Glissando TL 170
Add-on Hinge Soft
Closing Solution
Glissando TL 170
'snap-on'
Soft closing mechanism
Striking plate
Made of steel and plastic
2.13
For S-type 170 and B-type 170 hinges
For the following
Technical details
cup types
41
K
52.5
Legend of hinge cup symbols
Screw-on
Machine
Pre-mounted
ready
insertion
euro screws
ready
Item number
170°
951-0F15-650
Box content
100 pcs soft closing mechanisms
100 pcs striking plates
Pre-mounted
Easy-fix
Pre-mounted
chipboard
system
expando
screws
dowels
Advertisement
Table of Contents
Related Manuals for Titus Glissando TL 170
Summary of Contents for Titus Glissando TL 170
- Page 1 Glissando TL 170 Add-on Hinge Soft For S-type 170 and B-type 170 hinges Closing Solution For the following Technical details cup types Item number Glissando TL 170 170° 951-0F15-650 'snap-on' Box content 100 pcs soft closing mechanisms 100 pcs striking plates Soft closing mechanism 52.5...
- Page 2 Turn towards ‘+’ to increase and ‘-’ to decrease the damping Mounting details Toolless mounting Insert Glissando TL 170 into the holes on the hinge cup Press down Place the striking plate into the hole on the hinge arm Press down...
