Summary of Contents for Wildwood BASIC TV LIFT CABINET
- Page 1 W i l d w o o d T V L I F T F U R N I T U R E BASIC TV LIFT CABINET SETUP INSTRUCTIONS...
- Page 2 Tools Page Tools: Tape Measure 4mm Allen Wrench Phillips Screwdriver...
- Page 3 Step 1 Lift the lid by pressing down at the very back edge of the lid to access the mechanism. Feed the Power Strip’s cord out through the hole in the backing, as illustrated and plug it in to a power source in you home.
- Page 4 Hardware Washer ” Spacer TV Mounting Bracket (1 Left) (1 Right) ” Spacer 40mm Machine Screw 15mm Machine Screw (4 of Ø6mm) OR (4 of Ø 8mm) (4 of Ø6mm) OR (4 of Ø 8mm) Step 3: Attaching the TV Mounting Brackets On the back of the TV there are 4 threaded holes.
- Page 5 Attach the TV Mounting Brackets to the back of the TV. The TV Mounting Bracket must be positioned as close to the top of the TV as possible (without going above the TV), while still being able to access all 4 holes of the VESA Pattern through the TV Mounting Bracket.
- Page 6 Hardware 10mm Machine Screw Lift Bracket (Comes pre-installed in the Lift Bracket) Step 4: Installing the Lift Brackets Measure the distance between the top of the TV and the top of the TV Mounting Brackets. ” Step 5 Use this illustration as a guide to determine where to install the Lift Bracket.
- Page 7 Step 6 Use a 4mm Allen Wrench and remove the 10mm Machine Screws from the Lift Bracket. Do not discard the screws. Step 7 Attach the Lift Bracket to the Mechanism (Through the hole found in Step 5) using the 10mm Machine Screws that were removed in Step 6.
- Page 8 Profile View Step 8 Lower the mounted TV down into the Footboard. Check that the TV fits into the space inside of the Footboard. Check that: 1. The TV does not collide with the Cabinet Bottom, or the Mechanism’s motor 2.
- Page 9 Hardware 10mm Machine Screw Lift Bracket (Comes pre-installed in the Lift Bracket) Step 9 Raise the Mechanism again to its full height and remove the Now attach the 2 Lift Bracket to the mechanism in the 4 hole below the upper Lift Bracket.
-
Page 10: Anti-Tip Bracket
Warning: This TV lift product must have an anti-tip device installed to prevent the unit and TV from accidently being tipped over. Failure to install the anti- tip device could result in injury or death. Step 11 Move the cabinet to the desired location. Leave space between the back of the cabinet and the wall to work behind. - Page 11 Attach the 2 Anti-tip Bracket to the cabinet. As illustrated. Note the Anti-Tip is located on the 3” board just below the lid and aligned with the bracket on the wall. Screw the Anti-tip Bracket to the 3” board on the back of the cabinet using two of the ”...
-
Page 12: Cotter Pin
Hardware Clevis Pin Cable Cotter Pin Step 12 Beginning with the Anti-tip Bracket attached to the wall insert the eyelet of the cable between the bracket as shown. Secure the cable in place using the Clevis Pin. Now secure the Clevis Pin in place with the Cotter Pin.
