you can breathe easy knowing you have purchased a high-quality product backed by one of the best warranties in the industry. Your trailer or van comes with several types of warranties to provide you with peace of mind.
At your Handover Appointment you will receive either a hardcopy of this manual or a USB Key which contains this and other useful documents to assist you with getting the best out of your Maverick Camper product. The Handover Pack given to you when picking up your camper or caravan contains original equipment Manufacturer (OEM) Operator manuals, the signed Hand Over Checklist, information about warranty and registrations.
Observe and note all operating instructions and all safety labels within your camper or caravan. You must follow these instructions for your own safety, and the safety of others. Please call your Maverick Campers branch or if you are unsure how to proceed. Always use the appropriate safety gear when servicing or maintaining your camper/caravan.
S A F E T Y F E A T U R E S All Maverick Campers Trailers and Vans include safety features to protect lives and your trailer or van from serious damage. B R E A K S A F E A device that links your trailer or van to your car via a lanyard.
This particularly the case on uneven surface with a heavy trailer or van. You should avoid releasing the hand brake until you are hitched to your car or you have wheel chocks in place to avoid the van or trailer rolling away uncontrollably. Maverick Campers Operations Manual 2021...
We use the following fire extinguisher usually or an equivalent: MEGAFire 1.0kg ABE Portable Fire Extinguisher - Nozzle Maverick Campers Operations Manual 2021...
(not the hitch), crossing them under the trailers tongue. Inspect the length of the chains once attached to the tow vehicle frame. They should be long enough to allow for turns, but short enough to avoid any drag. Maverick Campers Operations Manual 2021...
E L E C T R I C B R A K E S A N D I N D E P E N D E N T S U S P E S I O N These two features combined represent the strength and safety that Maverick Campers are famous for. The...
S T A N D A R D F E A T U R E S All Maverick Camper models whether van or trailer have these important features to make your travelling experience second to none. Below is a list of standard features you can expect to see in your model.
C O N T R O L P A N E L Every Maverick Campers model has a control panel to allow you to control the features of your model but also ensure you conserve battery power. Control Panels will vary from model to model depending on what equipment and features are included. Here are a...
E X T E R N A L 1 2 V F R I D G E S T O R A G E & S L I D E All Maverick Camper trailers and vans come with an extra large external fridge storage & slide compartment. This allows you to fit up to a 96L 12v Fridge which can be easily accessed via the heavy duty fridge slide.
Page 19
Also be mindful of water crossings as they can lead to damage to the fridge if the water is high enough and the vehicle is stationary for long enough for water to seep into the compartment. Always ensure your seals are in good condition and you have adjusted the locking clamp bolts to ensure a good seal. Maverick Campers Operations Manual 2021...
Cutlery and utensil storage Water drainage plumbing Wind guard Benchtop space for chopping and meal preparation LED flexible lighting Storage for gas and water hosing and electrical power lines Drainage racking for drying dishes and storing kitchen items Maverick Campers Operations Manual 2021...
Page 21
This allows you to use the water faucet above the sink. The faucet will only function when the water pump power switch is in the on position on the power control panel. Maverick Campers Operations Manual 2021...
Page 22
For more information on the dometic range of kitchen stoves, please see the link below: dometic-hbg-2370_9600027607_82656.pdf https://epi.dometic.com/externalassets/dometic-hbg-2370_9600027607_82656.pdf Maverick Campers Operations Manual 2021...
– with multiple height options, a highly manoeuvrable trailing yoke design, different yoke locking positions, Maverick Campers proudly includes an Ark XO on every model. Thoroughly tested and continually improved, the XO Series Jockey Wheels have fast become a standard within the camper trailer and caravan industry.
From the solar blanket during day light hours Both methods ensure you get the most out of your camper trailer or van by giving your batteries charge when you are traveling or at your destination. Maverick Campers Operations Manual 2021...
30amp in size) For solar blankets on Hybrids or Campers – Connect the solar blanket to the Anderson plug located on the a frame of the trailer or van. The charger will handle the unregulated power and convert it into regulated 12v power to charge your batteries.
I N V E R T E R Most Maverick Camper models come fitted with a Projecta Inverter as part of the options pack. The inverter converts 12v DC power into 240v AC power to run household appliances whilst off-grid or remote. The types of appliances that...
Page 27
Campers. We also offer high wattage inverters up to 3000 watts allowing almost any appliance to operate when off- grid. Please contact your Maverick Campers showroom for more information or call us directly on 1300 XXXXX IMPORTANT SAFETY AND USAGE INFORMATION: Inverters can be extremely dangerous if mis-used or tampered with.
We offer our customers a highly effective solution for providing hot water to both your external kitchen faucet and for showers. The Maverick Campers hot water system is a stand alone product with its own pump and heating element. The system works by connecting the unit to a gas line, 12v power and a water source.
B L U E T O O T H S T E R E O / D V D / M P 3 P L A Y E R All Maverick Camper trailers and vans come with a pre-installed stereo system capable of playing AM and FM radio, Bluetooth connection to other devices, DVDs, CDs and MP3.
Australia. Hot water is never too far away. For more information on how to operate the Truma Hot Water System please use the following links: UltraRapid - Inform now (truma.com) https://www.truma.com/au/en/products/truma-hot-water-system/ultrarapid#to-7c6e30c5-2c7a-4f16-b54f- b16d12d4b3a7 Maverick Campers Operations Manual 2021...
Master Power and Water Pump switches on the Control Panel are in the on position. For more information on how to operate the Duoetto please see links below: DuoettoManual-1.pdf (ausj.com.au) https://ausj.com.au/wp-content/uploads/2018/05/DuoettoManual-1.pdf Maverick Campers Operations Manual 2021...
O N B O A R D D O M E T I C A I R C O N D I T I O N I N G A N D H E A T I N G All Maverick Camper Hybrids and the Matrix Limited Camper Trailer are equipped with a Dometic Reverse Cycle Air Conditioning unit.
D O M E T I C O N B O A R D F L U S H I N G T O I L E T All Maverick Camper Hybrid models come with an inbuilt Dometic flushing toilet and cassette system. These units making travelling a breeze and are very easy to use and maintain.
Page 36
- Inside is the waste cassette which needs to be removed and taken to a dump point - Below is a photo of the cassette inside the external door in the locked position for use Maverick Campers Operations Manual 2021...
Page 37
Once you arrive at the dump point, swivel the black pipe upwards as seen in the image above and unscrew the Be very careful as you are now in the danger zone for spillage of some very bad stuff Maverick Campers Operations Manual 2021...
P O R T A B L E T O I L E T This is included as part of the options pack on Maverick Campers Camper Trailers. Whilst there are various models that could be provided as part of the options pack, the theory is all the same.
Page 39
The cap on this side is the Fresh water filling for flushing. You may notice the middle tab at the bottom of this image to open and close the middle seal dividing the two sections Maverick Campers Operations Manual 2021...
Page 40
(look for a switch or swivel tab on the unit which opens the seal) Be very careful in undertaking this entire process and should you get spillage of waste on yourself, be sure to immediately clean the area and disinfect. Maverick Campers Operations Manual 2021...
The total permitted mass of the laden trailer/caravan transmitted to the ground by the caravan tyres, when carrying the maximum load recommended by the manufacturer, when coupled to a tow-vehicle. This rating must not exceed the axle-group (wheels/tyres/suspension/axle) rating stated by the chassis manufacturer. Maverick Campers Operations Manual 2021...
Whilst we would all love to be out enjoying the beautiful land, we call home all the time, sadly, for most of us we still have to work and therefore the Maverick Camper trailer or hybrid needs to be stored between trips. Below is a list of actions you should take to ensure your trailer or van are always ready to go and in peak condition for the longest period possible.
Page 44
(from Bunnings). These absorb condensation keeping everything dry. Ideally you should purchase 2 buckets with 1 being in or under a seat and one on the floor. Maverick Campers Operations Manual 2021...
Open the water inlet cap located on the side of the trailer or van and using a hose fill the tanks to full capacity c. Then repeat the opening of the tap or valve to empty the clean water out d. Your tanks are now flushed Maverick Campers Operations Manual 2021...
Page 46
Check that all latches are locking correctly and that the tension bolts on the inside of all external hatches and draws are tight to prevent dust coming inside o. Ensure external kitchen slide is locked and all connections are disconnected p. Ensure gas cylinder tap is off Maverick Campers Operations Manual 2021...
If travelling for an extended period of time, plan to book your van or trailer in for a service that aligns with your itinerary and book it in ahead of time How remote are you going – plan to have at least 2 if not 3 forms of communication (phone, cb radio & satellite phone) Maverick Campers Operations Manual 2021...
To the left is the hitch pin. This is installed to the towing tongue connected to your vehicle’s tow bar. The team at Maverick Campers will install the hitch pin to your vehicle during the handover process. To the left is the locking pin which doubles as a handle to tighten...
Page 49
McHitch straight on top of the tow pin Once in position, use the jockey wheel to adjust the heigh of the hitch to ensure you can drop the hitch onto the tow pin Maverick Campers Operations Manual 2021...
Page 50
Once you cannot tighten any further, remove the locking pin from the hole and thread it through the base of the hitch which will provide the secondary bond between trailer/van and vehicle. Maverick Campers Operations Manual 2021...
Page 51
Connect safety chains with appropriately rated shackles. Chains should be crossed over and long enough to allow tight turning, but not too long that they touch the ground. The idea of crossing the chains is they act like a cradle and catch the hitch should it become disconnected. Maverick Campers Operations Manual 2021...
Plug in the lighting plug and check all lights and indicators. The electrical plug only fits one way, so line up its cut-out with the lug on the bottom edge of the socket. Maverick Campers uses 7 pin rectangular connections as standard. You can purchase alternative connectors to change from rectangular to circle to suit your car.
The ideal site isn’t always available as seen on many youtube videos and travelling shows but it is important to pick the right site to suit your needs. Here is a list of things to consider when finding a suitable site to unhitch and enjoy your Maverick Campers’ van or trailer: Size of the site...
For more information on positioning your van/trailer check out the link below. There are plenty of sources of good information on this topic: How to Level and Position Your Caravan or RV | Snowys Blog https://www.snowys.com.au/blog/levelling-positioning-caravan-rv/ Maverick Campers Operations Manual 2021...
McHitch as the image below shows: The images above show how to release the safety switch and unwind the hitch cap with the locking pin at the same time. Maverick Campers Operations Manual 2021...
Page 56
At this stage it’s a good idea to lift the McHitch off the towing pin on the tow bar of the towing vehicle and re- insert the locking pin and clip to ensure they are not lost during the holiday. You can now safely drive your vehicle away from the van/trailer Maverick Campers Operations Manual 2021...
Step 1: Lower the stabilizer legs Included with your Maverick Camper Trailer is a winder for manually winding down your stabilizer legs. All trailers except for the Hornet V2 have a stabilizer leg on each of the 4 corners. The Hornet V2 only requires two at the rear of the trailer.
Page 58
Ideally have another person on the boat rack mount side to catch the boat rack when it is pushed over Push the boat rack over gently Reinstall the safety pins to prevent the boat rack moving or, Maverick Campers Operations Manual 2021...
Page 59
Whilst the roof folding mechanism is gas strut assisted, it will not speed up or slow down the motion so it is important that you are doing the initial and final controls of motion to prevent damage to the trailer Maverick Campers Operations Manual 2021...
Page 60
Now that the roof is secure, you can start to attach the external canvas skirts of the tent to the camper body via the eyelets and special hooks Maverick Campers Operations Manual 2021...
Page 61
You can now enter the trailer to commence tensioning the poles to create the room and tensioned roof Lift the gas strutted bow poles at each end of the trailer and push them upwards to create the end walls Maverick Campers Operations Manual 2021...
Page 62
To complete the inside of the trailer move the cushions into position and set up the folding table to create the club lounge Also set up the bed in readiness for sleeping Maverick Campers Operations Manual 2021...
Page 63
Open the control panel and turn on the Master Power switch (if not already on) Turn on the fridge button if commencing the use of the fridge at the destination. Turn on the lights button to allow internal and external lights to be used as needed. Maverick Campers Operations Manual 2021...
Page 64
Then connect these roof poles to the floor poles (which are easy to identify as they have a rubber black foot) Attach spreader poles between the roof poles to create tension and secure the roof. Repeat this process until you are left with a roof structure as per below: Maverick Campers Operations Manual 2021...
Page 65
We provide several different types of slide out kitchens however all have similar function and setup processes, firstly, Open the door of the kitchen slide. Disengage the latches holding the slide in position. Pull the kitchen out slowly until the latches engage. You will hear a click. Maverick Campers Operations Manual 2021...
Page 66
Pull the drainage racks up and secure them in place. Open the wind guards and open the glass lid of the stove (on Dometic stoves only) Maverick Campers Operations Manual 2021...
Page 67
Pull the electrical wires out from under the sink and connect them into the power outlets on the side of the trailer. One is the for the flexible kitchen LED light and the other is for the stove ignition. Turn on the Pump switch on the control panel. Maverick Campers Operations Manual 2021...
Once secure, the boat rack can now be folded over and secured into position Always check that all gas, water, electrical and other non-permanent connections are turned off and are disconnected Maverick Campers Operations Manual 2021...
The general process of setting up a hybrid is as follows; Step 1: Lower the stabilizer legs Included with your Maverick Camper Hybrd is a winder for manually winding down your stabilizer legs. All Hybrids have a stabilizer leg on each of the 4 corners.
Page 70
Enter the hybrid via the main door and watch your head as the roof will be in the lowered position and it is easy to bump your head Unpin the internal roof bars at each end of the hybrid. Maverick Campers Operations Manual 2021...
Page 71
Push the roof bar at the rear of the hybrid first and then engage the pins through the roof bar holes to secure the roof into position and prevent it accidently dropping Repeat the same at the front of the hybrid The roof should be fully up and safe for use Maverick Campers Operations Manual 2021...
Page 73
2 to 3 latches to allow it to swing down. To assist with the lowering, the bar is gas strut supported but will need to be controlled by yourself on the decent to prevent damage Maverick Campers Operations Manual 2021...
Page 74
You will see two black push latches at the top left and right side of the underside of the bed frame Push these latches and gentle lower the wall down Note: this does have some weight and is not gas strut supported Maverick Campers Operations Manual 2021...
Page 75
The underside of the bed frame should rest on the brackets at the bottom of the side walls Maverick Campers Operations Manual 2021...
Page 76
There are two types of locks that hold this wall in place. One is a bolt style locking the rear walls to the side walls and the other secures the roof to the rear wall Maverick Campers Operations Manual 2021...
Page 77
Once competed, go inside the hybrid through the main door and unfold and setup the bed as required Step 4: Power up the Hybrid Maverick Camper Hybrids come with several options to power the Hybrid: Fixed solar panels on the roof which charge the batteries...
Page 78
Step 5: Water Tanks & Water Inlet Setup Maverick Camper Hybrids come with 2 options for water supply. You can fill up the fresh water tanks prior to departure or at a reliable, clean water source at your destination via the water inlet.
Page 79
Our hybrids come with an isolation valve to change which tank the water pump draws from. The isolation valve is located under the bed base or dinette seating depending on which model you have purchased. Turn the valve to the desired tank labeled on the handle mechanism to choose the tank Maverick Campers Operations Manual 2021...
Page 80
Step 7: Opening the Electric Awning The electric awning installed on all Maverick Camper Hybrids is the quickest and easiest solution for shade. To operate the unit follow these instructions: Turn the main power switch to on located on the control panel...
Page 81
Then install the awning roof poles which are identifiable by the rubber foot that sits against the roof of the hybrid Then attach the floor poles to the roof poles and attach spreader poles in between to create a strong structure. Repeat this process until all poles are in place Maverick Campers Operations Manual 2021...
Page 82
Step 9 – Slide out and Setup the Outdoor Kitchen This process is identical to the process documented in the camper trailer section. Please review this page on how to setup and pack down the slide out kitchen. Maverick Campers Operations Manual 2021...
Always open the tent ASAP to allow it to dry even if it is still raining as it is better to continue to get wet. It only takes a couple of days for mold to start forming. Maverick Campers Operations Manual 2021...
3. There is little lag time between the moment the tow vehicle’s brakes are actuated and the moment the trailer brakes are actuated. 4. They can provide some braking independent of the tow vehicle in the event of an emergency. Maverick Campers Operations Manual 2021...
B A T T E R Y C A R E Your Maverick Camper is fitted with 100Ah AGM Batteries. Storage type batteries require periodical maintenance to perform at their peak and extend their service life. You also have the option of charging your batteries via the onboard battery charger to do this you will require access to a 240-volt power supply, this can be a powered camp site or via a generator.
10-year service life. This information is stamped on the bottle base. Once you connect your gas bottle you can connect the kitchen gas hose to the bayonet connection provided. Maverick Campers Operations Manual 2021...
Even if you’re not going away on any major journeys make it part of that annual maintenance, when doing the bearings, to give them a thorough check over. Don’t imagine that worn shock absorbers are something you can live with. Maverick Campers Operations Manual 2021...
B R A K E S Brakes should be checked and adjusted as necessary with new campers after the first 500km when the brake shoes and drums have 'bedded in', and at every 5000km interval, or as use and performance requires. While you have the drums off doing the bearings is a good time to check them.
W A T E R T A N K S Mars Campers recommend that you should clean your water tank when you pick up and take home. Buy a reputable tank cleaner from your camping store and follow their instructions on care and maintenance. Remember there are different techniques for stainless tanks to plastic tanks.
Page 90
Once a year give your zips a light spray with silicon to keep them sliding easily and check any press studs, bungee loops or other fasteners and give the stitching a once-over to make sure nothing is coming apart. Maverick Campers Operations Manual 2021...
(6) Maverick Campers Forward Fold Ranger Limited Walk Through Video – YouTube https://www.youtube.com/watch?v=Izn4ZrYezw4&t=67s R A N G E R A I R (6) Maverick Campers Ranger Air Light Weight Forward Fold Off-road Trailer Only 920KG Tare!! - YouTube https://www.youtube.com/watch?v=snwMM-xymx0&t=117s Maverick Campers Operations Manual 2021...
R A N G E R S L I D E (6) Maverick Campers Ranger Slide Forward Fold Off Road Trailer - YouTube https://www.youtube.com/watch?v=zjLsRBOkzig M A T R I X (6) Maverick Campers Matrix Double Fold Camper Walkthrough - YouTube https://www.youtube.com/watch?v=r7leNcEVjio...
V I P E R 1 6 (6) Maverick Campers Viper 16 Hybrid Off Road Caravan - YouTube https://www.youtube.com/watch?v=5ZmDHePCvjE&t=18s Maverick Campers Operations Manual 2021...
Safety chains and shackles connected to car. Crossed and at correct length Trailer is sitting at correct level Jockey wheel is raised and locked Do a walk around and check visually Maverick Campers Operations Manual 2021...
D U O E T T O H O T W A T E R S Y S T E M DuoettoManual-1.p D O M E T I C I N T E R N A L T O I L E T M A N U A L dometic-cts-4110_9 107100618_71735.pdf Maverick Campers Operations Manual 2021...
Page 97
For more information and assistance feel free to visit our website: www.maverickcampers.com.au or call us on 1300 XXX XXX Maverick Campers Operations Manual 2021...
