FIELD HAWKEN Henley Table Assembly Instructions

Assembly Instructions for Henley Table

Parts Included

Item
Tabletop
Leg brace including parasol hole
Legs
50mm Bolts (for leg brace)
30mm Bolts (for tabletop)
Metal Parasol Ring and Cover
Allen key
Screws
If you discover any of the stated parts are missing or damaged, please contact Field & Hawken
customer support immediately for it to be rectified and replacements provided if required.

Tools Required

Allen Key
Screwdriver (not provided)

Recommended Persons for Assembly

It is recommended that at least 2 people assemble this table.
Assembly Instructions
1. Lay the tabletop face down on some padding or protective material.
2. Assemble the leg components and spreader bar by matching the small numbered stickered
joints (E.g. A1 to A1, A2 to A2, etc.). Use the 50mm bolts to secure the spreader bar in place
and tighten using an allen key.
3. Insert the assembled leg structure into the tabletop matching any small numbered stickered
joints again. The tenon joint from the top of the legs goes inside the mortice joint in the
tabletop so that the 3 holes are aligned for the bolts to go through. Use the 30mm bolts to
secure the legs in place to the tabletop and tighten using an allen key.
4. Turn the table over and tighten any loose bolts. Do not overtighten.
5. If required, you can use the screws to tighten the leg structure fix to the tabletop. Insert the
screws into the predrilled holes in the leg braces between the legs and screw into the
tabletop. It is recommended that light pressure is applied in the direction of the arrows in
the picture to ensure a tight contact when screwing in. Screw in one side first, followed by
the next.
6. Insert the metal parasol ring.
Should you have any questions or concerns then please contact us.
Phone: 0118 942 2248, Email:
Thank you for your purchase
(2019 Design)
Quantity
1
1
2
4
4
1
1
4-8 (4 required)
1
1
