USER MANUAL : CDS552 CIRRUS LOOP LOGGER
CDS552 Cirrus Loop Logger User Manual
Document Number:
Client:
Date:
Issue:
Status:
Classification:
S/W File Name
Copyright Cape Digital Solutions.
This document contains information relating to the rights of Cape Digital Solutions. The confidentiality
agreement provisions are applicable to this document. When no longer needed for authorised
purposes, this document must be destroyed or returned to Cape Digital Solutions.
Cape Digital Solutions reserves the right to change the design or specifications of their products
without prior notice.
The contents of this manual is the property of Cape Digital Solutions and may not be copied or modified
without prior permission, in writing, from Cape Digital Solutions, Cape Town, South Africa.
DOCUMENT NAME
CDS552 CIRRUS LOOP LOGGER USER
MANUAL
CDS552 Cirrus Loop Logger User Manual
User
1 December 2020
V1.0
Draft
Confidential
CDS552 Cirrus Loop Logger User Manual.docx
CLASSIFICATION
CONFIDENTIAL
DATE
PAGE
15-JUL-21
1 OF 29
Advertisement
Table of Contents
Related Manuals for cloudworks CDS552
Summary of Contents for cloudworks CDS552
- Page 1 USER MANUAL : CDS552 CIRRUS LOOP LOGGER CDS552 Cirrus Loop Logger User Manual Document Number: CDS552 Cirrus Loop Logger User Manual Client: User Date: 1 December 2020 Issue: V1.0 Status: Draft Classification: Confidential S/W File Name CDS552 Cirrus Loop Logger User Manual.docx Copyright Cape Digital Solutions.
- Page 2 USER MANUAL : CDS552 CIRRUS LOOP LOGGER AMENDMENT HISTORY Issue Date Amendment Details Amended By 13 July 2021 Compile document Alex Romanov DOCUMENT NAME CLASSIFICATION DATE PAGE CDS552 CIRRUS LOOP LOGGER USER CONFIDENTIAL 15-JUL-21 2 OF 29 MANUAL...
-
Page 3: Table Of Contents
1.9 Installation considerations ....................13 Logger Setup ....................14 2.1 Setup via Bluetooth Configure ................... 14 2.2 CDS552 Cirrus Loop Logger Setup via Remote Configure ..........26 2.3 CDS552 Cirrus Loop Logger Setup via Offline Script Configure ........28 DOCUMENT NAME CLASSIFICATION DATE... -
Page 4: Cds552 Cirrus Loop Logger
The Cirrus Loop Logger has been designed to allow for easy installation and setup without the need for a complicated server infrastructure. Setup and management software (CloudWorks) is also supplied free of charge to allow clients to manage their own networks and data. There are no monthly charges for collecting and hosting data as the client can provide this service themselves. -
Page 5: Specifications
USER MANUAL : CDS552 CIRRUS LOOP LOGGER Onboard 24V 30mA power generator. The Cirrus Loop logger can generate a stable 24V output at a maximum of 30mA allowing for the powering of an external piece of equipment or current loop device eliminating the need for a secondary power supply. -
Page 6: Architecture
USER MANUAL : CDS552 CIRRUS LOOP LOGGER Architecture LTE/4G GSM Bluetooth Interface Interface Non volatile Central Input 2 x Pulse memory Processor Interface Inputs 24V 30mA 2 wire Isolated Power Generator 4-20mA Input Management External 12V 3 x Alkaline Power Supply... -
Page 7: Led And Button Functions
USER MANUAL : CDS552 CIRRUS LOOP LOGGER LED and button functions On the front of the logger, there are 2 LED's and a touch sensitive 'SELECT' button. Internally on the reverse side of the lid is the Bluetooth reset button. -
Page 8: Connections
USER MANUAL : CDS552 CIRRUS LOOP LOGGER In order to reset the Bluetooth interface, with the housing open, please follow the below procedure. Remove all power from the logger - remember to remove the batteries if external power is present. -
Page 9: External Power Supply / Solar System Connection
1.7.1 The CDS552 Cirrus Loop logger can be powered entirely from an external 12V (8-15V) 2A power supply or solar power source. Using a solar power source and also populating the logger with alkaline batteries means that the logger can be put into dual mode. -
Page 10: Using The Pulse Inputs
USER MANUAL : CDS552 CIRRUS LOOP LOGGER To assist with the powering of loop devices, the Cirrus Loop logger is equipped with an onboard 24V loop power generator. This generator is designed to provide the power for devices that source this directly off the loop. Since the maximum power to flow on a 4-20mA loop, should be 20mA, the generator has been designed to supply a maximum of 30mA. - Page 11 USER MANUAL : CDS552 CIRRUS LOOP LOGGER Example configuration of water meter with electronic interface. Please note the polarity of the interface. Ground connection to pin 8 (or 10 for Input 2). DOCUMENT NAME CLASSIFICATION DATE PAGE CDS552 CIRRUS LOOP LOGGER USER...
-
Page 12: Sim Card And Battery Installation
USER MANUAL : CDS552 CIRRUS LOOP LOGGER 1.8 Sim card and battery installation The CDS552 Cirrus logger uses a MicroSIM and is installed as follows. 1. Slide the cover plate backwards to unlock. 2. Flip the cover plate up to expose the connections. -
Page 13: Installation Considerations
1.9 Installation considerations The CDS552 Cirrus Loop logger is environmentally rated to IP68 - max1.2m. In order to achieve this, it is critical that any cables entering the logger are properly sealed by the IP68 gland. This gland is designed to only have one cable exiting the logger and not multiple ones. -
Page 14: Logger Setup
2.1 Setup via Bluetooth Configure The CDS552 Cirrus Loop logger has an onboard Bluetooth interface which allows for the device configuration to be done locally. There are two different places in the software to activate the Bluetooth connection. The first option is from the log in screen at start up. - Page 15 USER MANUAL : CDS552 CIRRUS LOOP LOGGER The second option is on the Zone screen by pressing the 'Device Setup' button. Activating this function will launch the Bluetooth Server which will search for the available remote devices in the immediate vicinity.
- Page 16 Once the Bluetooth connection has been established, Cloudworks will automatically activate the correct configuration screen needed for each device type. This device will immediately be placed into Command Mode and the current setup data retrieved and displayed on the right hand screen.
- Page 17 USER MANUAL : CDS552 CIRRUS LOOP LOGGER To switch between the Diagnostic Mode and Command Mode, simply press the 'Command/Connect' button. Switching from the Diagnostic Mode to Command Mode can take several seconds depending on what the logger is currently executing.
- Page 18 USER MANUAL : CDS552 CIRRUS LOOP LOGGER Local IP Local IP address assigned by the GSM network. This data is important when using a static IP system to ensure that the correct IP has been assigned to the logger. Datalog Size Number of records in the datalog/maximum number possible for the selected application type.
- Page 19 Very important here is the 'Vendor Code'. The Cloudworks System supports multiple databases. What this means is that the server will automatically populate the database that is associated with a specific logger. Each database and logger has a Vendor Code assigned to it.
- Page 20 Cloudworks loggers support the use of simcard pin codes. How this works is - should a simcard have a pincode activated, it will request the pincode when the modem powers up and starts connecting to the network.
- Page 21 USER MANUAL : CDS552 CIRRUS LOOP LOGGER Datalog timings are calculated forward from midnight of the day on which they are set. What this means is that if the datalog period is set to 5 minutes for instance, the next log time will be calculated as 5 minute intervals starting from midnight.
- Page 22 USER MANUAL : CDS552 CIRRUS LOOP LOGGER The second is the 'Heartbeat Time'. This is for powered loggers only. The server will continuously ping the logger at the interval set by this timer. The logger will respond to the ping and the two will remain in communications. Should the logger not receive two heartbeat pings in a row, it will assume there has been a failure in the communications and abort the connection and go back to sleep (battery) or re-establish a connection (powered).
- Page 23 The Bluetooth interface may be setup with or without access via password. The password used is the Bluetooth Password setup under the General Setup option in CloudWorks. As long as the logger's requested password and the system Bluetooth Password are the same, the connection will be established.
- Page 24 Upgrading firmware on the logger can be done through the Bluetooth interface. Newer versions of the software for each type of device is embedded into the Cloudworks software so will not need an internet connection to collect the data. When in Command Mode, press the 'Upgrade Firmware' button. The first thing the software will do is to determine the current firmware version on the logger and see if there is an upgrade available.
- Page 25 USER MANUAL : CDS552 CIRRUS LOOP LOGGER Once the upgrade is complete, the following message will be displayed. Please power cycle the logger and then reconnect the Bluetooth interface if you wish to carry out further configurations. A note about power cycling a logger - when a logger is in battery mode and asleep, disconnecting the battery will not cycle the device.
-
Page 26: Cds552 Cirrus Loop Logger Setup Via Remote Configure
2.2 CDS552 Cirrus Loop Logger Setup via Remote Configure Once the remote connection has been established, Cloudworks will automatically download the current setup data and display it on the screen. This data can be refreshed at any time by pressing the 'Refresh' button in the top menu. - Page 27 - and pressing ENTER. The logger will then send an SMS to that number. The message should read, 'Hello from Cirrus Loop Logger CDS552 - Device Code xxxxxxxxxx'. The receiving number can then be used to send sms commands to that logger.
-
Page 28: Cds552 Cirrus Loop Logger Setup Via Offline Script Configure
USER MANUAL : CDS552 CIRRUS LOOP LOGGER 2.3 CDS552 Cirrus Loop Logger Setup via Offline Script Configure Once activated, the correct blank Scripting Editor screen will be displayed, ready for the capture of the settings that need to be altered. - Page 29 USER MANUAL : CDS552 CIRRUS LOOP LOGGER Pending commands are those that still need to be executed. Listed also is the response to each command for diagnostic purposes. You can read back the current script to determine its status at any point by pressing the 'Read Script' button.
