Summary of Contents for Billion SG200
- Page 1 ZigBee Lighting Control Box SG200 User’s Manual www.billion.com.tw www.smartgrid.com.tw...
-
Page 2: Table Of Contents
Table of Contents CHAPTER 1 Introduction...............1 Warning................3 Wiring and LED description..........4 Join or Leave ZigBee Network.........6 CHAPTER 2 Specification ……………...........8 Application Scenarios ............. 9 www.billion.com.tw www.smartgrid.com.tw... -
Page 3: Chapter 1 Introduction
For example, if a warehouse is empty, the lights in this warehouse should be off to save energy. In this application, the SG200’s DI can connect to a motion sensor detecting human activities. SG200 then can automatically turn the lights on/off based on the environmental variables. - Page 4 AC power cable and a lighting power cable to the quick install terminals of SG200. SG200 will support automatic allocation with Billion Smart Energy Gateway when triggering the pairing function on the smart gateway. The LED indicator on the front panel is for the customer to understand the communication and the relay status.
-
Page 5: Warning
www.smartgrid.com.tw... -
Page 6: Wiring And Led Description
Dimming 1(+) Dimming 2(+) Dimming 3(+) Dimming 4(+) Reset to default setting when press button 5 seconds LED on: SG200 not join ZigBee network LED blink: SG200 joined ZigBee network. LED on: Relay on. LED off: Relay off. www.billion.com.tw www.smartgrid.com.tw... - Page 7 Wiring example www.billion.com.tw www.smartgrid.com.tw...
-
Page 8: Join Or Leave Zigbee Network
1-1. ZigBee join and leave Just press ZigBee button of SG6200NXL gateway when SG200 is not yet join ZigBee network, then SG200 will automatically join ZigBee Network with SG6200NXLGateway. 1.2.1 Join Plug in ZigBee SG200 AC power Check ZigBee LED status of SG200, If ZigBee LED is on then next step Press ZigBee button of SG6200NXLgateway d. - Page 9 www.smartgrid.com.tw...
-
Page 10: Chapter 2 Specification
Power Requirements Input : 100~277VAC 50/60Hz RF Specifications ZigBee 2.4GHz(2405~2480MHz) IEEE 802.15.4-2003 Output power < 8dBm Operating Environment Operating temperature: 0°C – 60°C Storage temperature: -20°C – 70°C Humidity: 20% – 95% non-condensing www.billion.com.tw www.smartgrid.com.tw... -
Page 11: Application Scenarios
www.smartgrid.com.tw... - Page 12 Manufacturer: Billion Electric Co., Ltd. Address：8F., No.192, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.) www.billion.com.tw www.smartgrid.com.tw...
