Prosafe
Hydraulic Self Closing Gate
Installation & MAINTENANCE
MANUAL
-22 QUEENS SQUARE, HODDLESDEN, DARWEN, LANCASHIRE. BB3 3NQ
MOSSFIELD ROAD, ADDERLEY GREEN, STOKE ON TRENT, STAFFORDSHIRE. ST3 5BW
Tel: + 44 (0)1254 703212 Fax: +44 (0)1254 707407 WEB: www.multihog.co.uk
TEL: 01782 339320 FAX:01782 339321 WEB: www.iae.co.uk
BF J000 0009 10
V1.1
SEP 2015
Advertisement
Table of Contents
Summary of Contents for IAE Prosafe
- Page 1 -22 QUEENS SQUARE, HODDLESDEN, DARWEN, LANCASHIRE. BB3 3NQ MOSSFIELD ROAD, ADDERLEY GREEN, STOKE ON TRENT, STAFFORDSHIRE. ST3 5BW Tel: + 44 (0)1254 703212 Fax: +44 (0)1254 707407 WEB: www.multihog.co.uk TEL: 01782 339320 FAX:01782 339321 WEB: www.iae.co.uk BF J000 0009 10 V1.1...
- Page 2 General Installation Standard gate dimensions Installation Ensure that the gate posts are set vertical and that the closing gap not less than 25mm. It is important to settle the mechanism. Allow at least 1 hour after installation before the first operation. The gate should now be operated to check the speed.
- Page 3 Maintenance Bi-annual inspection:- Check speed: Open gate to 90° and allow to close. If speed needs adjusting, refer to the instructions on page 1. Check bottom mounting block: Check M8 setscrews and tighten if necessary. Check M6 cap screws and tighten if necessary. Check all fixings and bump stop.
- Page 4 For further information contact your Authorised Dealer Dealer Stamp MOSSFIELD ROAD, ADDERLEY GREEN, STOKE ON TRENT, STAFFORDSHIRE. ST3 5BW TEL: +44 (0)1782 339320 FAX: +44 (0)1782 339321 WEB: www.iae.co.uk...
